SignalLED User Handbook

SIG NAL LED STUDIO I LLUMINATED SIG NS

SIG NAL LED STUDIO I LLUMI NATED SIG NS

SignalLED User Handbook

SIG NAL LED STUDIO I LLUMI NATED SIG NS

SIG NAL LED STUDIO I LLUMINATED SIG NS

Technical Specications

Physical Specication

Power Supply: Plug-top power supply providing 6V at 1A, with 4

international wall adapters (UK, EU, US and AUS) and 5m

lead to bare ends.

Power Input: 5-7V DC

40cm Sign: 500mA max

Input Connector: 4 way screw terminal block

Control Inputs: 2 x pull-down to 0V

Perspex Dimensions: Single: 40cm (W) x 8cm (H)

Equipment Type

Single Flush Mounting Signs (20cm):

LD-20F1REC 20cm ‘RECORD’ Sign

LD-20F1ONA 20cm ‘ON AIR’ Sign

LD-20F1MCL 20cm ‘MIC LIVE’ Sign

Single Flush Mounting Signs (40cm):

LD-40F1REC 40cm ‘RECORD’ Sign

LD-40F1ONA 40cm ‘ON AIR’ Sign

LD-40F1MCL 40cm ‘MIC LIVE’ Sign

LD-40F1PHN 40cm ‘PHONE’ Sign

LD-40F1TRF 40cm ‘TRAFFIC FLAG ON’ Sign

LD-40F1ADB 40cm ‘AD BREAK’ Sign

LD-40F1REH 40cm ‘REHEARSAL’ Sign

LD-40F1DOR 40cm ‘DOOR’ Sign

LD-40F1OBT 40cm ‘OBIT’ Sign

LD-40F1NOE 40cm ‘NO ENTRY’ Sign

LD-40F1EXIT 40cm ‘EXIT’ Sign

LD-40F1SIL 40cm ‘SILENCE PLEASE’ Sign

LD-40F1MET 40cm ‘MEETING IN PROGRESS’ Sign

LD-40F1INT 40cm ‘INTERVIEW IN PROGRESS’ Sign

Twin Flush Mounting Signs (2 x 20cm):

LD-40F2TX-REH 2 x 20cm ‘TX’ & ‘ REH’ Sign

LD-40F2ONA-MCL 2 x 20cm ‘ON AIR’ & ‘MIC LIVE’ Sign

Double Sided End Mounting Signs (40cm):

LD-40E1REC 40cm ‘RECORD’ Sign

LD-40E1ONA 40cm ‘ON AIR’ Sign

LD-40E1MCL 40cm ‘MIC LIVE’ Sign

Mounting Kits:

LD-KE1 End Mounting Kit For 40cm Or 20cm Flush Mounting Signs

LD-IT LED Sign End Mounting Installation Tool

Weights & Boxed Dimensions:

Sign Type Width

(cm) Depth

(cm) Height

(cm)

Gross

Weight

(kg)

Nett

Weight

(kg)

LD-20F1 style signs 39 20 11 1.0 0.65

LD-40E1 style signs 60 20 11 1.1 0.75

LD-40E2 style signs 60 20 11 1.1 0.75

LD-40F1 style signs 60 20 11 1.1 0.75

LD-40F2 style signs 60 20 11 1.1 0.75

Note : Weights are approximate and based on a sign supplied with the PSU.

SignalLED LD-E1, LD-E2 & LD-KE1

User Handbook

This handbook is for use with the following stock codes:

LD-40E1MCL SignalLED double sided end mounting 40cm MIC LIVE sign

LD-40E1ONA SignalLED double sided end mounting 40cm ON AIR sign

LD-40E1REC SignalLED double sided end mounting 40cm RECORD sign

LD-40E2 SignalLED twin double sided end mounting 2 x 20cm sign

LD-IT SignalLED end mount sign installation tool

LD-KE1 SignalLED conversion kit, single ush mount to end mount

©Sonifex Ltd, 2009

Revision 1.0, March 2009

Sonifex Ltd, 61, Station Road, Irthlingborough,

Northants, NN9 5QE, England.

Tel: +44 (0)1933 650 700

Fax: +44 (0)1933 650 726

Email: sales@sonifex.co.uk

Website: http://www.sonifex.co.uk

Information in this document is subject to change without notice and does not represent a commitment on the part of

the vendor. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising from the use of information or any

error contained in this manual.

No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,

including photocopying, recording, information storage and retrieval systems, for any purpose other than the purchaser’s

personal use, without the express written permission of Sonifex Ltd.

Unless otherwise noted, all names of companies, products and persons contained herein are part of a completely

ctitious adaptation and are designed solely to document the use of Sonifex product

SignalLED User Handbook

SIG NAL LED STUDIO I LLUMINATED SIG NS

SIG NAL LED STUDIO I LLUMI NATED SIG NS

SignalLED User Handbook

SIG NAL LED STUDIO I LLUMINATED SIG NS

SIG NAL LED STUDIO I LLUMI NATED SIG NS

112

Warranty Information

This product is supplied with a 12 month back to base warranty. For further details, please

refer to the Sonifex website: http://www.sonifex.co.uk/company/terms/index.shtml

In order to register the date of purchase so that we can keep you informed of any design

improvements or modications, it is important to complete the warranty registration

document that is enclosed and return it to Sonifex Ltd in the UK.

For your own records you should write down the serial number of the SignalLED sign.

Serial Number TL………………………………………

Introduction

The SignalLED Sign is a new elegant approach to illuminated displays and signage. Using

the latest technology and components, the SignalLED sign can be simply congured onsite

for colour and mode.

t $IPPTFGSPNXIJUFHSFFOSFECMVFZFMMPXPSBOHFDZBOBOENBHFOUB

t $IPPTFGSPNBMBSHFSBOHFPGEJòFSFOUTJHOUFYU

t 'PVSJMMVNJOBUJPONPEFTDPOTUBOUøBTIJOHQVMTJOHBOEPò

t 5XPDPOUSPMQVMMMPXJOQVUT

t 4JOHMFPSUXJOTJHOTXJUITFQBSBUFDPOUSPMT

t %$JOQVUQPXFSTVQQMZQSPWJEFE

t 'MVTIUPUIFXBMMPSFOENPVOUFE

t %PVCMFTJEFEFOENPVOUJOHBWBJMBCMFGPSVTFJODPSSJEPST

t 4JNQMFUPJOTUBMM

t $VTUPNTJHOTDBOCFNBEFUPPSEFS

Safety Information

This equipment has been designed to meet the safety regulations currently advised

in the country of purchase and it conforms to the safety regulations specied by use

of the CE Mark. This equipment operates in a horizontal position.

Installation Notes

The SignalLED sign should be installed in an area which is not subject to excessive heat or

cold. Also, you should avoid installing it in atmospheric conditions which are dusty, smoky,

or dirty, or where there is moisture or vibration. The sign is for internal use only. The unit is

not sealed and cannot be used outside or in very damp or humid environments.

Do not use any solvents to clean the sign. Use a soft dry brush or a clean cloth moistened

with water or mild detergent.

Avoid using the SignalLED sign close to strong sources of electromagnetic radiation such as

video monitors or high power electric cabling.

In all cases the SignalLED sign should be installed and serviced by qualied personnel.

2. Setting Which Side (Segment) of Your Sign Illuminates

B&OTVSFBMMUIFTXJUDIFTBSFTFUUPUIF0òQPTJUJPO

b) Set SWT 2 and 3 to modify the relevant input state:

Function SWT2 SWT3

Program resting state (when no signalling inputs are active) 0ò 0ò

Signalling Input 1 active state On 0ò

Signalling Input 2 active state 0ò On

Signalling Input 1 and Input 2 active state On On

c) Set SWT 6 to 8 as follows:

Side (Segment) SWT6 SWT7 SWT8

Master (section of the sign nearest the

connection block) 0ò 0ò 0ò

Slave (section of the sign furthest from the

connection block) On 0ò 0ò

Whole Sign 0ò 0òOn

E4FU4850OBOESFUVSOJUUP0òUIJTTBWFTUIFTJEFPSTFHNFOU

3. Setting the Illumination Mode of Your Sign

B&OTVSFBMMUIFTXJUDIFTBSFTFUUPUIF0òQPTJUJPO

b) Set SWT 2 and 3 to modify the relevant input state:

Function SWT2 SWT3

Program resting state (when no signalling inputs are active) 0ò 0ò

Signalling Input 1 active state On 0ò

Signalling Input 2 active state 0ò On

Signalling Input 1 and Input 2 active state On On

c) Set SWT 5 to On to indicate that you are about to set the Mode.

d) Set SWT 6 to 8 as follows:

Illumination Mode SWT6 SWT7 SWT8

On constantly 0ò 0ò 0ò

Flashing On 0ò 0ò

Pulsing On0ò 0ò

Follow mode** On On On

**Note: Follow mode can be assigned when both inputs are active. It will illuminate the

two halves of the sign according to the modes set for input 1 and input 2.

F4FU4850OBOESFUVSOJUUP0òUIJTTBWFTUIFJMMVNJOBUJPONPEF
