Contents
18
1. Instructions for safe and proper use____________________ 19
2. Positioning of hob__________________________________ 20
2.1 Attachment to support structure ________________________________________20
3. Electrical connection _______________________________ 22
4. Gas connection ___________________________________ 23
4.1 Connection to LPG __________________________________________________24
4.2 Ventilation of rooms _________________________________________________24
4.3 Discharge of combustion products ______________________________________24
5. Adapting to different types of gas______________________ 25
5.1 Removing the hob___________________________________________________25
5.2 Regulation for LPG __________________________________________________26
5.3 Regulation for natural gas_____________________________________________26
5.4 Regulation of primary air______________________________________________27
5.5 Reassembling the hob _______________________________________________27
5.6 Regulation of minimum for natural gas ___________________________________27
5.7 Regulation of minimum for LPG ________________________________________28
5.8 Arrangement of burners on hob ________________________________________28
5.9 Lubrication of gas taps _______________________________________________28
6. Description of controls ______________________________ 29
6.1 Front control panel __________________________________________________29
7. Using the hob _____________________________________ 30
7.1 Burner lighting with
safety
device _______________________________________30
7.2 Practical advice for using the burners____________________________________30
7.3 Diameter of containers _______________________________________________30
8. Cleaning and maintenance___________________________ 31
8.1 Cleaning stainless steel ______________________________________________31
8.2 Cleaning of components ______________________________________________31
THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE IDENTIFICATION SYMBOLS
APPEAR ON THE COVER OF THIS MANUAL.
THIS BUILT-IN HOB IS CLASS 3.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified technician who
must carry out a suitable check of the gas system, install the appliance, set it
functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice, description of the
commands and the correct procedures for cleaning and maintenance of the appliance.
