DO4A

Rugged, portable digital ohmmeter digital with

calibration and 4,000 count

The DO4A is a practical instrument for low resistance measurement, ideal for

use in the workshop, field or test facilities.

It is of rugged construction contained in an aluminium case with tilt handle.

The DO4A has many advanced features, digital calibration and long scale

length (4,000 count).

The rechargeable sealed lead acid battery means real portability with

more than 14 hours continuous operation. Full measurement capability is

maintained while charging. For ease of operation the control functions have

been kept to a minimum and are clearly marked.

It is of course direct reading, warning LEDs illuminate when an open circuit

lead condition is detected. Over range and low battery indication is also

provided. The DO4A is supplied ready for immediate use with battery, mains

cord and measuring leads, no extras are normally necessary.

The 15mm LCD provides easy viewing and the instrument can be used in

any position for many and varied applications. The test leads provided have a

length of 1m with spade tags for connection to the ohmmeter terminals.

They are terminated in combined current and potential probes that will

accept conductor diameters up to 6mm.

www.seaward.co.uk/DO4A

For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775

For all other enquiries Tel: +44 (0) 191 587 8741

Email: sales@seaward.co.uk

Key Features

True 4 wire measurement eliminates

lead resistance errors

6 push button ranges 40mΩ Ω - 4k

with long scale length

10μ resolution on 40m rangeΩ Ω

Zero control thermal E.M.F.

compensation

Digital calibration

Mains/rechargeable battery

operation

Open circuit lead warning

Rugged industrial maintenance free

design

Universal mains supply 100/200/

220/240V +10% - 13%

Ideal For

Aerospace

Drivers and electrical machines

Military

Manufacturing

Utilities, electrical, water and gas

DO74A Plus Optional Accessories

Code Item Part Number

C02 1m cable clamp with metal base for the precise measurement of 1m cable samples 0.1–100mm2930150

C02A 1m cable clamp with metal base for the precise measurement of 1m cable samples 1–1000mm2930214

C03 1m cable clamp with water bath for the precise measurement of 1m cable samples 1–1000mm2930419

HS01 Duplex handspikes with 3m lead length 190082

HS02 Duplex handspikes with 3 and 15 m lead length 190055

LS03 Lead set with 2 x 3m leads terminated in large Kelvin clips type KC3 190042

LS04 Lead set with 3 and 15m lead length terminated in large Kelvin clips type KC3 190046

LS05 Lead set with 4 x 1m leads terminated in banana plugs, 4 x crocodile clips, 4 x test probes and 2

x Kelvin clips type KC1 190004

LS06 Lead set with 1m leads terminated in miniature Kelvin clips type KC2 190007

MTS2 Calibration standard 930241

www.seaward.co.uk/DO4A

For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775

For all other enquiries Tel: +44 (0) 191 587 8741

Email: sales@seaward.co.uk

Technical Speciﬁcations

General Speciﬁcations

Dimensions

15 x 250 x 88mm / 0.5 x 9.8 x 3.5” (w x d x h) approx

1/2 19” rack 2U high

467 x 374 x 216mm / 18 x 15 x 8.5” (w x d x h) packed in carton

Mass

3.5kg / 8lbs approx. 4.5kg / 10lbs packed in carton

Working Temperature

0 to +40°C re. humidity 80% max. non-condensing

Storage Temperature

-20 to +50°C

Services

1 year warranty (subject to product registration with Seaward. Visit

www.seaward.co.uk/register-product)

Service and calibration by Calibrationhouse.

Go to www.calibrationhouse.com for more information.

Part Number

930127

Range Resolution Typical Current Accuracy @ 20°C±5°C 1 year Temperature Coefﬁcient (°C)

4k 1 100μA ±(0.05% Rdg +0.02% FS) 30ppm Rdg + 1ppm FSΩ Ω

400 100 1mA ±(0.05% Rdg +0.02% FS) 30ppm Rdg + 1ppm FSΩ Ω

40 10 10mA ±(0.05% Rdg +0.02% FS) 30ppm Rdg + 1ppm FSΩ Ω

4 1m 10mA ± (0.05% Rdg +0.03% FS) 30ppm Rdg + 4ppm FSΩ Ω

400m 100μ 10mA ± (0.05% Rdg +0.05% FS) 30ppm Rdg + 25ppm FSΩ Ω

40m 10μ 100mA ± (0.05% Rdg +0.05% FS) 30ppm Rdg + 25ppm FSΩ Ω

Measurement

4 terminal Kelvin/Thomson principle eliminates errors due

to lead resistance

Display

15mm LCD 4000 count with automatic decimal point

and polarity indication

Ranges

6 push button selected with LED indication

Terminals

4mm binding posts accept spade tags and 4mm banana plugs

Mains Supply

100/120/220/240V +10% to 13%

47 - 63Hz 20VA

Safety

EN 61010-1 EMC 61326

Calibration

Digital security key protected

Auto Zero

Permits the automatic zero of amplifiers and external circuits,

eliminating errors due to thermal E.M.F.

Battery

6V 2.8Ah sealed lead acid battery with built-in charger. 14 hour

typical operating time on lowest range, 28 hours typical on other

ranges. Internal charger and automatic switch off.

Rev 3
