X3
Key Features
● Support for HDR
● Modular Design throughout for input and output
● Hot swap input and output modules
● 4K@60 inputs compatible including HDMI 2.0,
DisplayPort1.2
● Up to 12G-SDI Input option
● 4K/2K EDID Management
● Multiple operation modes
● Support for 3D signal
● Control via XPOSE and T series consoles
● Redundant hot swap PSU option
Application
Dimensions
Order Codes
Product Code Item
310-0003-10-0
X3
190-0003-01-0
Quad DVI Input Module
190-0003-02-0
Quad HDMI Input Module
190-0003-03-0
Quad VGA Input Module
190-0003-04-0
Quad 3G SDI (SCALE) Input Module Product Code Item
190-0003-06-0
Octuple CVBS Input Module
190-0003-21-0
Quad DVI Output Module
190-0003-07-0
Quad USB Input Module
190-0003-22-0
Quad 2K HDMI Output Module
190-0003-11-0
4K@30 Digital Input Module
190-0003-24-0
Quad 3G SDI Output Module
190-0003-13-0
Quad H.264 Input Module
190-0003-25-0
Quad HDBaseT Output Module
190-0003-15-0
4K@60 Digital Input Module
190-0003-28-0
ARO Rotation Module
190-0003-17-0
12G SDI Input Module
190-0003-38-0
4K HDMI Output Module
190-0003-18-0
Quad HDBaseT Input Module
950-0001-00-0
Power Supply 200W
Tel: +86-592-5771197 | Fax: +86-592-5788216 | E-mail: sales@rgblink.com
Headquarter: S601 Weiye Building,Torch Hi-Tech Development Zone,Xiamen,Fujian,P.R.C.
www.rgblink.com
Specifications are correct at time of printing and subject tochange or alteration without notice.
Specification
4 slots, up to 16 inputs
4K@60 Module
1 x DVI-I | 2 x HDMI-A | 1 x DisplayPort
4K@30 Module
2 x DVI-I |2x HDMI-A (1 In/1 Loop)| 2x DisplayPort (1 In/1Loop)
12G SDI Module
4 x BNC (1 x 12G SDI input, or 4x3G SDI Input）
3G SDI Module
8 x BNC (4 In | 4 Loop)
HDMI Module
4 x HDMI-A
DVI Module
4 x DVI-I
H.264 Module
4 x RJ 45
HDBaseT Module
4 x RJ 45
VGA Module
4 x DB15
CVBS Module
8 x BNC
USB Module
4 x USB-A
2slots, up to 8 outputs
HDMI Module
4 x HDMI-A
DVI Module
4 x DVI-I
HDBaseT Module
4 x RJ 45
4K HDMI Module
2 x HDMI-A
ARO Rotation Module
4 x DVI-I
LAN
1 x RJ 45
RS 232
1 x RJ 11
1 x USB
1 x USB-B
Genlock/Sync
1 x BNC | 1 x HDMI-A
Power
2 slots
Up to 2 power Inputs
IEC
SDI
SMPTE
480i | 576i | 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080i@59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 |
1080psf@23.8/24/25/29.7/30
DVI | HDMI
SMPTE
720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@239.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.8/24/25/29.7/30
VESA
800x600@60 | 1024x768@60 | 1280x768@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1440x900@60 | 1400x1050@60 |
1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 2048x1080@60 | 2048x1152@60 | 2560x960@60
HDBaseT
SMPTE
720p@50/60 | 1080p@24/25/30/50/60
VESA
800x600@60/75/85 | 1024x768@60/75/85 | 1280x768@60 | 1280x800@60 | 1280x1024@60/75/85 |
1360x768@60 | 1366x768@60 | 1400x900@60 | 1400x1050@60 | 1600x1200@60 | 1680x1050@60 |
1920x1080@60 | 1920x1200@60 | 2048x1152@60 | 2560x812@60 | 2048x816@60
CVBS
SMPTE
480i | 576i
VGA
VESA
800x600@60 | 1024x768@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1400x1050@60 |
1440x900@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60
176x144 | 240x180 | 320x180 | 320x240 | 320x256 | 352x228 | 352x480 | 400x224 | 400x320 | 480x270 | 480x272 |
480x320 | 480x360 | 480x480 | 544x480 | 608x448 | 640 x 360 | 640x480 | 704x576 | 720x404 | 720x480 | 720x540 |
1280x720 | 720x576 | 850x480 | 1024x576 | 1680x1056 | 1920x1080
4K@30
SMPTE
480p| 576p| 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@30
VESA
800x600@60 | 1024x768@60 | 1280x800@60 | 1280x1024@60 | 1400x1050@60 | 1440x900@60 | 1600x1200@60 | 1680x1050@60 |
1920x1080@60 | 2048x1080@60 | 2048x1152@60 | 2560x1600@60 | 3840 x 2160@30
4K@60
SMPTE
720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@50/59.94/60 | 2160p@30/60
VESA
800x600@60 | 1024x768@60 | 1280x768@60 | 1280x800@60 |1280x1024@60 | 1360x768@60 | 1366x768@60 |1400x900@60 |
1600x1050@60 | 1600x1200@60 |1680x1050@60 | 1920x1080@60 | 1920x1200@60 | 2048x1080@60 | 2048x1152@60 |
2560x812@60 | 2560x960@60 | 2560x1600@60 |3840x1080@60| 3840x2160@30 | 3840x2160@60
12G SDI
SMPTE
720p@50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@23.98/24/25/29.97/30/50/59.94/60
Select from below or configure customized
SDI
SMPTE
720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.8/24/25/29.7/30
DVI | HDMI
SMPTE
720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60
VESA
800x600@60 | 1024x768@60 | 1280x800@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1440x900@60 |
1400x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 2048x1152@60
HDBaseT
SMPTE
720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@239.98/24/25/29.97/30/50/59.94/60
1024x768@60/75/85 | 1280x768@60 | 1280x800@60 | 1280x1024@60/75/85 | 1360x768@60 | 1366x768@60 |
1400x900@60 | 1400x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@ 60 | 1920x1200@60 |
1920x1080@60 | 2560x812@60 | 2048x816@60
4K HDMI
SMPTE
720p@25/30/50/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@23.98/24/25/29.97/30/50/60
800x600@60 | 1024x768@60 | 1280x768@60 | 1280x800@60 |1280x1024@60 | 1360x768@60 | 1366x768@60 |
1400x900@60 | 1600x1050@60 | 1600x1200@60 |1680x1050@60 | 1920x1080@60 | 1920x1200@60 | 2048x1152@60 |
2560x812@60 | 2560x816@60 | 2560x1600@60 |3840x1080@60 | 3840x2160@ | 4096x2160@60
SDI
SMPTE ST 2082-1, SMPTE ST 2081-1, SMPTE ST 424, SMPTE ST 292-1, SMPTE ST 259, DVB-ASI,MADI
HDMI
2.0
DP
1.2
DVI
Dual Link
HDBaseT
1.0
Grey Level
12 bit
Color Space
4:4:4
Input Voltage
AC 100V-240V, 50/60Hz
Max Power
205W
Temperature
0 55℃～ ℃
Hudmidity
10%~90%
Net
12.3kg
Package
20.4kg
Net
485mmx387mmx135mm
Package
635mmx545mmx275mm
Headquarter: S601 Weiye Building,Torch Hi-Tech Development Zone,Xiamen,Fujian,P.R.C.
