Using the One Connect cable holder
(S95F, The Frame (LS03FA) only)
You can use the One Connect cable holder to tidy up the
cables while installing the wall mount.
•The image may differ depending on the model.
When you turn on your TV for the first time, it
immediately starts the Initial Setup. Follow the
instructions displayed on the screen and configure the
TV's basic settings to suit your viewing environment.
•You will need a Samsung Account to access our
network-based smart services. If you choose not to
log in, you will only get a connection to terrestrial TV
(applicable to devices with tuners only) and external
•43LS03F model as a wall mount, When installing the
it can be installed vertically and used.
–Some features may not support portrait mode or
–The initial setup is optimised for landscape mode.
You can turn on the TV with the TV Controller button at
the bottom of the TV, and then use the Control menu.
The Control menu TV Controller appears when the
button is pressed while the TV is On.
•The position and shape of the buttons at the bottom
of the TV may differ depending on the model.
•The screen may dim if the protective film on the
Samsung logo or the bottom of the TV is not detached.
If protective film is attached, remove the film.
•On model LS03FW, the TV Control button / Remote
Control Sensor may not be fixed in place and may move.
This is not a defect, but part of the design to ensure
smooth remote control sensing when a Customizable
Frame is installed, which is sold separately.
TV Controller Remote control sensor button / /
Microphone switch Motion Sensor / *
TV Controller Remote control sensor button /
•WARNING - TO PREVENT THE SPREAD
OF FIRE, KEEP CANDLES AND OTHER
ITEMS WITH OPEN FLAMES AWAY
FROM THIS PRODUCT AT ALL TIMES.
•To clean this apparatus, unplug the power cord
from the wall outlet and wipe the product with a
soft, dry cloth. Do not use any chemicals such as
wax, benzene, alcohol, thinners, insecticide, aerial
fresheners, lubricants, or detergents. These chemicals
can damage the appearance of the TV or erase the
•The exterior and screen of the TV can get scratched
during cleaning. Be sure to wipe the exterior and screen
carefully using a soft cloth to prevent scratches.
•Do not spray water or any liquid directly onto the TV.
Any liquid that goes into the product may cause a
failure, fire, or electric shock.
Make sure the following items are included with your TV.
If any items are missing, contact your dealer.
•Warranty Card / Regulatory Guide (Not available in
•*Remote Control & Batteries
•*Standard Remote Control & Batteries
•*CI Card Adapter (Depending on the country and model)
•**Wireless One Connect Box
•**One Connect Box Power Cord
•**One Connect cable holder (for wall mount)
*: Some of the items specified above may not be
included in the package, depending on the model or
**: Some components may not be provided, depending
on the One Connect connection method (wired or
How to turn on and off the Microphone
You can turn on or off the microphone by using the
switch at the bottom or rear bottom of the TV. If
microphone is turned off, All voice and sound features
using microphone are not available.
•This function is supported only in Q8F (except for
32Q8F)/QN7*F/QN*EF/QN8*F/QN9*F/QN9**F/S8*F/
•The position and shape of the microphone switch may
differ depending on the model.
•During analysis using data from the microphone, the
For more information, refer to "Troubleshooting" in the
(F6***F/H5***F: > left directional button >
Settings Support Open User guide Troubleshooting > > > )
(Other models: > left directional button > Settings
> > Support Tips and User Guides Open User guide > >
If none of the troubleshooting tips apply, please visit
"www.samsung.com" and click Support or contact the
•This panel is made up of sub pixels which require
sophisticated technology to produce. There may be, however,
a few bright or dark pixels on the screen. These pixels will
have no impact on the performance of the product.
•To keep your TV in optimum condition, upgrade to the
latest software. Use the Update Now Auto update or
functions on the TV's menu ( > left directional
button > > > Settings Support Software Update >
Update Now Auto update or ).
**: The number of One Connect cables provided may
differ depending on the model.
•The type of battery may vary depending on the model.
•The items’ colours and shapes may vary depending on
•Cables not included can be purchased separately.
•Check for any accessories hidden behind or in the
packing materials when opening the box.
•'One Invisible Connection' is communicated as 'One
Clear Connection' in Australia and New Zealand.
Warning: Screens can be damaged from
direct pressure when handled incorrectly.
We recommend lifting the TV at the edges,
as shown. For more information about
handling, refer to the Unpacking and
Installation Guide came with this product.
(One Connect Box Supported Model only)
For more information about how to connect via the One
Connect Box, refer to Unpacking and Installation Guide.
•Do not use the One Connect Box in the
upside-down or upright position.
•Take care not to subject the cable to any
of the actions below. The One Connect
Cable contains a power circuit.
CLASS 1 LASER PRODUCT (The Frame (LS03FA) only)
•Caution - Invisible laser radiation when open. Do not
–Do not bend the One Connect Cable excessively. Do
–Do not place heavy objects on the cable.
–Do not disassemble either of the cable connectors.
•Caution - Use of controls, adjustments, or the
performance of procedures other than those specified
herein may result in hazardous radiation exposure.
•Make sure that the power cord is securely plugged
into the product and the wall outlet.
•Make sure that the wall outlet is working and the
remote control sensor at the bottom of the TV is lit
•Try pressing the TV Controller button at the bottom of
the TV to make sure that the problem is not with the
remote control. If the TV turns on, refer to "The remote
The remote control does not work.
•Check if the remote control sensor at the bottom of
the TV blinks when you press the
–H5***F/HE50EF/F6***F/FE60EF/U7***F/U8***F/
UE8**F/UE1**F/QEF1/QE1F/Q6F: If it does not
blink, replace the remote control's batteries. Make
sure that the batteries are installed with their poles
(+/–) in the correct direction. Alkaline batteries are
recommended for longer battery life.
–Other models: When the remote's battery is
discharged, charge the battery using the USB
charging port (C-type), or turn over the remote to
expose the solar cell to light.
•Try pointing the remote directly at the TV from 1.5-1.8
•If your TV came with a Samsung Smart Remote
(Bluetooth Remote), make sure to pair the remote to
the TV. To pair a Samsung Smart Remote, press the
and buttons together for 3 seconds.
(except for H5***F, F6***F)
Eco Sensor adjusts the brightness of the TV
automatically. This feature measures the light in
your room and optimises the brightness of the TV
automatically to reduce power consumption. If you want
> left directional button >
Settings All Settings General & Privacy Power and > > >
Energy Saving Brightness Optimisation > .
•The eco sensor is located at the bottom of the TV.
Do not block the sensor with any object. This can
decrease picture brightness.
Other models: 3840 x 2160
Singapore / Malaysia only: UA43F6000FK
UA32H5000FK LS32H5000FK UA43U8000FK
UA50U8000FK UA55U8000FK UA58U8000FK
UA65U8000FK UA70U8000FK UA75U8000FK
UA85U8000FK UA43U8500FK UA50U8500FK
UA55U8500FK UA65U8500FK UA75U8500FK
UA85U8500FK UA43UE100FK UA50UE100FK
UA55UE100FK UA65UE100FK UA75UE100FK
UA85UE100FK QA43QEF1AK QA50QEF1AK
QA55QEF1AK QA55Q6F5AK QA65Q6F5AK
QA65QEF1AK QA75QEF1AK QA85QEF1AK
QA55Q6FAAK QA65Q6FAAK QA75Q6FAAK
QA85Q6FAAK QA43Q7FAAK QA50Q7FAAK
QA55Q7FAAK QA65Q7FAAK QA75Q7FAAK
QA85Q7FAAK QA55Q7F5AK QA65Q7F5AK
QA55Q75FAK QA65Q75FAK QA43Q8FAAK
QA50Q8FAAK QA55Q8FAAK QA65Q8FAAK
QA75Q8FAAK QA85Q8FAAK QA43Q80FAK
QA50Q80FAK QA55Q80FAK QA65Q80FAK
QA75Q80FAK QA85Q80FAK QA55QN1EFAK
QA65QN1EFAK QA75QN1EFAK QA85QN1EFAK
QA55QN3EFAK QA65QN3EFAK QA55QN70FAK
QA65QN70FAK QA75QN70FAK QA85QN70FAK
QA50QN80FAK QA55QN80FAK QA65QN80FAK
QA75QN80FAK QA85QN80FAK QA100QN80FK
QA55QN85FAK QA65QN85FAK QA75QN85FAK
QA85QN85FAK QA43QN90FAK QA50QN90FAK
QA55QN90FAK QA65QN90FAK QA75QN90FAK
QA85QN90FAK QA98QN90FAK QA115QN90FK
QA65QN900FK QA75QN900FK QA85QN900FK
QA65QN990FK QA75QN990FK QA85QN990FK
QA98QN990FK QA55S85FAE QA65S85FAE
QA77S85FAE QA83S85FAE QA42S90FAE
QA48S90FAE QA55S90FAK QA65S90FAE
QA77S90FAE QA83S90FAE QA55S95FAK
QA65S95FAK QA77S95FAK QA83S95FAE
QA65LS03FWK QA75LS03FWK QA85LS03FWK
QA43LS03FAK QA50LS03FAK QA55LS03FAK
QA65QN990FK (POC8001F) QA75QN990FK (POC8002F)
QA85QN990FK (POC8003F) QA98QN990FK (POC8004F)
QA55S95FAK (SOC5001F) QA65S95FAK (SOC5002F)
QA77S95FAK (SOC5003F) QA83S95FAE (SOC5004F)
QA43LS03FAK (SOC1001F) QA50LS03FAK (SOC1001F)
QA55LS03FAK (SOC1001F) QA65LS03FAK (SOC1002F)
F6***F (32"): 10 W, FE60EF/F6***F (43"): 20 W
U8***F/UE8**F/UE1**F/QEF1/Q6F/Q7F/Q8F/Q80F/
QN70F/QN1EF/S85F/S90F (42"): 20 W
QN85F/S90F (48"-83"): 40 W
QN90F (43"): 20 W, QN90F (50"): 40 W
QN3EF/QN90F (55"-115"): 60 W
QN990F (65"-85"): 90 W, QN990F (98"): 120 W
LS03FA (43"-50"): 20 W, LS03FA (55"-85"): 40 W
50 °F to 104 °F (10 °C to 40 °C)
10 % to 80 %, non-condensing
-4 °F to 113 °F (-20 °C to 45 °C)
5 % to 95 %, non-condensing
•This device is a Class B digital apparatus.
•For information about the power supply, and more
information about power consumption, refer to the
information on the label attached to the product.
–On most models, the label is attached to the back
of the TV. (On some models, the label is inside the
–On One Connect Box models, the label is attached
to the bottom of the One Connect Box.
•To connect a LAN cable, use a CAT 7 (*STP type) cable
for the connection. (100/10 Mbps)
•The images and specifications of the Unpacking and
Installation Guide may differ from the actual product.
•Operation of this product shall be limited to indoor
(QN900F, QN950F, QN990F, The Frame (LS03FW) only)
When you shut the TV off, it enters Standby mode. In
Standby mode, it continues to draw a small amount
of power. To decrease power consumption, unplug the
power cord when you don't intend to use the TV for a
This product is RoHS compliant.
This marking on the product, accessories
or literature indicates that the product
and its electronic accessories should
not be disposed of with other household
waste at the end of their working life. To
prevent possible harm to the environment
or human health from uncontrolled
waste disposal, please separate these
items from other types of waste and
recycle them responsibly to promote the
sustainable reuse of material resources.
For more information on safe disposal and recycling
visit our website www.samsung.com/in or contact our
Helpline numbers-1800 40 SAMSUNG(1800 40 7267864)
This product is qualified for the BEE Star rating in the
‘Home’ Mode. The Objectives of Star Labeling Program
is designed to promote energy efficient products and
When the television is initially set up, it is designed
to meet the BEE Star Labeling requirements while
maintaining optimum picture quality.
•Changes to certain functionalities of this television
(TV Guide, Picture/sound etc) may change the power
•Depending upon such changed setting (eg., Retail
mode), the power consumption may vary which
possibly could exceed the stated energy consumption.
To reset the television to Star rating qualified settings,
select ‘Home’ mode from the initial set-up procedure in
‘factory settings’ under the ‘Set-up’ menu.
