Side 1/3

Storage # 5507

Insert 4 cams (with arrow out) into the box top panel. Using a

Philips screwdriver, screw 2 cam posts into the outside holes on

the back edge of the panel until tight to the panel. Insert 1 dowel

in each of the short edges of the panel and tap with a rubber

mallet until they cannot be inserted any further.

Insert 4 cams (with arrow out) into the bottom of the box bottom

panel. Using a Philips screwdriver, screw 2 cam posts into the

outside holes on the back edge of the panel until tight to the

panel. Insert 1 dowel in each of the short edges of the panel and

tap with a rubber mallet until they cannot be inserted any further.

Simple Collection

™

Assembly Instructions

For questions or concerns, please call 1-888-971-6225

available Monday-Friday 7:30 AM to 5:00 PM CST

(English-speaking operators)

safcoproducts.com

Product Warranty is available at:

Pan Head Screw

905000506

QTY:4

Cam Post

920000504

QTY:12

Barrel Nut

920000579

QTY:8

L-Bracket

420000198

QTY:4

Dowel

920000472

QTY:6

Cam

920000310

QTY:12

Pan Head Screw

905000508

QTY:8

Wood Screw

X5108

QTY:4

Leveler

Q444

QTY:4

Hardware Included:

Pack# 900000385

Other Hardware

Laminate Stickers

FCAP5

QTY:16

Box Bottom Panel

Tools required for assembly:

Phillips screwdriver and rubber mallet

Top Box Panel

Box Bottom Panel

Box Back Panel

Box Top Panel

Box Side Panel

Top Panel

99000359, Page 1 of 3, Rev B, Rev Date 01-MAR-2021

Insert 1 dowel in each of the long edges of the box back

panel and tap with a rubber mallet until they cannot be

inserted any further. Attach 4 cams into the panel with

the arrows facing the board edge.

Insert 4 barrel nuts into the box side panel (with the

open threaded holes in line with the holes in the panel)

and cover the head of each of the barrel nuts with a

laminate sicker. Using a Philips screwdriver, screw 2

cam posts into the outside holes on the top edge of the

panel and screw 2 cam posts into the outside holes on

the bottom edge of the panel until tight to the panel.

Repeat all of step 3 on the second box side panel.

Use a Phillips screwdriver to attach the legs to the box

side panels using the long pan head screws. Ensure the

threaded holes at the top of the legs are facing in.

Screw 1 leveler into

each leg until tight.

Attach the 2 box side panels (from step 3) to the box top

panel and box bottom panels. Use a Phillips screwdriver

to turn cams clockwise to tighten.

Place the box back panel (from step 4) on a ﬂat surface.

Attach the box top panel (from step 2) and the bottom

box panel (from step 1). Use a Phillips screwdriver to

turn cams clockwise to tighten.

Storage # 5507

Simple Collection

™

Assembly Instructions

Box Back Panel

Box Side Panel

Place cam sticker

over barrel nut

99000359, Page 2 of 3, Rev B, Rev Date 01-MAR-2021

Produkt Specifikationer

Mærke:	Safco
Kategori:	Ikke kategoriseret
Model:	5507
Bredde:	596.9 mm
Dybde:	355.6 mm
Højde:	751.84 mm
Vægt:	17690 g
Ramme, materiale:	Stål
Pakkevægt:	19050.88 g
Pakkedybde:	717.55 mm
Pakkebredde:	412.75 mm
Pakkehøjde:	196.85 mm
Styrehjul:	Ingen
Oprindelsesland:	USA
Ramme, farve:	Sort
Antal skuffer:	1 skuffe(r)
Andre farver på dele:	Valnød
Øvrige materialedele:	MDF
