Side 1/20

600TV Lines

Super High

Resolution

Color Camera

3-AXIS VANDAL RESISTANT

DOME CAMERA

Please read this manual thoroughly before use, and keep it handy for future reference.

Design and specifications are subject to change without notice.

- ii -

WARNING

CAUTION

CAUTIONCAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER(OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of uninsulated "dangerous voltage"

within the product's enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the product.

Should any liquid or solid object fall into the cabinet,

unplug the unit and have it checked by the qualified

personnel before operating it any further.

Unplug the unit from the wall oulet if it is not going to

be used for several days or more. To disconnect the

cord, pull it out by the plug. Never pull the cord itself.

Allow adequate air circulation to prevent internal heat

build-up. Do not place the unit on surfaces (rugs,

blankets, etc.) or near materials(curtains, draperies)

that may block the ventilation holes.

Height and vertical linearity controls located at the

rear panel are for special adjustments by qualified

personnel only.

Do not install the unit in an extremely hot or

humid place or in a place subject to excessive

dust, mechanical vibration.

Clean the unit with a slightly damp soft cloth.

Use a mild household detergent. Never use

strong solvents such as thinner or benzine as

they might damage the finish of the unit.

Retain the original carton and packing

materials for safe transport of this unit in the

future.

Safety ----------------------------------------- Installation -----------------------------------

Cleaning --------------------------------------

PRECAUTIONS

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR

MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR

OTHER OPENINGS ON THE EQUIPMENT.

Produkt Specifikationer

Mærke:	REVO
Kategori:	sikkerhedskamera
Model:	REVDN600-2
Vekselstrømsindgangsspænding:	24 V
Højde:	115 mm
Vægt:	700 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Relativ luftfugtighed ved drift (H-H):	0 - 96 %
Format til analogt signal:	NTSC, PAL
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	811 x 507 pixel
Forbindelsesteknologi:	Ledningsført
Diameter:	146 mm
Indbygget HDD:	Ingen
Hvidbalance:	Auto, Manual
Sensortype:	CCD
Optisk zoom:	- x
Digital zoom:	4 x
Grænseflade:	BNC
Strømforbrug:	200 mA
Sammensat videoudgang:	1
Strøm over Ethernet (PoE):	Ingen
Bredt dynamikområde (WDR):	Ja
Dag/nat funktion:	Ja
Minimumsbelysning:	0.04 Lux
Optisk sensorstørrelse:	1/3 "
Nattesyn:	Ja
Bevægelsessensor (video):	Ja
Brændviddeområde:	2.8 - 12 mm
Kameraets lukkerhastighed:	0.016 - 0.00001 sek./side
Signal/støjforhold:	50 dB
Kamera lukker type:	Elektronisk
PTZ-kontrol:	Ja
Antal TV-linier:	600
NTSC opløsninger:	811 x 507 pixel
PAL opløsninger:	795 x 595 pixel
