Side 1/6

Safety instructions

– The washing machine is heavy - take care when lifting.

– Caution: frozen hoses may rip/burst. Do not install the washing machine in areas exposed

to frost or outdoors.

– The washing machine could be damaged. Do not lift the appliance by protruding

components (e.g. the washing machine door).

– In addition to the instructions provided in this document, special regulations from the

relevant water and electric utility companies may apply.

– If in doubt, have a technician connect the appliance.

– Lay hoses and cables in such a way that there is no risk of tripping.

Installation surface

– The machine must be stable so that it does not move around.

– The installation surface must be firm and level.

– Soft floors/floor coverings are not suitable.

Installation on a pedestal

– The feet of the washing machine be secured with holding brackets*.must

* order no. WMZ2200, WX9756, CZ110600, Z7080X0

Installation on a wood joist floor

– If possible, place the washing machine in a corner.

– Screw a water-resistant wooden board (min. 30 mm thick) to the floor.

– The feet of the washing machine be secured with holding brackets*.must

* order no. see above

Installing the appliance

Install the appliance before connecting it to the power supply.

Installation in a kitchenette (underneath the worktop or fitted in a cabinet)

– Recess width of 60 cm required.

– Only install the washing machine underneath a continuous worktop that is securely

connected to adjacent cabinets.

Installation underneath the worktop

Risk of electric shock.

– Instead of the appliance covering plate, you must have a metal cover * fitted by an expert.

* order no. WMZ2420, WZ10190

– Recess width of 60 cm required.

Scope of delivery depending on model

Also required, depending on the connection:

– 1 hose clamp Ø 24-40 mm (exclusive dealers) to connect to a siphon

a page 4; water connection.

Useful tools

– Spirit level for installation.

Hose and cable lengths depending on model

Left-hand connection or Right-hand connection

Available from specialist dealers/the after-sales service:

– Extension for Aqua-Stop or cold-water inlet hose (approx. 2.50 m).

order no. WMZ2380, WZ10130, CZ11350, Z7070X0

– Longer inlet hose (approx. 2.20 m) for standard model.

Mains cable

Water outlet

Water inlet

Elbow

for fixing the drainage

hose in place

Covers

quaä

ecure

Wrench

(depending on model)

~145 cm

~100 cm

~90 cm

~140 cm

~145 cm

min. 60 cm

~90 cm

max. 100 cm

Moisture inside the drum is

due to final testing.

Removing the transport braces

– Before using the appliance for the first time, make sure that you

completely remove transport braces and keep them for subsequent

transportation.

– If you need to transport the appliance at a later date, always re-affix the

transport braces to prevent damage to the machine page 6.a

– Store the screw and sleeve screwed together.

1. Take the hoses and elbow out of the holders, depending on model.

2. Loosen the bolts ....

... until they move freely in the sleeves.

3. Completely remove all 4 transportation protection devices (each bolt

together with sleeve) and take the main cable out of the holder.

Always displace bolt and sleeve together as shown in the illustration.

All bolts and sleeves must be removed.

4. Insert covers.

Water connection depending on model

– Do not immerse the Aqua-Stop safety device in water Risk of electric shock.

(contains an electric valve).

– To prevent leaks or water damage, observe the instructions in this

section.

– : only operate the washing machine using cold drinking water.Caution

– Do not connect to the mixer tap of an unpressurised hot-water boiler.

– Do not use a used inlet hose. Only use the inlet hose supplied or one which was

purchased from an authorised specialist dealer.

– If in doubt, have a technician connect the appliance.

Water inlet

Water inlet hose:

Caution: do not bend, squash, modify or cut through

(otherwise its strength is no longer guaranteed).

Optimum water pressure in the supply network: 100 1,000 kPa (1 10 bar)ä ä

– When the tap is on, the water flow is at least 8 l/min.

– If the water pressure is higher than this, a pressure reducing valve must be installed.

Model: Aqua Stopä

Aqua Secureä

Standard

1. Connect the water inlet hose to the tap.

Caution: only tighten the screw connections by

hand.

2. Open the water tap carefully, checking the leak

tightness of the connection points.

Caution:the screw connection is under mains water

pressure.

Water outlet

Water outlet hose:

Caution: do not bend or pull lengthways.

Height difference between the installation surface and the drain:

min. 60 cm - max. 100 cm

Outlet in a sink

Caution: secure the drain hose from slipping out.

Caution: the plug must not block drainage from the sink. During

pumping, check whether the water is draining away quickly enough.

The end of the drain hose must not be immersed in the water pumped

out. This risks water being sucked back into the washing machine.

Drainage into a siphon:

Caution: the connection point must be secured with a hose clamp,

Ø 24-40 mm (exclusive dealers).

max.

90°

max.

90°

min.

10 mm

min.

10 mm

3/4”

Produkt Specifikationer

Mærke:	Siemens
Kategori:	Vaskemaskine
Model:	WM12E221EP
Bredde:	600 mm
Dybde:	590 mm
Højde:	848 mm
Vægt:	81000 g
Produktfarve:	Hvid
Skærmtype:	LED
Energieffektivitetsklasse (gammel):	A++
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	7 kg
Maksimal centrifugeringshastighed:	1200 rpm
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy, Black
Børnesikring:	Ja
Energiforbrug ved vask:	1.05 kWh
Balance system:	Ja
Spin-tørre klasse:	B
Cyklustid (maks.):	188 min.
Skum kontrol system:	Ja
Vaskeklasse:	A
Vandforbrug pr. cyklus:	47 L
Forsinket start (maks.):	24 t
AquaStop funktion:	Ja
Indikator for resterende tid:	Ja
Effektkrav:	50Hz, 10A, 220-240V
Rense plus funktion:	Ingen
Justerbar centrifugeringshastighed:	Ja
