Side 1/32

RMZ-955

MULTI-ROOM

SYSTEM

Installation & Operation

Manual

MULT I-ZONE CUSTOM CONTROLLER RMZ-955

ZONE A

ACT IVE CODE

ZONE B

ACT IVE CODE

ZONE C

ACT IVE CODE

ZONE D

ACT IVE CODE

DIGIT ALLY CONT ROLLED AUDIO PROCESSING

I.R. TRANSMITT ER

POWER

Operating

Instructions

begin on Page 23

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT. INSERT FULLY.

APPLICABLE FOR USA, CANADA OR WHERE

APPROVED FOR THE USAGE

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET

POUSSER JUSQU AU FOND.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol is to alert the user to the

presence of uninsulated dangerous

voltages inside the product's enclosure

that may constitute a risk of electric shock.

This symbol is to alert the user to important

operating and maintenance (service)

instructions in this manual and literature

accompanying the product.

WARNING:

There are no user serviceable parts inside. Refer all servicing to

qualified service personnel.

WARNING:

To reduce the risk of fire or electric shock, do not expose the

RMZ-955 to moisture or water. Do not allow foreign objects to get

into the enclosure. If the unit is exposed to moisture, or a foreign

object gets into the enclosure, immediately disconnect the power

cord from the wall. Take the unit to a qualified service person for

inspection and necessary repairs.

Read all the instructions before connecting or operating the RMZ-955 . Keep

this manual so you can refer to these safety instructions.

Heed all warnings and safety information in these instructions and on the

product itself. Follow all operating instructions.

Clean the RMZ-955 only with a dry cloth or a vacuum cleaner.

Keep the ventilation inlets on the unit unobstructed. For example, do not place

the unit on a bed, sofa, rug, or similar surface that could block the ventilation

slots. If the RMZ-955 is placed in a bookcase or cabinet, there must be suffi-

cient clearance around the unit and ventilation of the cabinet to allow proper

cooling.

Keep the RMZ-955 away from radiators, heat registers, stoves, or any other

appliance that produces heat.

The RMZ-955 must be connected to a power supply only of the type and volt-

age specified on the rear panel of the unit.

Connect the RMZ-955 to the power outlet only with the supplied 3-pin polarized

grounded power supply cable or an exact equivalent. Do not modify the sup-

plied cable in any way. Do not attempt to defeat grounding and/or polarization

provisions. The cable should be connected to a 3-pin polarized grounded wall

outlet, matching the wide blade of the plug to the wide slot of the receptacle.

Do not use extension cords.

Do not route the power cord where it will be crushed, pinched, bent at severe

angles, exposed to heat, or damaged in any way. Pay particular attention to the

power cord at the plug and where it exits the back of the unit.

The power cord should be unplugged from the wall outlet if the unit is to be left

unused for a long period of time.

Immediately stop using the RMZ-955 and have it inspected and/or serviced by a

qualified service agency if:

• The power supply cord or plug has been damaged.

• Objects have fallen into or liquid has been spilled into the unit.

• The unit has been exposed to rain.

• The unit shows signs of improper operation

• The unit has been dropped or damaged in any way

Place the RMZ-955 on a fixed, level surface strong

enough to support its weight. Do not place the

RMZ-955 on a moveable cart that could tip over.

ZONE D

MULTI-ZONE CUSTOM CONTROLLER RMZ-955

ZONE A

ACTIVE CODE

ZONE B

ACTIVE CODE

ZONE C

ACTIVE CODE

ZONE D

ACTIVE CODE

DIGITALLY CONTROLLED AUDIO PROCESSING

I.R. TRANSMITTER

POWER

INPUTS

2 3 41

IN OUT IN OUT IN OUT IN OUT

RC-5N/C

TX-FORMAT

123456

ZONE B

DATA

123456

PRE-OUT

DATA

123456

PRE-OUT

SPEAKERSSPEAKERS SPEAKERSSPEAKERS

DATA

123456

PRE-OUT

DATA

1 2 3 4 5 6

PRE-OUT

ZONE C ZONE A

WE1

WE2

WE3

WE4

RC-5N/C

MULTI-ZONE CUSTOM CONTROLLER

MODEL NO. RMZ-955

POWER CONSUMPTION: 430W

AC120V ~ 60HZ

DESIGNED AND MANUFACTURED

IN ENGLAND

WARNING:

T O REDUCE THE RISK

OF FIRE OR ELEC TRICAL SHOCK DO

NOT EXPOSE THIS EQUIPMENT T O

RAIN OR MOIST URE.

SPEAKER IMPEDANCE

4 OHM MINUMUM

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

– + – +

LEFT RIGHT

– + – +

LEFT RIGHT

– + – +

LEFT RIGHT

– + – +

LEFT RIGHT

PAGING

T RIG GER

AUDIO IN

AUDIO OUT

UNSWITCHED SWITCHED

LINK IN

LINK OUT
