Full-Motion TV Mount - 47" to 90"

Installation Guide

04-0923A

Important: If you have difficulty following or understanding these installation instructions,

please consult a qualified installation specialist.

Full-motion Articulating LCD/Plasma TV Wall-mount

TV size: 47" - 90"

Tilt angle: +/- 12 degrees

Max load capacity: 200 lbs / 90 kg

Wall distance (at the front plate): 3.9" to 19.7"

Caution

• Prior to installation of this product, the installation guide should be read and completely

understood. The installation guide must be read to prevent personal injury and property

damage. Keep the installation guide in an easily accessible location for future reference.

• This mount contains small parts which can act as a choking hazard if swallowed.

• CAUTION: The maximum load capacity is 200 lbs. Use with products exceeding the

maximum load capacity may cause serious injury. See apparatus instructions.

• The wall structure must be capable of supporting at least five (5) times the maximum load

capacity as indicated. If not, the wall must be reinforced.

• Recommended mounting surfaces: wood stud and solid-flat concrete. If the mount is to

be installed on any surface other than wood studs or solid concrete, use suitable

hardware (not included but commercially available).

• Do not install on a structure that is prone to vibration, movement or chance of impact.

Failure to do so could result in damage to the display and/or damage to the mounting

surface.

• Do not install near heater, fireplace, air conditioning, in direct sunlight or any other heat

producing source. Failure to do so may result in damage to the display and could

increase the risk of fire.

• Make sure no water or natural gas lines are present where the mount is to be installed.

Cutting or drilling into water or natural gas lines could cause personal injury or property

damage.

• Proper installation procedure by yourself or a qualified service technician, as outlined

in the installation guide, must be adhered to. Failure to do so could result in serious

personal injury.

• When mounting to a wall that contains wood studs, confirm the dead center of the wood

stud prior to installation, it is recommended that the wood studs be a minimum of 16"

apart (if applicable).

• This product is intended for indoor installation/use only. Premature product failure or

serious personal injury could occur if this product is used outdoors.

• It is recommended that two people perform the installation. Injury and/or damage can

result from dropping or mishandling the display.

Tools Required

• Electronic stud finder for drywall installation

• Phillips head screwdriver and bubble level

• Socket or wrench set (metric)

• Electric drill, 5/32" drill bit for wood stud installation, 3/8" masonry drill bit for

concrete/brick wall installation

Important: The Full-Motion TV Mount - 47" to 90" is shipped with the proper installation

hardware and parts. Make sure that none of the items are missing or damaged before

starting the installation. If there are any missing and/or damaged parts, please stop the

installation and contact your place of purchase.

Produkt Specifikationer

Mærke:	SIIG
Kategori:	Ikke kategoriseret
Model:	CE-MT1A12-S1
Bredde:	869.9 mm
Dybde:	500.3 mm
Højde:	400 mm
Vægt:	11600 g
Produktfarve:	Sort
Panel montering grænseflade:	200 x 100,200 x 200,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,800 x 400 mm
Husmateriale:	Stål
Monteringstype:	Væg
Bæredygtighedscertifikater:	RoHS
Drejevinkel område:	-40 - 40 °
Hældningsvinkelområde:	-12 - 12 °
Maksimal vægtkapacitet:	90 kg
Maksimal skærmstørrelse kompatibilitet:	90 "
Antal understøttede skærme:	1
Minimal skærmstørrelse kompatibilitet:	47 "
Montering interface kompatibilitet (min.):	200 x 100 mm
Montering interface kompatibilitet (maks.):	800 x 400 mm
