DO7010

Rugged portable micro ohmmeter for low

resistance measurement

The DO7010 is a very rugged and very compact, portable digital ohmmeter

for the measurement of low resistance. Using rechargeable and replaceable

NiMh batteries with external charger, the DO7010 is capable of measuring

with a current of 1 and 10A on all except the highest range.

The DO7010 has been designed with the latest solid state and

microprocessor techniques to ensure the very best in measurement reliability

and features. The LCD graphic display panel gives full information regarding

the measurement conﬁguration, and a single measurement start button

ensures that the operation is simple and easy to use.

The measurement may be triggered when the measurement leads are

applied to the device under test, ensuring fast single-person operation.

The data-logging function also permits up to 1,000 date and time stamped

readings to be stored.

www.seaward.co.uk/DO7010

For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775

For all other enquiries Tel: +44 (0) 191 587 8741

Email: sales@seaward.co.uk

Key Features

True 4 wire measurement eliminates

lead resistance errors

4 ranges 6mΩ Ω to 6

Resolution 1µ on 6m rangeΩ Ω

Graphics Display with backlight

3 languages (English, French,

German)

1 and 10A measuring current

even on the 600mΩ range

Forward and reverse current

measurement

Auto average of forward and

reverse measurement

True zero offset

Built in test resistor for conﬁdence

check

Data logging with up to 1000 readings

stored with date and time stamp

Hi-Lo limits with audible and visual

warning

Automatic measurement trigger

when leads are connected to DUT

Small size and light weight <4Kg

RS232 interface with option remote

terminal to enable operation up to

15m distance

Rechargeable NiMh batteries with

charge indicator and easily

replaceable battery pack

Ideal For

Aerospace

Automotive

Military

Manufacturing

Utilities, electrical, water and gas

DO74A Plus Optional Accessories

Part Number Item Part Number

DO7010-BP Additional battery pack 100123

HS01-7010 Duplex handspikes with 3m lead length 190052

HS02-7010 Duplex handspikes with 3 and 15m lead length 190056

LS03-7010 Lead set with 3m leads and terminated with large Kelvin clips type KC3 190043

LS04-7010 Lead set with 3 and 15m lead length terminated in large Kelvin clips type KC3 190047

MTS3 Calibration Standard 930242

RSL04 RS232 interface cable 1m 920069

Technical Speciﬁcations

General Speciﬁcations

Dimensions

390 x 160 x 270mm / 15 x 6.3 x 11” (w x h x d) approx

Mass

4kg / 9lbs approx

Services

1 year warranty (subject to product registration with Seaward. Visit

www.seaward.co.uk/register-product)

Service and calibration by Calibrationhouse.

Go to www.calibrationhouse.com for more information.

Part Number

930217

Range Resolution Typical Current FSV Accuracy at 20°C±5°C 1 year

6 1m 100mA/1A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω

600m 100µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω

60m 10µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω

6m 1µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω

Measurement

4 Terminal Kelvin/Thomson principle eliminates errors due to

lead resistance.

Open circuit measurement voltage = 5VDC

Display

240 x 64 dot graphics LCD with backlight

Ranges

4 ranges with auto range mode. Two selectable measuring

currents for each range

Terminals

The measurement leads are connected via Jaeger connectors

and a full range of lead conﬁgurations are available

Working Temperature

0 to +50°C rel. humidity up to 80% non condensing

Storage Temperature

-20 to +50°C

Safety

Conforms to EN 61010-1, Main instrument Class III (SELV),

Battery pack Class III (SELV) and external mains charger Class II

Battery

The DO7010 is supplied with battery ﬁtted. The batteries are

NiMh and the charger is external. The battery pack may be

removed from the front panel when discharged and a

replacement charged pack inserted. This ensures minimum

down-time when making measurements

Lead Sets

We offer a wide variety of lead sets with 3 sizes of Kelvin clip or

handspikes. Lead lengths may be up to 100m total loop

Data Logging

The DO7010 has data logging modes. The ﬁrst will store each

reading with record number date and time. The second is a

sequence mode which will store values with operator ID, serial

number etc

Rev 2

www.seaward.co.uk/DO7010

For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775

For all other enquiries Tel: +44 (0) 191 587 8741

Email: sales@seaward.co.uk
