Schumacher Electric Corporation

Model IP-1825FL

OWNER’S MANUAL

INSTANT POWER™ Jump Starter & DC Power Source

THIS PRODUCT HAS A SEALED LEAD-ACID BATTERY INSIDE THAT SHOULD BE KEPT AT FULL CHARGE FOR LONGER LIFE.

RECHARGE WHEN FIRST RECEIVED (EVEN IF GREEN ‘FULL POWER’ LED GLOWS), AFTER EACH USE AND EVERY 3 MONTHS.

IMPORTANT SAFETY INSTRUCTIONS

Save these instructions

important safety instructions

Someone should be within range of your voice or close enough to

come to your aid when you are working near a lead-acid battery.

Have plenty of fresh water and soap nearby in case battery acid

contacts skin, clothing, or eyes. If acid enter the eye area, rinse

with cold water for at least 10 minutes and get medical help

immediately.

Do not smoke, or use matches or cigarette lighter, or allow any

spark or ame near the battery or engine.

Never operate the power source unit if it has damaged lead wire

or clamps. Have the lead wire replaced by a qualied technician.

Wear complete eye and clothing protection when working with

lead-acid batteries.

Do not permit the internal battery in the IP-1825FL to freeze. Never

attempt to recharge a frozen battery.

handling warning

WARNING: Handling the cord on this product or cords associated

with this product, may expose you to lead, a chemical known to

the State of California to cause cancer and birth defects or other

reproductive harm. Wash hands after handling.

operating instructions

Warning: Failure to follow instructions may cause

damage or an explosion. Read entire instruction

manual before use.

1. Turn ignition OFF before making cable connections.

2. Use in a well-ventilated area.

3. Keep clear of fan blades, belts, pulleys and other parts that

may cause injury.

4. NEVER allow clamps to touch together or to contact the same

piece of metal to prevent sparking.

5. Clamp the red clamp (+) to the positive terminal (+) of the

battery. (For a negative grounded system.)*

6. Clamp the black clamp (-) to an unpainted and unmoving part

of the chassis or engine block.

7. You can now crank the engine. If the engine does not start

within 3-8 seconds, wait at least 1 minute before attempting to

start vehicle again. (This permits the battery to cool down.)

8. After the engine starts, rst disconnect the black clamp (-) and

then the red clamp (+) in that order. Store the clamps on the

ears located on the sides of the case.

9. Recharge the IP-1825FL as soon as possible after use.

*NOTE: In the rare case of jump-starting a vehicle that has

a positive-grounded vehicle electrical system, connect the

NEGATIVE black clamp (-) to the negative terminal (-) of the

vehicle battery. Then connect the POSITIVE red clamp (+)

to an unpainted and unmoving part of the vehicle chassis or

engine block. If you are unsure of the nature of the vehicle’s

electrical grounding system, check the owner’s manual of the

vehicle. To disconnect clamps, reverse order.

led indicators

To check the internal battery’s charge status, press the red button

on the front of IP-1825FL.

The LED lights will indicate the charge level as follows:

1. A red LED indicates a 50% or less charge and you should

immediately recharge IP-1825FL.

2. A yellow LED indicates a 50 to 75% charge. IP-1825FL may

be used but should be recharged as soon as possible.

3. A green LED indicates the internal battery is fully charged.

charging of internal battery with built-in charger.

After removing the IP-1825FL from the carton, charge it for a

minimum of 8 hours even if the green Full Power LED glows.

1. To charge, plug extension cord into charger plug on the side

of the IP-1825FL. (Extension cord not included; must be

purchased separately.)

2. Plug the extension cord into 110V AC electrical wall outlet.

3. The red LED will glow while charging.

4. The green LED will glow when the battery has reached full

charge. This could take up to 72 hours on some charges due to

age and condition of the battery. The charger will automatically

drop into a oat mode and maintain the battery at full charge

without damaging the battery. The IP-1825FL can be left

plugged into the 110V wall outlet indenitely to maintain full

power.

5. Recharge IP-1825FL after use and every 3 months to full

charge status to extend the battery’s life.

multi-purpose power supply

The IP-1825FL is a power source for all 12 volt DC accessories that

are equipped with a 12V accessory plug. Make sure the device to

be powered is OFF before inserting 12 volt accessory plug into 12

volt accessory outlet on the IP-1825FL. Use the 12 volt accessory

outlet for power outages, shing and camping trips. Estimate usage

time is listed in chart below.

12 Volt dc power source chart

Appliance Type Estimated Wattage Estimated Time*

Cell Phones 4 Watts 30 Hours

Fluorescent Lights 4 Watts 30 Hours

Radios 9 Watts 21 Hours

Depth Finders 9 Watts 21 Hours

Fans 9 Watts 21 Hours

00-99-000673/1106

Camcorders, VCRs 15 Watts 12 Hours

Electrical Tools 24 Watts 7 Hours

Electrical Coolers 48 Watts 3 Hours

Car Vacuum,

Air Compressors 80 Watts 1.5 Hours

The DC socket has a 15 amp automatic overload protection circuit

breaker. Reset the breaker by pushing the breaker button located

on the back of IP-1825FL.

110 Volt ac power source chart

(Inverter {Not Included} is Necessary)

Appliance Type Estimated Wattage Estimated Time*

Spot Lights,

Sump Pumps 100 Watts 1.5 Hours

VCRs 100 Watts 1.5 Hours

Faxes, TVs 150 Watts 1 Hour

Small Power Tools 150 Watts 1 Hour

When the IP-1825FL is used with an inverter, it can operate

appliances normally powered by 110V AC. (Inverter not included;

must be purchased separately.)

*NOTE: Estimated time is conservatively reported. Actual time

may vary. Times are based on IP-1825FL having a full charge.

Requires the use of an inverter that is not included. Designed for

up to a 125 watt inverter.

flex-light

To use the ex-light, insert the light’s plug into the 12V accessory

outlet. The ON/OFF control is on the back of the light.

light replacement

The bulb used in the IP-1825FL light is a 12 volt, 5 watt halogen

bayonet type. Since the bulb needing replacement is not working

and the switch may be in the ON position, the lamp circuit could

be “live”. Use caution while changing the bulb.

To replace the bulb, unscrew the cover on the lamp back, remove the

old bulb, then replace with a new 12 volt, 5 watt halogen bulb.

Finally screw the cover onto the lamp housing.

storage

The IP-1825FL can be stored in any position. The clamps are live

and will produce arcing or sparking if they come in contact with

each other. To prevent accidental arcing, always keep the clamps

on the side ears when not using it to jump start a vehicle.

All batteries are affected by temperature. The ideal storage

temperature is at 70 degrees Fahrenheit. Performance varies based

on battery temperature conditions.

limited warranty

Schumacher Electric Corporation warrants your unit to be free from defects in material and workmanship, excepting abuse or misuse, for a period of

one year from the date of sale to the original user or consumer purchaser. If your unit fails or malfunctions within the rst 30 days of the warranty, we

will replace it with a new unit. If your unit malfunctions or fails within the 12 month warranty period because of a defect in material or workmanship, we

will repair without charge.

The internal battery, excluding units with swollen batteries or melted battery terminals, carries a 90-day warranty from the date of purchase. Proof of

purchase required. All battery replacements will be at the sole discretion of the manufacturer or his designated agents.

This warranty is in lieu of all other express warranties. The duration of any implied warranty, including but not limited to any implied warranty of merchantability

or tness for a particular purpose, made in respect to your unit is limited to the period of the express warranty set forth above.

For warranty service, return your product, with proof of purchase, to the factory or a designated agent: Schumacher Electric Corporation Warranty Service

Department, 1025 E. Thompson Street, PO Box 280, Hoopeston, IL 60942. Phone 1-800-621-5485, Customer Service hours: 7 AM to 4:30 PM CST.

You will be responsible for all insurance and freight or other transportation charges to the factory or point of repair. We will return your unit freight

prepaid if repair is covered under warranty. Your unit should be properly packed to avoid damage in transit, since we will not be responsible for any such

damage.

In no event shall Schumacher Electric Corporation be liable for consequential or incidental damages. Some states do not allow limitations on the length

of the implied warranty or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
