Side 1/31

Contents

INSTRUCTIONS FOR THE USER: these contain user advice, description

of the commands and the correct procedures for cleaning and maintenance

of the appliance

INSTRUCTIONS FOR THE INSTALLER: these are intended for the

qualified technician who must install the appliance, set it functioning and

carry out an inspection test

1. INSTRUCTIONS FOR USE .................................................................. 35

2. INSTRUCTIONS FOR DISPOSAL –

OUR ENVIRONMENTAL CARE ........................................................... 36

3. SAFETY INSTRUCTIONS .................................................................... 37

4. GET TO KNOW YOUR OVEN .............................................................. 38

5. BEFORE INSTALLATION..................................................................... 38

6. DESCRIPTION OF THE CONTROLS ON THE FRONT PANEL.......... 39

7. USE OF THE OVEN ............................................................................. 42

8. AVAILABLE ACCESSORIES................................................................ 46

9. COOKING HINTS WITHOUT MICROWAVE ........................................ 47

10. COOKING HINTS FOR THE MICROWAVE ......................................... 52

11. CLEANING AND MAINTENANCE ........................................................ 59

12. EXTRAORDINARY MAINTENANCE .................................................... 61

13. SOMETHING NOT WORKING? ........................................................... 62

14. INSTALLING THE APPLIANCE......................... ......................... .......... 63

Instructions for disposal

2. INSTRUCTIONS FOR DISPOSAL –

OUR ENVIRONMENTAL CARE

Our product's packing is made of non-polluting materials, therefore

compatible with the environment and recycable. Please help by disposing

of the packing correctly. Find the addresses of collection, recycling and

disposal centres from your retailer or from the competent local

organisations.

Do not throw the packing or any part of it away. They can constitute a

suffocation hazard for children, especially the plastic bags.

Your old appliance also needs to be disposed of correctly.

Important: Hand over your appliance to the local agency authorised for

the collection of electrical appliances no longer in use. Correct disposal

means intelligent recycling of valuable materials.

Before disposing of your old appliance remove the door and leave the

racks in their normal working positions so that children cannot get stuck in

the oven compartment whilst playing. It is also necessary to cut the

electric power cord into remove it along with the plug.

Safety instructions

3. SAFETY INSTRUCTIONS

CONSULT THE INSTALLATION INSTRUCTIONS FOR THE SAFETY

STANDARDS FOR ELECTRICAL OR GAS APPLIANCES AND FOR THE

VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY IT

HAS BEEN ESTABLISHED BY LAW THAT THE INSTALLATION AND SERVICING

OF ALL ELECTRICAL APPLIANCES IS TO BE CARRIED OUT BY QUALIFIED

PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE. OUR

REGULAR INSTALLERS GUARANTEE A SATISFACTORY JOB. GAS OR

ELECTRICAL APPLIANCES MUST ALWAYS BE DISCONNECTED BY

QUALIFIED PEOPLE.

THE PLUG TO BE CONNECTED TO THE POWER CORD AND ITS SOCKET

MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN

FORCE.

THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE IS BUILT IN.

NEVER UNPLUG BY PULLING ON THE CABLE.

IT IS OBLIGATORY FOR ALL ELECTRICAL SYSTEM TO BE GROUNDED

ACCORDING TO THE METHODS REQUIRED BY SAFETY RULES.

IMMEDIATELY AFTER INSTALLATION CARRY OUT A BRIEF INSPECTION TEST,

FOLLOWING THE INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT

FUNCTION, DISCONNECT IT FROM THE SUPPLY AND CALL THE NEAREST

TECHNICAL ASSISTANCE CENTRE. NEVER ATTEMPT TO REPAIR THE

APPLIANCE.

NEVER PUT INFLAMMABLE OBJECTS IN THE OVEN: THEY COULD BE

ACCIDENTALLY LIGHTED AND CAUSE FIRES.

DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO

TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.

THE OVEN IS DESIGNED FOR USE BY ADULTS. DO NOT ALLOW CHILDREN

TO GO NEAR IT OR PLAY WITH IT. WHEN THE GRILL IS WORKING THE

ACCESSIBLE PARTS CAN BECOME VERY HOT: KEEP CHILDREN AWAY.

BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL LABELS AND

PROTECTIVE FILMS APPLIED INSIDE OR OUTSIDE MUST BE REMOVED.

ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE 0 (OFF) POSITION

WHEN YOU FINISH USING THE OVEN.

The manufacturer declines all responsibility for damage to persons or

things caused by non-observance of the above prescriptions or by

interference with any part of the appliance or by the use of non-original

spares.

Instructions for the user

4. GET TO KNOW YOUR OVEN

5. BEFORE INSTALLATION

CONTROL PANEL

OVEN LIGHT

OVEN FAN (ONLY ON SOME

MODELS)

SUPPORTS FOR PLATES

AND RACKS

Do not discard packing in the home environment. Separate the various

waste materials and take them to the nearest special garbage collection

centre.

In order to remove all manufacturing residues, is recommended to clean

the inside of the appliance. For further information on cleaning see

chapter"11. CLEANING AND MAINTENANCE" .

Before using the oven and the grill for the first time, pre-heat them to

maximum temperature long enough to burn any manufacturing oily

residues which could give the food a bad taste.

Instructions for the user

6. DESCRIPTION OF THE CONTROLS ON THE

FRONT PANEL

All the oven controls are grouped together on the front panel. The symbols

used are described in the table below.

THERMOSTAT SWITCH

Cooking temperature is selected by turning the

switch clockwise to the desired setting, between

50° and 250°C.

When this light comes on, the oven is heating up.

When this light goes out, the preset heating

temperature has been reached. When the light

flashes, the temperature inside the oven is

steady.

TIMER KNOB

Allows manual cooking or minute counter to be

selected; the oven switches off automatically at

the end of cooking. If no selection of a cooking

time is made, the timer knob must be positioned

on the symbol turning it anticlockwise.

To set the cooking time, turn the knob clockwise until the “60” position and

then set the desired cooking time. The numbers from 1 to 60 correspond

to minutes. Adjustment is progressive and intermediate positions between

the indicated figures can be used.

The manual function only works on the traditional functions

(serigraphed in black on the front panel), while for microwave and

combined functions (serigraphed in orange) a cooking time has to be set

The audible signal at the end of the preset time switches off the oven

whatever function has been set.

Instructions for the user

FUNCTION SWITCH KNOB

Rotate the knob in either direction to select a

desired function from the following:

The combined or microwave only functions are selected positioning the

knob on the orange-coloured symbols.

TRADITIONAL FUNCTIONS

(IN BLACK)

COMBINED FUNCTIONS

(IN ORANGE)

NO FUNCTION SET UPPER + LOWER HEATING

ELEMENT

UPPER + LOWER HEATING

ELEMENT

FULL GRILL ELEMENT +

VENTILATION

GRILL ELEMENT UPPER + LOWER HEATING

ELEMENT + VENTILATION

FULL GRILL ELEMENT +

VENTILATION

MICROWAVE FUNCTION

VENTILATED HEATING ELEMENT

MICROWAVE POWER REGULATION KNOB

This knob selects the power settings, in %, for

the microwave oven according to the product in

the oven.

For proper use of the power settings, please refer

to the heading "7.3 Microwave cooking".

Instructions for the user

LUMINOUS FUNCTIONS PANEL

This panel shows the functions selected with the

function switch knob.

THERMOSTAT INDICATOR LIGHT

(YELLOW) light comes on when the

oven is heating up.

FAN ELEMENT INDICATOR LIGHT

(GREEN)

OVEN ON INDICATOR LIGHT

(RED): light comes on when a

function is selected

MICROWAVE ON INDICATOR

LIGHT (RED): steady ON when the

appliance is set in advance for the

microwave functions and flashing

when these are activated

UPPER AND LOWER HEATING

ELEMENT INDICATOR LIGHT

(GREEN)

MICROWAVE START BUTTON:

serves for starting the cooking with

the microwave function; the

microwaves are not activated if a

power setting (with the MICROWAVE

POWER REGULATION KNOB), a

function (with the FUNCTION

SWITCH KNOB) and a cooking time

(with the TIMER KNOB) is not set

beforehand

GRILL INDICATOR LIGHT (GREEN)

FAN INDICATOR LIGHT (GREEN)

The microwaves do not function if the TIMER KNOB is positioned on the

symbol.

Instructions for the user

7. USE OF THE OVEN

Before using the oven, make sure you have selected either a cooking time

or manual functioning .

7.1 Warnings and general advice

Before using the oven for the first time, pre-heat it to maximum

temperature long enough to burn any manufacturing oily residues which

could give the food a bad taste. Do not use the microwave or combined

functions for this first preheating.

During cooking, do not cover the bottom of the oven with aluminium or tin

foil and do not place pans or oven trays on it as this may damage the

enamel coating. If you wish to use greaseproof paper, place it so that it will

not interfere with the hot air circulation inside the oven.

The oven accessories intended to come into contact with food are made of

materials that comply with the provisions of Directive 89/109/EEC, dated

21/12/88 and of Decree Law 108, dated 25/01/92.

To prevent any steam in the oven creating

problems, open the door in two stages: half open (5

cm approx.) for 4-5 seconds and then fully open. To

access food, always leave the door open as short a

time as possible to prevent the temperature in the

oven from falling and ruining the food. When the

door is opened oven ventilation is automatically

switched off; it then resumes as soon as the door is

closed.

Instructions for the user

7.2 Cooling system

The oven is equipped with a cooling system which automatically comes on

when the oven is being turned on. Fans cause a steady outflow of air from

above the door which may continue for a brief period of time even after the

oven has been turned off.

7.3 Microwave cooking

Microwave cooking is possible at different power levels that can be

selected with the MICORWAVE POWER REGULATION KNOB. Below is

a list of the most suitable operations for each power level selected.

MIN-20%: softening dairy products and cream spreads, keeping foods hot;

30-50%: thawing foods, cooking sauces, cooking tender meat in

combination with the normal functions;

60-80%: cooking pasta or rice, cooking chicken, vegetables or large fish in

combination with the normal functions;

90-100%: heating up pre-cooked meals, cooking fresh and frozen

vegetables, combined with the normal functions for cooking turkey and

fatty chicken, cooking cakes and desserts;

To activate the microwave you must set a cooking time, select a power

setting, select a function (among those serigraphed in orange on the

control panel) and press the key on the control panel.

Instructions for the user

7.3.2 Kitchenware

Not all kitchenware is suitable for use with microwave cooking.

Do not use the following, for example:

1 closed containers, closed bottles, tins: high pressure can build up inside

them which could cause them to explode;

2 closed metal containers;

3 metal cutlery;

4 lead crystal;

5 crockery with knurled edges;

6 non heat-resistant plastics;

7 silver-plated paper or tin foil;

8 kitchenware with metal parts from which the covering has not been

completely removed;

9 plastic kitchenware which can fuse at high temperatures;

10 porcelain kitchenware with handles or knobs in which dampness might

collect, which could create high pressure and cause these items to

break;

11 in the case of foods being cooked in "throwaway" paper containers,

check the oven frequently for the possible presence of flames.

Instructions for the user

8. AVAILABLE ACCESSORIES

The oven features 4 support positions for

plates and racks of different height.

Grill: useful for holding cooking containers.

Pastry plate: for baking cakes, pizza and

oven desserts.

Accessories available on request

Original accessories may be ordered from any Authorised Service Centre.

Instructions for the user

9. COOKING HINTS WITHOUT MICROWAVE

In fan-assisted mode preheating should be carried out at 30/40°C above

the cooking temperature. This considerably shortens cooking times and

reduces power consumption, as well as giving better cooking results.

Keep the oven door closed during cooking.

9.1 Traditional cooking

FUNCTION SWITCH

THERMOSTAT 50 ÷ 250 °C

This traditional cooking method, in which heat comes from above and

below, is suitable for cooking food on a single level. You have to pre-heat

the oven until the set temperature is reached. Place the food in the oven

only after the thermostat indicator light has turned off. Put frozen meat in

immediately, without waiting for it to thaw. The only precaution you need to

take is to set the temperature about 20°C lower and cooking time about 1/

4 longer than you would for fresh meat.

9.2 Hot-air cooking

FUNCTION SWITCH

THERMOSTAT 50 ÷ 250 °C

This system is suitable for cooking on several levels, including different

types of food (fish, meat etc.), without the tastes and smells mingling. Air

circulation in the oven ensures a uniform distribution of heat.

Multiple cooking is possible as long as the cooking temperature of the

different foods is the same.

Instructions for the user

9.3 Grill cooking

FUNCTION SWITCH

THERMOSTAT

Permits rapid browning of foods. For short-term cooking of small

quantities, place the grid in the fourth guide from the bottom. For long-term

cooking and grills, put the grid in the lowest guide in accordance with the

size of the pieces.

Keep the oven door closed during cooking. Grilling with the door

open can permanently damage the oven and jeopardise safety whilst

the grill is on.

9.4 Hot-air grilling

FUNCTION SWITCH

THERMOSTAT 200 °C

Ensures uniform heat distribution with greater heat penetration into the

food. Food will be lightly browned on the outside and remain soft inside.

Keep the oven door closed during cooking. Heating up time must

not exceed 60 minutes.

Keep the oven door closed during cooking. Grilling with the door

open can permanently damage the oven and jeopardise safety whilst

the grill is on.

Instructions for the user

9.5 Thawing

FUNCTION SWITCH

THERMOSTAT 0

The movement of air ensured by the fan causes faster thawing of foods.

The air circulating inside the oven is at room temperature.

Thawing at room temperature has the advantage of not altering the taste

and appearance of the food.

Produkt Specifikationer

Mærke:	Smeg
Kategori:	Ovn
Model:	S201X
Justerbar termostat:	Ja
Bredde:	596 mm
Dybde:	566 mm
Højde:	595 mm
Produktfarve:	Rustfrit stål
Kontroltype:	Dreje
Strøm:	2900 W
Indvendig belysning:	Ja
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	50 L
Antal ovne:	1
Ovn termostatinterval:	50 - 250 °C
