T U R N

O V E R

1998-2013 Harley-Davidson®

PMX-HD9813 Radio Tuning Guide for

STAGE1, STAGE2 & STAGE3 Systems.

0 9 -03-2019 E r i c R u s s e l l

1 2 2 0 - 7 2 8 8 5 - 0 1 - A

7 BAND EQ: FLAT

CROSSOVER:

FRONT HPF: 60Hz @ 12dB/Oct.

REAR HPF: 60Hz @ 12dB/Oct.

SUB LPF: APF

PU N C H EQ: GAIN 0

FLAT: Use on non-Rockford Fosgate systems.

ST AGE1:

Upper Fairing

ST AGE2:

Upper Fairing + Baglid s

RADIO DEFAU LTS

ST AGE3:

Upper Fairing + TourPak

Upper Fairing + TourPak + Baglid s INTERNAL AMPLIFIER: ON

HD9813RG-STAGE1

HD9813RG-STAGE2

HD9813RG-STAGE3

HD9813RGU-STAGE1

HD9813RGU-STAGE2

HD9813RGU-STAGE3

HD9813SG-STAGE1

HD9813SG-STAGE2

HD9813SG-STAGE3

HD9813SGU-STAGE1

HD9813SGU-STAGE2

HD9813SGU-STAGE3

AUDIO KIT PRESE T :

These PMX-HD9813 tunings are

independently optimized ONLY

for Rockford Fosgate TMS speaker

systems due to their unique

frequency response. They are not

for use with other speaker brands.

1) P ress & Hold MEN U to

access SETTINGS.

2) Rotate VOLUME,

press to select AUDIO.

3) Rotate VOLUME, press to

select AUDI O KIT P RESET.

4) Radio will automatically

reboot & load preset.

TURN

OVER

1998-2013 Harley-Davidson

TM400X4ad Amp Tuning Guide for PMX-HD9813

on STAGE2 & STAGE3 Systems.

For other radi os, refer to Knowledge Base Answer ID #1355.

REAR INPUT LEVEL: 9:00 (1/4)

Matches the amp to the radio.

Tells the amp where to “cli p.”

FRONT INPUT LEVEL: 8:00 to 9:00

When using baglids or TourPak ,

reduce fai ring speaker output

by tri mmi ng front gain so fr ont

& rear are equally balanced.

FRONT & REAR EQUALIZER: 12:00

Works with PM X-HD9813 DSP

to pr ovide excepti onal

bass & treble response.

INPU T SWITCH: 4CH

Number of i nputs to feed amp.

New harness supports

integrated 4-channel

front/rear audio.

Must use rear speak er

harness on PM X-HD9813.

CROSSOVER FREQUENCY: 50Hz

Tells amp what fr equencies to pass.

Motorcycles use thi s as a “bass blocker”

to pr event subwoofer frequenci es from

damagi ng fai ri ng and bagli d speakers.

(latched to HP/AP/LP swi tch)

CROSSOVER SWITCH: HP (Hig h-Pass)

Type of crossover needed.

(works with crossover frequency dial)

[HP (High-Pass) allows frequenci es above to pass]

[AP (All-P ass) allows all frequencies to pass]

[LP (L ow-Pass) allows frequencies below to pass]

TURN-ON O.K.

blue remote wire not required

0 9 -0 3 - 2 0 1 9 E r i c R u s s e l l

1 2 2 0 - 7 2 8 8 5 - 0 1 - A

RADIO O.K.

no ﬂash required

Ro ckfor d Fos gate

PMX- HD 981 3
