2_ Safety instructions
Contents
Features
• Air Turbo Drying System
Air Turbo technology spins the drum at high-
speed to extract more water so you can shorten
the drying time.
- Time Saving: AIR TURBO saves your time,
ensuring your clothes are dried 30%~40%
faster than line drying alone. Especially during
the rainy season and in high-humid weather,
laundry that once took days to drip-dry, such
as heavy jeans, bulky sweaters, and thick
blankets are dried more rapidly.
- Easy-to-iron: AIR TURBO is perfect for
delicates and clothes made of synthetic
fabrics. No more hanging and waiting. You can
iron items straight-out-of-the washer, since AIR
TURBO eliminates moisture and keep clothes
adequately damp for ironing.
• Transparent Window (depending on models)
- This Transparent Window is the new concept
to solve the curiosity of users to see inside of
washing machine while operation.
While operation, the laundry progress inside of
washing machine can be checked by looking
through the transparent window.
• Magic Mixer (depending on models)
- You don’t need to manually stir the detergent
with hand. With Magic mixer, just put detergent
in water start the Magic Mixer function.
Samsung Hexa Storm pulsator generates
strong water current and mixes the detergent
into water thoroughly.
How to use:
1. Fill the water in the tub at very low level.
2. Put required amount of detergent in the tub.
3. Set the WASH TIMER to Magic Mixer.
4. Set the WASH SELECTOR to Heavy.
5. Put clothes when you see bubbles in the tub.
Safety instructions
• Must follow the cautions and precautions for
safety intend to prevent unpredictable danger and
damage by helping the proper use in safety.
Cautions
• Be sure that the washing machine is
grounded.
To avoid electrical shock, use
a metal pipe for the ground
connection. But, don’t ground the
washing machine with gas pipes or
telephone lines to avoid to dangers
of explosion or lightning strike.
• Do not put your hands into the
spin basket when it is spinning.
You fingers can be caught by
spinning laundry and damaged.
• Never allow children to operate or
play with the washing machine.
Children playing with the washing
machine may accidentally fall into the
wash tub.
• Do not climb up the washing machine or lid.
• Must follow the cautions
below when the washing
machine is working.
Do not fall the wash-tray to
the wash tub when washing is
running.
• Disconnect the power cord from the power
supply when not in use.
• Ventilation opening must not be obstructed
by carpeting when the washing machine is
installed on a carpeted floor.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• To avoid overfilling and damages this
appliance must be filled with the operator
present using a moderate water supply
pressure only.
FEATURES . . . . . . . . . . . . . . .2
SAFETY INSTRUCTIONS . . . . . . . . .2
Cautions . . . . . . . . . . . . . . .2
Precautions when operating . . . . . . . .3
DESCRIPTION OF PARTS . . . . . . . . .4
CONTROL PANEL . . . . . . . . . . . .5
INSTALLATION . . . . . . . . . . . . .6
Environment . . . . . . . . . . . . . .6
Connecting the drain hose . . . . . . . .6
Connecting the supply hose . . . . . . . .6
CLEANING THE MACHINE. . . . . . . . .6
WASHING PROCEDURE . . . . . . . . .6
Washing . . . . . . . . . . . . . . .6
Soaking. . . . . . . . . . . . . . . .7
Spinning dry . . . . . . . . . . . . . .7
Heavy wash . . . . . . . . . . . . . .7
Delicates wash . . . . . . . . . . . . .8
Over flow wash . . . . . . . . . . . . .8
Spinning rinse . . . . . . . . . . . . .8
LAUNDRY GUIDE . . . . . . . . . . . .9
Washing time . . . . . . . . . . . . .9
Detergent . . . . . . . . . . . . . . .9
Spin dry time. . . . . . . . . . . . . .9
TEST PROGRAM. . . . . . . . . . . . .9
Test program. . . . . . . . . . . . . .9
MAINTENANCE . . . . . . . . . . . . 10
TROUBLESHOOTING . . . . . . . . . . 10
SPECIFICATIONS . . . . . . . . . . . 10
