Side 1/28

Model:RPI430 / RPIF430 / RPI430MM

TABLES DE CUISSON

NOTICE D’EMPLOI ET D’INSTALLATION

HOBS

INSTRUCTIONS FOR USE AND INSTALLATION

- SA DES USINES DE ROSIERES LUNERY

18400

USINES DE ROSIÈRES

ІНСТРУКЦІЯЗ ЕКСПЛУАТАЦІЇ ТА ПІДКЛЮЧЕННЯ

ВБУДОВАНО Ї ІНДУКЦІЙНОЇ ПОВЕРХНІ UK

RPI342 / RPIF342 / RPI342MM / RPI346

Model:

1 GB

READ THE INSTRUCTIONS BOOKLET CAREFULLY TO MAKE THE MOST OF YOUR HOB.

We recommend you keep the instructions for installation and use for later reference, and before installing the hob, note its serial number

below in case you need to get help from the after sales service.

We are constantly striving to improve product quality and as such may modify appliances to incorporate the latest technical improvements.

Induction hobs conform to irectives 73/23/CEE and 89/336/CEEEuropean D , replaced by 2006/95/EC and 2004/108/EC,

and subsequent amendments.

Identification plate

(located under the hob's bottom casing)

• It is strongly recommended to keep children away from the cooking zones while they are in operation or when they are switched off,

so long as the residual heat indicator is on, in order to prevent the risks of serious burns.

• When cooking with fats or oils, take care always to watch the cooking process as heated fats and oils can catch fire rapidly.

• The hob’s control area is sensitive, do not place hot containers on it.

• Aluminium foil and plastic pans must not be placed on heating zones.

• After every use, some cleaning of the hob is necessary to prevent the build up of dirt and grease. If left, this is recooked when the

hob is used and burns giving off smoke and unpleasant smells, not to mention the risks of fire propagation.

• Do not left metallic objects such as knives, forks, spoons or lids on the induction zone,because if they are too large or too heavy, they

could become hot.

• Never cook food directly on the glass ceramic hob. Always use the appropriate cookware.

• Always place the pan in the centre of the unit that you are cooking on.

• Do not use the surface as a cutting board.

• Do not slide cookware across the hob.

• Do not store heavy items above the hob. If they drop onto the hob, they may cause damage.

• Do not use the hob as a working surface.

• Do not use the hob for storage of any items.

• In the unlikely event of a surface crack appearing, do not use the hob. Immediately disconnect the hob from the electrical power supply

and call the After Sales Service.

Warning: this appliance complies with current safety regulations and electromagnetic compatibility regulations. Nevertheless,

people with a pacemaker should not use this appliance. It is impossible to guarantee that all such devices found on the market

comply with current safety regulations and electromagnetic compatibility regulations, and that dangerous interference will not

occur. It is also possible that people with other types of device, such as a hearing aid, could experience some discomfort.

GENERAL WARNINGS

RPI430/RPIF430/RPI430MM

4 INDUCTION

560 X 490

590 X 520 X 55

220-240V~ 50/60 Hz

7000

d X w X h

400 V 50/60Hz

3 INDUCTION

7200

RPI342/RPIF342/RPI342MM/RPI346

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

•

Produkt Specifikationer

Mærke:	Rosieres
Kategori:	Komfur
Model:	RPI 430
Antal effektniveauer:	15
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	230 V
Bredde:	590 mm
Dybde:	520 mm
Højde:	50 mm
Vægt:	11000 g
Produktfarve:	Sort
Kontroltype:	Berøring
Indbygget skærm:	Ja
Strøm:	16 A
Pakkevægt:	12000 g
Pakkedybde:	580 mm
Pakkebredde:	680 mm
Pakkehøjde:	130 mm
Timer:	Ja
Placering af apparat:	Indbygget
Installationsrum bredde:	560 mm
Installationsrum dybde:	490 mm
Komfurtype:	Zone induktionskogeplade
Overfladetype:	Keramisk
Antal kogeplader / madlavningsområde:	4
Antal elektriske kogeplader:	4
Blus/kogeplade zone 1 strøm:	2300 W
Blus/kogeplade zone 2 strøm:	1200 W
Blus/kogeplade zone 1 type:	Stor
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre bagende
Blus/kogeplade zone 1 strømkilde:	Elektrisk
Blus/kogeplade zone 2 type:	Simre
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre front
Blus/kogeplade zone 2 strømkilde:	Elektrisk
Kontrolposition:	Front
Blus/kogeplade zone 3 type:	Simre
Blus/kogeplade zone 4 type:	Stor
Blus/kogeplade zone 2 diameter:	150 mm
Blus/kogeplade zone 1 diameter:	220 mm
Blus/kogeplade zone 3 diameter:	150 mm
Blus/kogeplade zone 4 diameter:	220 mm
Blus/kogeplade zone 4 strømkilde:	Elektrisk
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Elektrisk
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Højre bagende
Blus/kogeplade zone 4 position:	Højre forside
Restvarmeindikator:	Ja
Holde varm funktion:	Ja
Blus/kogeplade zone 4 strøm:	2300 W
Blus/kogeplade zone 3 strøm:	1200 W
Boost funktion:	Ja
Almindelig kogeplade/kogezone, diameter:	150 mm
Simre kogeplade/kogezone, diameter:	150 mm
Simre kogeplade / madlavningsområde:	1200 W
Almindelige kogeplade / madlavningsområde:	1200 W
Stor kogeplade / madlavningsområde:	2300 W
Ekstra stor hurtig kogeplade / madlavningsområde:	2300 W
Stor kogeplade/kogezone, diameter:	220 mm
Ekstra stor højhastighed kogeplade/kogezone, diameter:	220 mm
