2Russound Acclaim Speakers Installation Manual
INTRODUCTION
Thank you for selecting the Russound Acclaim In-ceiling and In-wall Speakers.
Like all Russound speakers, they combine acoustic technology with durability
and will provide years of musical enjoyment. The speaker line provides
solutions for everything from background music to dedicated music listening
and even home theater installations.
Many of the Acclaim models use Russound's proprietary NeoDrive™
technology with advanced neodymium motor structures that weigh
substantially less than traditional speaker components. Russound Acclaim
speakers feature high quality drivers, sophisticated crossover networks, and
advanced designs to ensure optimum reproduction in your home for whatever
your favorite music may be.
RSG-6R
Round grille.
(included with
the speakers)
RSG-8R
Round grille.
(included with
the speakers)
RSG-6S
Square grille,
optional.
(sold separately)
RSG-8S
Square grille,
optional.
(sold separately)
Preparation/Wiring Info 3 ........................................................................................................
Preparation/Speaker Placement 4-5 ....................................................................................
Preparation for Installation 6-7 ..............................................................................................
Installation 8 .................................................................................................................................
Tests and Adjustments 9 ..........................................................................................................
Troubleshooting Guide 9 .........................................................................................................
Technical Specications 10 ......................................................................................................
Troubleshooting Guide & Warranty 11 ................................................................................
TABLE OF CONTENTS
RSA-615 RSA-635 RSA-835
RSF-610 RSF-620 RSF-610T RSF-820
RSF-635
Angeled Woofer for Directional Sound - 15o, two-way, in-ceiling
Two-way, in-ceiling, in-wall
Magnetic Edgeless Grilles
