Side 1/6
SignalLED User Handbook
SIGNALLED STUDIO ILLUMINATED SIGNS
SIGNALLED STUDIO ILLUMINATED SIGNS
SignalLED User Handbook
SIGNALLED STUDIO ILLUMINATED SIGNS
12
SIGNALLED STUDIO ILLUMINATED SIGNS
1
Technical Specications
Physical Specication
Power Supply: Plug-top power supply providing 6V at 1A, with 4
international wall adapters (UK, EU, US and AUS) and 5m
lead to bare ends.
Power Input: 5-7V DC
40cm Sign: 500mA max
Input Connector: 4 way screw terminal block
Control Inputs: 2 x pull-down to 0V
Perspex Dimensions: Single: 40cm (W) x 8cm (H)
Equipment Type
Single Flush Mounting Signs (20cm):
LD-20F1REC 20cm ‘RECORD’ Sign
LD-20F1ONA 20cm ‘ON AIR’ Sign
LD-20F1MCL 20cm ‘MIC LIVE’ Sign
Single Flush Mounting Signs (40cm):
LD-40F1REC 40cm ‘RECORD’ Sign
LD-40F1ONA 40cm ‘ON AIR’ Sign
LD-40F1MCL 40cm ‘MIC LIVE’ Sign
LD-40F1PHN 40cm ‘PHONE’ Sign
LD-40F1TRF 40cm ‘TRAFFIC FLAG ON’ Sign
LD-40F1ADB 40cm ‘AD BREAK’ Sign
LD-40F1REH 40cm ‘REHEARSAL’ Sign
LD-40F1DOR 40cm ‘DOOR’ Sign
LD-40F1OBT 40cm ‘OBIT’ Sign
LD-40F1NOE 40cm ‘NO ENTRY’ Sign
LD-40F1EXIT 40cm ‘EXIT’ Sign
LD-40F1SIL 40cm ‘SILENCE PLEASE’ Sign
LD-40F1MET 40cm ‘MEETING IN PROGRESS’ Sign
LD-40F1INT 40cm ‘INTERVIEW IN PROGRESS’ Sign
Twin Flush Mounting Signs (2 x 20cm):
LD-40F2TX-REH 2 x 20cm ‘TX’ & ‘ REH’ Sign
LD-40F2ONA-MCL 2 x 20cm ‘ON AIR’ & ‘MIC LIVE’ Sign
Double Sided End Mounting Signs (40cm):
LD-40E1REC 40cm ‘RECORD’ Sign
LD-40E1ONA 40cm ‘ON AIR’ Sign
LD-40E1MCL 40cm ‘MIC LIVE’ Sign
Mounting Kits:
LD-KE1 End Mounting Kit For 40cm Or 20cm Flush Mounting Signs
LD-IT LED Sign End Mounting Installation Tool
Weights & Boxed Dimensions:
Sign Type
Width
(cm)
Depth
(cm)
Height
(cm)
Gross
Weight
(kg)
Nett
Weight
(kg)
LD-20F1 style signs 39 20 11 1.0 0.65
LD-40E1 style signs 60 20 11 1.1 0.75
LD-40E2 style signs 60 20 11 1.1 0.75
LD-40F1 style signs 60 20 11 1.1 0.75
LD-40F2 style signs 60 20 11 1.1 0.75
Note : Weights are approximate and based on a sign supplied with the PSU.
SignalLED LD-E1, LD-E2 & LD-KE1
User Handbook
This handbook is for use with the following stock codes:
LD-40E1MCL SignalLED double sided end mounting 40cm MIC LIVE sign
LD-40E1ONA SignalLED double sided end mounting 40cm ON AIR sign
LD-40E1REC SignalLED double sided end mounting 40cm RECORD sign
LD-40E2 SignalLED twin double sided end mounting 2 x 20cm sign
LD-IT SignalLED end mount sign installation tool
LD-KE1 SignalLED conversion kit, single ush mount to end mount
©Sonifex Ltd, 2009
All Rights Reserved
Revision 1.0, March 2009
Sonifex Ltd, 61, Station Road, Irthlingborough,
Northants, NN9 5QE, England.
Tel: +44 (0)1933 650 700
Fax: +44 (0)1933 650 726
Email: sales@sonifex.co.uk
Website: http://www.sonifex.co.uk
Information in this document is subject to change without notice and does not represent a commitment on the part of
the vendor. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising from the use of information or any
error contained in this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying, recording, information storage and retrieval systems, for any purpose other than the purchaser’s
personal use, without the express written permission of Sonifex Ltd.
Unless otherwise noted, all names of companies, products and persons contained herein are part of a completely
ctitious adaptation and are designed solely to document the use of Sonifex product
