Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Tools needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
TV Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
LIFETIME LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Introduction
Congratulations on your purchase of a high-quality Rocketfish product. Your
RF-HTLF23 represents the state of the art in TV wall-mount design and is designed for
reliable and trouble-free performance.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
• This product is designed ONLY to be installed into wood studs, solid concrete,
or concrete block.
• DO NOT INSTALL INTO DRYWALL ALONE — DRYWALL ALONE WILL NOT HOLD
THE WEIGHT OF YOUR TV.
• This product is designed for INDOOR USE ONLY.
• The wall must be capable of supporting five times the weight of the TV and
mount combined.
• Do not use this product for any purpose not explicitly specified by
manufacturer.
• Manufacturer is not responsible for damage or injury caused by incorrect
assembly or use.
• Improper installation may cause property damage or personal injury. If you do
not understand these directions, or have doubts about the safety of the
installation, contact Customer Service or call a qualified contractor. Rocketfish
is not responsible for damage or injury caused by incorrect installation or use.
• The weight of your TV and accessories must not exceed 100 lbs. (45.3 kg).
• This product contains small items that could be a choking hazard if swallowed.
Keep these items away from young children!
