CAUTION: You must read this manual
before connecting this device. There is a
strict procedure to follow especially when
connecting older vintage ampliers that are
not equipped with safety grounds.
RADIAL ENGINEERING
Radial Engineering Ltd. warrants this product to be free from defects
in material and workmanship and will remedy any such defects free
of charge according to the terms of this warranty. Radial Engineering
will repair or replace at its option any defective component(s) of this
product, excluding the nish, the tube, the footswitch (tubes and
footswitches are warranted for 90 days) and wear and tear from
normal use, for a period of three (3) years from the original date of
purchase. In the event that a particular product is no longer available,
Radial Engineering reserves the right to replace the product with
a similar product of equal or greater value. In the unlikely event
that a defect is uncovered, please call 1-800-942-1001 or email
service@radialeng.com to obtain an RA number (Return Authorization
number) before the 3 year warranty period expires. Once you have
obtained an RA number you must return the product, freight prepaid,
within fteen (15) days after the date the RA number is issued. To
make a request or claim under this limited warranty, the product must
be returned prepaid in the original shipping container (or equivalent)
to Radial Engineering or to an authorized repair centre and you must
assume the risk of loss or damage. A copy of the original invoice
showing date of purchase and the dealer name must accompany any
request for work to be performed under this limited warranty. This
limited warranty shall not apply if the product has been damaged due
to abuse, misuse, misapplication, accident or as a result of service or
modication by any other than an authorized repair centre.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN
THOSE ON THE FACE HEREOF AND DESCRIBED ABOVE. NO
WARRANTIES WHETHER EXPRESSED OR IMPLIED, INCLUDING
BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY PERIOD
DESCRIBED ABOVE OF THREE YEARS. RADIAL ENGINEERING
SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING
FROM THE USE OF THIS PRODUCT. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH MAY VARY DEPENDING ON WHERE YOU LIVE
AND WHERE THE PRODUCT WAS PURCHASED.
www.tonebone.com
www.radialeng.com
1588 Kebet Way, Port Coquitlam, BC V3C 5M5
tel: 604-942-1001 fax: 604-942-1010
email:info@radialeng.com
JX-2 Users Guide v2.0 - Feb. 2010 Part #: R870 1030 00
Specications and appearance subject to change without notice. Copyright
© 2010 Radial Engineering Ltd.
www.radialeng.com
www.radialeng.com
True to the Music
Radial Engineering
1588 Kebet Way, Port Coquitlam BC V3C 5M5
tel: 604-942-1001 • fax: 604-942-1010
email: info@radialeng.com • web: www.radialeng.com
JX•2 Switchbone
Users Guide
®
™
INDEX PAGE
Caution ............................................................................... 1
Introduction ......................................................................... 3
Concept ............................................................................. 3
Grounding .......................................................................... 4
Feature set 5 ........................................................................
Getting started 6 ....................................................................
Switch LED indicators 7 ........................................................
Drag™ Control 8 ...................................................................
Boost Circuit 8 .......................................................................
Set-ups ............................................................................... 9
Questions & Answers ............................... Inside back cover
Warranty .................................................Outside back cover
Greetings from Radial! You are now an official Bonehead!
The following manual has been written to assist you with your new Radial
JX2 Switchbone. Please take the time to read it so you can take maximum
advantage of all the features that have been designed into this marvelous
device and are familiar with the safety procedures.
Should you have any questions on the Switchbone, please visit our web
site www.tonebone.com for up-to-date information. Occasionally, take
a few minutes to peruse the questions and answers section for helpful
tips that will surely emerge as more and more Switchbones are sold. If
by chance you have a question that is not covered in this manual or on
our web site, please feel free to contact Radial at info@radialeng.com
and we will do our very best to get you an answer quickly. These ques-
tions are often the source for more FAQs on our site and serve to help
other Boneheads.
In the interim, enjoy! The Switchbone has been developed to help
you make music more fun and hopefully, enhance your creative spirit.
Now get out there and re up that double stack!
JX•2 Switchbone
User Guide
™
<<<<<<< CAUTION >>>>>>>
Please read before connecting
electronic devices to your JX2!
Caution must be used when connecting electronic equipment to
the JX2 switchbone. The JX2 bridges all electronic equipment
connected to it so faulty wiring or incorrect grounding of any of
the equipment may cause a shock hazard to be present and/or
damage to the JX2 or other connected equipment. Because
grounding schemes differ between manufacturers, it is important
to check for correct polarity, in particular with older ampliers using
2-prong unprotected A/C cords. If the polarity is reversed on an
ungrounded amplier there may be a potential of 120V present
between the amp chassis and ground. Radial Engineering takes
no responsibility for this or how the JX2 is connected or used.
It is the user’s full responsibility to ensure that proper electrical
polarity is maintained on all equipment connected to the JX2 and
that proper building electrical codes have been followed wherever
the JX2 is being used.
To reduce opportunity for shock hazard or damage to the JX2 or
connected equipment, plug the ¼” connectors into the ampliers
rst and then to the JX2. This is especially important when using
old ampliers that do not have 3-prong plugs as the possibility ex-
ists to touch the chassis ground with the connector plug tip when
the plug is inserted into the jack.
Cautions for ampliers with ungrounded 2-prong A/C cords:
Before connecting any input to an ungrounded amplier, power the
amp up and listen to the residual hum. If the amp has a two-posi-
tion ground polarity reverse switch, set the switch in the position
that produces the least residual hum from the speakers. If there
is no polarity switch, reverse the A/C plug at the outlet to nd the
least residual hum.
To ensure an ungrounded amplier does not present a shock
hazard: Test for voltage potential by connecting a voltmeter be-
tween the amplier chassis and the JX2 chassis. If voltage is pres-
ent, reverse the amplier’s A/C supply polarity and test again.
Note that due to this potential problem, damage to the JX2 or
other connected equipment caused by improper A/C polarity is
not covered by warranty.
Radial Engineering Ltd. Switchbone
™
Users Guide
1
2
Radial Engineering Ltd. Switchbone
™
Users Guide
