Side 1/15

Contents

qualified technicia

Further information about the products can be found at www.smeg.com

Instructions for proper use

1. INSTRUCTIONS FOR PROPER USE

ELECTRICAL CONNECTION: PLEASE REFER TO INSTALLATION INSTRUCTION FOR THE GAS

& ELECTRICAL SAFETY REGULATIONS AND THE VENTILATION REQUIREMENTS.

IN YOUR OWN INTEREST, AND THAT OF SAFETY, IT IS THE LAW THAT ALL GAS AND

ELCTRICAL APPLIANCES BE INSTALLED AND SERVICE BY COMPETENT PERSONS, WHO

WILL COMPLY WITH THE RELEVANT STANDARDS AND REGULATIONS.

CORGI REGISTERED INSTALLERS UNDERTAKE TO WORK TO SATISFCTIORY STANDARDS.

DISCONNECTION OF GAS AND ELECTRIC APPLIANCES SHOULD ALWAYS BE CARRIED OUT

BY COMPETENT PERSON.

THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT

IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE

COOKING HOB. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN

BEFORE USING THE COOKING HOB. INSTALLATION MUST BE CARRIED OUT BY QUALIFIED

PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS

INTENDED FOR DOMESTIC USES AND CONFORMS TO CURRENT REGULATIONS IN FORCE.

THE APPLIANCE HAS BEEN BUILT TO CARRY OUT THE FOLLOWING FUNCTIONS: COOKING

AND HEATING-UP OF FOOD. ALL OTHER USES ARE CONSIDERED IMPROPER.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR IMPROPER USE.

NEVER USE THIS APPLIANCE FOR HEATING ROOMS.

DO NOT LEAVE THE PACKING IN THE HOME ENVIRONMENT. SEPARATE THE VARIOUS

WASTE MATERIALS AND TAKE THEM TO THE NEAREST SPECIAL GARBAGE COLLECTION

CENTRE.

THIS APPLIANCE IS MARKED ACCORDING TO THE EUROPEAN DIRECTIVE 2002/96/EC ON

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).

THIS GUIDELINE IS THE VALIDITY OF RETURN AND FRAME OF A EUROPEAN-WIDE

RECYCLING ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT.

THE IDENTIFICATION PLATE, WITH TECHNICAL DATA, SERIAL NUMBER AND MARKING IS

CLEARLY VISIBLE UNDER THE CASING.

THE PLATE ON THE CASING MUST NOT BE REMOVED.

TAKE CARE NOT TO SPILL SUGAR OR SWEET MIXTURES ON TO THE

COOKING HOB WHEN HOT. NEVER PLACE MATERIALS OR SUBSTANCES

WHICH MAY MELT (PLASTIC OR ALUMINIUM FOIL) ON TO THE COOKING

HOB. IN THE EVENT, PROMPTLY SWITCH OFF AND REMOVE THE MOLTEN

MATERIAL WITH THE SCRAPER PROVIDED WHILE THE TOP IS STILL WARM

TO PREVENT IT FROM BEING DAMAGED. FAILURE TO INSTANTLY CLEAN

THE GLAZED CERAMIC HOB COULD LEAD TO ENCRUSTATIONS WHICH ARE

IMPOSSIBLE TO REMOVE ONCE THE HOB HAS COOLED DOWN.

for damage to persons or things caused by no

observance of the above prescriptions or by interference with any part of the appliance or by

the use of non-original spares.

Produkt Specifikationer

Mærke:	Smeg
Kategori:	Kogesektioner
Model:	P775AO
Antal effektniveauer:	6
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	718 mm
Dybde:	510 mm
Højde:	- mm
Produktfarve:	Anthracit
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Strøm:	38 A
Automatisk slukning:	Ja
Timer:	Ingen
Placering af apparat:	Indbygget
Installationsrum bredde:	685 mm
Installationsrum dybde:	490 mm
Komfurtype:	Keramisk
Overfladetype:	Keramisk
Antal kogeplader / madlavningsområde:	5
Antal elektriske kogeplader:	5
Blus/kogeplade zone 1 strøm:	1200 W
Blus/kogeplade zone 2 strøm:	1800 W
Blus/kogeplade zone 1 type:	Simre
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre bagende
Blus/kogeplade zone 1 strømkilde:	Elektrisk
Blus/kogeplade zone 2 type:	Regelmæssig
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre front
Blus/kogeplade zone 2 strømkilde:	Elektrisk
Kontrolposition:	Top forside
Tilsluttet belastning (elektrisk):	8600 W
Blus/kogeplade zone 3 type:	Stor
Blus/kogeplade zone 4 type:	Stor
Blus/kogeplade zone 2 diameter:	200 mm
Blus/kogeplade zone 1 diameter:	145 mm
Blus/kogeplade zone 4 diameter:	140 \ 210 mm
Blus/kogeplade zone 4 strømkilde:	Elektrisk
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Elektrisk
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Central
Blus/kogeplade zone 4 position:	Højre bagende
Restvarmeindikator:	Ja
Højde under bordplade:	40 mm
Blus/kogeplade zone 5 position:	Højre forside
Blus/kogeplade zone 5 strømkilde:	Elektrisk
Blus/kogeplade zone 5 type:	Simre
Blus/kogeplade zone 5 diameter:	145 mm
Blus/kogeplade zone 5 strøm:	1200 W
Kogezone 5 form:	Rund
Almindelig kogeplade/kogezone, diameter:	148 mm
Simre kogeplade/kogezone, diameter:	144 mm
Simre kogeplade / madlavningsområde:	1200 W
Almindelige kogeplade / madlavningsområde:	1800 W
Stor kogeplade / madlavningsområde:	2000 W
Ekstra stor hurtig kogeplade / madlavningsområde:	2400 W
Stor kogeplade/kogezone, diameter:	148 mm
Ekstra stor højhastighed kogeplade/kogezone, diameter:	148 mm
Kogezone 3 størrelse (B x D):	170 x 265 mm
