RY36BI300A
Safety, performance, and dependability have been given top priority in
the design of your battery inverter.
INTENDED USE
The product may be used for the following purposes:
■operating and charging USB-powered devices
■supplying electrical power for operating compatible small electronics
such as cell phones, tablets, laptops, LED lights, fans, radios, etc.
The product is intended for indoor use only.
When a battery pack is installed, the product converts DC electricity to
230 V AC household power. When using a type A USB cable, the USB
port supplies 5 V DC USB (up to 3 A), 9 V DC USB (up to 2 A), 12 V DC
(up to 1.5 A) charging power. When using a type C USB cable, the USB
port supplies 5 V DC USB (up to 2 A), 9 V DC USB (up to 2 A), 12 V DC
(up to 2 A), 20 V DC (up to 2 A) charging power. The USB ports share
internal circuitry. If two USB ports are in use at the same time, the two
USB ports supply 5 V output only.
The product is rated at 300 W power output. Check the power rating
of your electrical device before using with the product. Do not use the
product if the power rating of your electrical device exceeds 300 W.
GENERAL SAFETY WARNINGS
Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, re and/or serious injury.
■Save these instructions. Refer to them frequently and use them to
instruct others who may use this product. If you loan someone the
product, loan them these instructions also.
■Do not expose the product to rain, wet, or damp conditions. Water
entering the product increases the risk of electric shock.
■Do not use the product if it has been dropped or received a sharp
IMPORTANT!
The product is not intended to be used or cleaned by persons with reduced physical, sensory or mental capabilities, or lack of experience or
knowledge unless they have been given instructions concerning the safe use of the product by a person legally responsible for their safety. They
should be supervised while using the product. Children shall not use, clean or play with the product, which when not in use should be secured out
of their reach.
x2
0%
x2
30%
x2
100%
2s
1
7
4
5
8
3
2
6
1
blow. A damaged product increases the risk of fire. Always inspect
the product for damages before use.
■Remove the battery pack from the product when not in use.
■Do not disassemble or modify the product. Electric shock hazard
may occur even when a battery is not installed. Any part that is
damaged should be properly repaired or replaced by an authorised
service centre.
■
To reduce the risk of injury, close supervision is necessary when the
product is used near children.
■Store the product indoors and away from children.
■Use caution when plugging or unplugging other devices into the
product. Do not force plugs into the product.
■If the product is used in a manner not specified by the manufacturer,
the protection provided by this equipment may be impaired.
■Do not overload the product. The product must be used for powering
devices less than the product rating.
■Never block the air vents. Blocked vents may cause overheating.
The product automatically turns off when overheated.
■Keep the product cool. Do not place the product near heat vents or
in direct sunlight.
■Do not use the product around flammable fumes and gases, such as
in the bilge of a boat or near propane tanks.
■Do not put foreign objects into the product.
■Operate the product using only the AC power type listed in the
product specifications.
■The product should never be hard-wired into a circuit.
■Do not leave the product unattended during operation.
■Operate the product only in temperatures between 0°C and 40°C.
■Do not use the product to power life support devices or other
medical equipment.
■Risk of electric shock. When using a grounded appliance, the product
does not provide an electrical path to earth ground. Do not power
devices that are damaged or with damaged or frayed power cords.
■An internal cooling fan runs to regulate the product’s operating
temperature. Always wait for the fan to stop before disconnecting
the battery pack from the product.
■Use RYOBI 36V MAX POWER battery packs only. Do not use
battery packs from other manufacturers.
■Do not at any time, let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc., come in contact with plastic parts.
Chemicals can damage, weaken, or destroy plastic, which could
result in serious personal injury.
■The light source of the product is not replaceable. When the light
source reaches its end of life, the product must be replaced.
■Do not use a multiple socket outlet or adaptor on the AC socket.
KNOW YOUR PRODUCT
See illustration.
1. 5. LED indicatorPower / Light button
2. Type A USB charging port 6. AC socket
3. Type C USB charging port 7. Area Light
4. Wall hanger holes 8. Battery port
SYMBOLS ON THE PRODUCT
Safety alert
Remove the battery pack before starting any work on the
product.
Beware of electric shock hazard.
Do not expose to rain or damp conditions
Read the instructions carefully before starting the product.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
Double insulation
Isolated inverter
F20A*2
Fast blow fuse
Never block the air vents.
Do not use the product in a vertical position unless
mounted on a wall.
Use the product in a horizontal position.
Indoor use only
Conforms to all regulatory standards in the country in the
EU where the product is purchased.
EurAsian Conformity Mark
Ukrainian mark of conformity
PRODUCT SPECIFICATIONS
Battery Inverter
Model: RY36BI300A
Supply: 36 V DC, 12.5 A MAX, 450 W MAX
Output: 230 V AC, 50 Hz, 300 W
Type A USB: 5 V DC max 3 A / 9 V DC max 2 A / 12 V DC max 1.5 A
Type C USB: 5 V DC max 2 A / 9 V DC max 2 A / 12 V DC max 2 A /
20 V DC max 2 A
*The USB ports share internal circuitry. If two USB ports are in use at
the same time, the two USB ports supply 5 V output only.
Dimensions: 140 mm x 75 mm x 80 mm
Weight: 300 g
Compatible battery packs (not included): BPL36***, RY36B***
099631008001-01
POWER BUTTON LED FUNCTIONS
LED indicator Status Troubleshooting
Green The product is on.
Flashing red The product is overloaded. 1. Press the
power/light button
to remove the lock state. The LED indicator turns o󰀨.
2. Disconnect the all devices. Make sure that the battery is su󰀩ciently charged.
3. Press the
power/light button
button to turn on the AC socket.
4. Reconnect all devices. If the LED indicator ashes red again, the devices exceed the
capacity of the product.
Red The product is overheated. 1. Disconnect all devices. Allow the product to cool down until the LED indicator ashes red.
2. Briey press the
power/light button
to reset the product. When the LED indicator turns green,
reconnect the devices.
Flashing yellow The battery charge is low. Remove and charge the battery.
Flashing red (3x) The battery charge is
insu󰀩cient.
Remove and charge the battery.
EN 61000-6-1:2019; EN61000-6-3:2017+A1:2011; EN 62477-
1:2012 + A11:2014 +A1:2017; IEC 60598-2-4: 2017, IEC
60598-1: 2014 + A1: 2017, EN 60598-2-4: 2018, EN 60598-1:
2015 + A1: 2018, IEC 62031: 2018 and EN IEC 62031: 2020
RYOBI is a trade mark of Ryobi Limited,
and is used under license.
© 2020 Techtronic Cordless GP.
Imported by:
Techtronic Industries GmbH
Max-Eyth-Straße 10,
71364 Winnenden, Germany
