Side 1/1

32"

813mm

1-1/2" O.D.

DRAIN TAILPIECE

1" IPS

FEMALE

SUPPLY

INLET

REMOVABLE

ACCESS PANELS

(NOT SHOWN)

1" IPS BRASS

STAY OPEN

BALL VALVE

WITH INLET

AND OUTLET

UNION

OPTIONAL SHOWER HEAD

STAINLESS STEEL

SHOWER HEAD

WITH 20 GPM FLOW CONTROL

HANGER BRACKET

(NOT SUPPLIED)

"PANIC BAR"

FOR ACTIVATING

EYE/FACE WASH

1 X 22" S.S. NIPPLE

(SUPPLIED)

ESCUTCHEON

(SUPPLIED)

SUSPENDED

CEILING

22"

559mm

INSTALLATION

Ø3/16"

4.8mm

MOUNTING

HOLE

4-1/2"

114mm

102mm

20-1/8"

511mm

2-5/8"

67mm

1-7/8"

48mm

23-5/16"

592mm

2-11/16"

68mm

1 X 5" GALV. NIPPLE

(SUPPLIED)

(9-1/2") (241mm)

ø 10-1/2"

267mm

FLANGE

FLOOR LINE

30-1/4"

768mm

25mm

FLANGE

ALL AROUND

18-3/4"

476mm

PULL DOWN

TO OPEN

EYE/FACE WASH

(BOTTOM OF

ROUGH IN)

FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND EXCEEDS ANSI STANDARD Z358.1.

WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.

WASTE CONNECTION MUST ADHERE TO LOCAL HEALTH AND PLUMBING CODES.

1" IPS

(NOT SUPPLIED)

3-1/2"

89 mm

10"

254mm

ACTIVATION

POSITION

SHOWER

"PANIC BAR"

IN THE OFF POSITION

82"-96"

2083mm-2438mm

34"

864mm

RECOMMENDED

NOTES:

DIMENSIONS MAY VARY BY ± 1/2" [12.7mm].4.

MOUNTING HARDWARE NOT SUPPLIED.

21-7/8"

556mm

TO FINISHED FLOOR

(34-5/8")

(879mm)

(47-1/2")

(1206mm)

DWG. NO.

APPROVED:

DRAWN:

PART NUMBER:

DRAWING NO.:

SCALE: SHEET OF

REV.

DRAWING TYPE:

THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS

MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.

SIZE:

BY:ECN NO.

DATE:

ECN:

REVISED PER

CHK'D.:

HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.

SPARKS, NEVADA 89431

(775) 359-4712 FAX (775) 359-7424

1455 KLEPPE LANE

E-MAIL: HAWS@HAWSCO.COM

WEBSITE: WWW.HAWSCO.COM

MODEL(S)

15915A00

I. ROBERTS

7/12/10

15915A00 6

0002080154.D

8356WCDD

1/18

1 1

4290 PF

INSTALLATION

4842

2013

(29-5/8")

(752mm)

EXTERNAL

DRAIN COVER

SEE DETAIL "A"

SHOWER HEAD MUST BE POSITIONED IN-LINE WITH EYE/FACEWASH HEAD TO ALLOW FOR

SIMULTANEOUS USE BY THE SAME USER PER ANSI Z358.1.

11"

BALL

DETENT

IN-LINE STRAINER

HOUSING
