Side 1/8

Table of Contents:

Introduction. ............................................. 1

Overview ...................................................2

Precautions ...............................................2

Setting Up ................................................ 3

Preparing the ceiling ............................ 3

Drop Ceilings .................................... 3

Fixed Ceilings ................................... 3

Connecting the wiring to the

removable locking connector............3

Wiring Schemes ..................................... 4

Attaching and securing the

wiring to the speaker............................4

Installing the speaker into

the ceiling..................................................5

Adjust the Multi-Tap Selector.............5

Attaching the Grille .............................. 5

Painting ..................................................... 5

Preparing.............................................5

Painting the rim................................5

Painting the grille.............................5

Speciﬁcations ......................................... 6

Frequency Response ........................... 6

Troubleshooting ......................................7

Three-Year Limited Warranty.............7

CSP-SERIES

Thank you for choosing Senal.

The CSP-series speakers are passive coaxial two-way speakers that provide premium sound

quality for use with 70V or 100V systems and for low-ohm systems.

These high power - low distortion speakers feature wide coverage that evenly distributes high

ﬁdelity audio to ﬁll large and small spaces. All models are ideal for broadcasting announcements

and music reproduction in commercial and residential applications.

The CSP-series ceiling speakers have a multi-tap transformer, which allows ﬂexibility in

conﬁguring multiple speakers of a high-impedance system. It is easily accessed with the multi-

tap selector on the front bafﬂe of the speaker. Low frequencies are enhanced with a vented

port, and precise and smooth high frequencies are delivered by the coaxially mounted 3/4 "

titanium-coated tweeter. The sealed backcan enhances overall ﬁdelity by focusing the sound

and preventing the distribution of sound into the surrounding ceiling structure.

Removable locking connectors simplify the process of wiring the speakers. Each speaker comes

with the mounting brackets and hardware necessary for installation. The attachment screw

system makes installation simple while providing a secure mounting connection to most ceiling

types. Secondary support tabs ensure extra security for compliance with building codes. The

speakers can be painted to match ceiling décor.

CSP-162

The CSP-162 is a powerful 150-watt, low-distortion ceiling speaker with a built-in multi-tap

transformer with maximum power of 60W. It features a 6.5-inch woofer and 3/4 titanium-"

coated tweeter.

CSP-142

The CSP 142 is a compact 80-watt ceiling speaker with a built-in multi-tap transformer with

a maximum power of 30W. It features a 4-inch woofer and 3/4 titanium-coated tweeter. "

Low clearance of 6.25 (15.9 cm) makes it possible to install this speaker into smaller ceiling "

spaces.

USER’S GUIDE
