Side 1/20

Contents

1 INSTRUCTIONS FOR SAFE AND PROPER USE ____________________ 25

2 POSITIONING OF THE HOB ____________________________________ 27

3 ELECTRICAL CONNECTION ____________________________________ 29

4 GAS CONNECTION ___________________________________________ 30

5 ADAPTATION TO DIFFERENT TYPES OF GAS _____________________ 32

6 FINAL OPERATIONS __________________________________________ 36

7 USING THE HOB______________________________________________ 39

8 CLEANING AND MAINTENANCE_________________________________ 42

THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES

WHOSE IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS

MANUAL.

INSTRUCTIONS FOR THE INSTALLER: these are for the qualified

technician who must carry out a suitable check of the gas system, install

the appliance, set it functioning and carry out an inspection test.

INSTRUCTIONS FOR THE USER: these contain user advice,

description of the commands and the correct procedures for cleaning

and maintenance of the appliance.

Introduction

1 INSTRUCTIONS FOR SAFE AND PROPER USE

THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND

THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN

ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE

COOKING HOB. WE ADVISE READING THIS MANUAL AND ALL THE

INSTRUCTIONS THEREIN BEFORE USING THE COOKING HOB.

ALSO KEEP THE SERIES OF NOZZLES SUPPLIED. INSTALLATION

MUST BE CARRIED OUT BY QUALIFIED PERSONNEL IN

ACCORDANCE WITH THE REGULATIONS IN FORCE. THIS

APPLIANCE IS INTENDED FOR DOMESTIC USES AND CONFORMS

TO CURRENT REGULATIONS IN FORCE. THE APPLIANCE HAS

BEEN BUILT TO CARRY OUT THE FOLLOWING FUNCTIONS:

COOKING AND HEATING-UP OF FOOD. ALL OTHER USES ARE

CONSIDERED IMPROPER. THE MANUFACTURER DECLINES ALL

RESPONSIBILITY FOR IMPROPER USE.

DO NOT LEAVE THE PACKING IN THE HOME ENVIRONMENT.

SEPARATE THE VARIOUS WASTE MATERIALS AND TAKE THEM TO

THE NEAREST SPECIAL GARBAGE COLLECTION CENTRE.

IT IS OBLIGATORY FOR THE ELECTRICAL SYSTEM TO BE

GROUNDED ACCORDING TO THE METHODS REQUIRED BY

SAFETY RULES.

THE PLUG TO BE CONNECTED TO THE POWER CABLE AND THE

SOCKET MUST BE THE SAME TYPE AND MUST CONFORM TO

CURRENT REGULATIONS.

NEVER UNPLUG BY PULLING ON THE CABLE.

IMMEDIATELY AFTER INSTALLATION CARRY OUT A BRIEF

INSPECTION TEST OF THE COOKING HOB, FOLLOWING THE

INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT FUNCTION,

DISCONNECT IT FROM THE SUPPLY AND CALL THE NEAREST

TECHNICAL ASSISTANCE CENTRE.

NEVER ATTEMPT TO REPAIR THE APPLIANCE.

ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE

POSITION "ZERO" (OFF) WHEN YOU FINISH USING THE HOB.

Produkt Specifikationer

Mærke:	Smeg
Kategori:	Komfur
Model:	SR34ASX1
Bredde:	600 mm
Dybde:	500 mm
Højde:	30 mm
Produktfarve:	Rustfrit stål
Placering af apparat:	Indbygget
Komfurtype:	Gaskomfur
Antal kogeplader / madlavningsområde:	4
Blus/kogeplade zone 1 strøm:	1800 W
Blus/kogeplade zone 2 strøm:	4000 W
Blus/kogeplade zone 1 type:	Regelmæssig
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre bagende
Blus/kogeplade zone 1 strømkilde:	Gas
Blus/kogeplade zone 2 type:	Ekstra stor
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre front
Blus/kogeplade zone 2 strømkilde:	Gas
Blus/kogeplade zone 3 type:	Regelmæssig
Blus/kogeplade zone 4 type:	Simre
Blus/kogeplade zone 4 strømkilde:	Gas
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Gas
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Højre bagende
Blus/kogeplade zone 4 position:	Højre forside
Antal gasbrændere:	4
Blus/kogeplade zone 4 strøm:	1050 W
Blus/kogeplade zone 3 strøm:	1800 W
Wokbrænder:	Ja
Wokbrændeposition:	Venstre front
