[General]
Rated input: 7.2V , 3.2W
Operating temperature:
0 to 40 °C (32 to 104 °F)
Storage temperature:
–20 to 55 °C (–4 to 131 °F)
Dimensions (W/H/D) (Approx.):
113.3 × 67.9 × 87.5 mm
113.3 × 67.9 × 74.5 mm (from front
edge of lens to monitor)
4 1/2 × 2 3/4 × 3 1/2 in.
4 1/2 × 2 3/4 × 3 in. (from front edge
of lens to monitor)
Mass (Approx.):
498g (1lb 1.6oz) (including battery
pack, SD Card)
[Wireless LAN]
WW697160 (see name plate on the
bottom of camera)
Supported format:
IEEE802.11a/b/g/n/ac
Frequency band: 2.4GHz/5GHz
WW402748 (see name plate on the
bottom of camera)
Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz
[Eco and energy saving]
Power consumption (Off mode): Not
available
Power consumption (Standby mode/
Low power mode): 0.5W
Power consumption (Networked
standby mode): 2.0W (Bluetooth)/
2.0W (all terminals and networks
connected)
Low power mode activated:
Within 20minutes (default)
Networked standby mode activated:
Within 20minutes (default)
Rechargeable battery pack
NP-FW50
Rated voltage: 7.2V
Recommended USB-PD-
compatible AC adaptor
Input: 100-240V , 50/60Hz
Output: 9V / 2A or more
Design and specifications are subject to change without notice.
Compatible iPhone/iPad models
iPhone 16 Pro Max, iPhone 16 Pro, iPhone 16 Plus, iPhone 16, iPhone 15 Pro Max,
iPhone 15 Pro, iPhone 15 Plus, iPhone 15, iPhone 14 Pro Max, iPhone 14 Pro, iPhone 14 Plus,
iPhone 14, iPhone SE (3rd generation), iPhone 13 Pro Max, iPhone 13 Pro, iPhone 13,
iPhone 13 mini, iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone 12 mini, iPhone SE
(2nd generation), iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11, iPhone XS Max, iPhone XS,
iPhone XR, iPad Pro 13-inch (M4), iPad Pro 12.9-inch (2nd through 6th generation), iPad Pro
11-inch (M4), iPad Pro 11-inch (1st through 4th generation), iPad Pro 10.5-inch, iPad Air
13-inch (M2), iPad Air 11-inch (M2), iPad Air (3rd through 5th generation), iPad (6th through
10th generation), iPad mini (A17 Pro), iPad mini (5th through 6th generation)
(As of January 2025)
Trademarks/Licenses
•
is a trademark of Sony Group Corporation.
• Apple, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other
countries.
• USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
• The terms HDMI™, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the
HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator,
Inc.
• Wi-Fi, the Wi-Fi logo and Wi-Fi Protected Setup are registered trademarks or trademarks
of the Wi-Fi Alliance.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Sony Group Corporation and its
subsidiaries is under license.
• QR Code is a trademark of Denso Wave Inc.
• In addition, system and product names used in this manual are, in general, trademarks or
registered trademarks of their respective developers or manufacturers. However, the ™
or marks may not be used in all cases in this manual.
IMPORTANT – Read the End User Software License Agreement before using your Sony
product.
Using your product indicates your acceptance of the End User Software License
Agreement. The software license agreement between you and Sony is available at the
following URL:
(https://rd1.sony.net/help/di/el23/h_zz/)
• Use of the Made for Apple badge means that an accessory has been designed to
connect specifically to the Apple product(s) identified in the badge, and has been
certified by the developer to meet Apple performance standards. Apple is not
responsible for the operation of this device or its compliance with safety and regulatory
standards.
Note on the 5GHz band for wireless LAN
When using the wireless LAN function outdoors, set the band to 2.4GHz by following the
procedure below. (WW697160 only)
• MENU (Network) [Wi-Fi] [Wi-Fi Frequency Band]
How to turn off wireless network functions (Wi-Fi, etc.) temporarily
When you board an airplane, etc., you can turn off all wireless network functions
temporarily using [Airplane Mode].
How to turn on or off Wi-Fi function
Select MENU (Network) [Wi-Fi] [Wi-Fi Connect] [On] or [Off].
How to turn on or off Bluetooth function
Select MENU (Network) [Bluetooth] [Bluetooth Function] [On] or [Off].
For Customers in the U.S.A. and Canada
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment
has very low levels of RF energy that is deemed to comply without testing of specific
absorption rate (SAR).
This equipment has been tested and found to comply with ISED radiation exposure limits
set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency
(RF) Exposure rules.
The available scientific evidence does not show that any health problems are associated
with using low power wireless devices. There is no proof, however, that these low power
wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio
frequency energy (RF) in the microwave range while being used. Whereas high levels of
RF can produce health effects (by heating tissue), exposure of low-level RF that does not
produce heating effects causes no known adverse health effects. Many studies of low-
level RF exposures have not found any biological effects. Some studies have suggested
that some biological effects might occur, but such findings have not been confirmed by
additional research.
For Customers in the U.S.A.
For question regarding your product or for the Sony Service Center nearest you, call 1-800-
222-SONY (7669) .
Supplier’s Declaration of Conformity
Trade Name : SONY
Model : WW697160
Responsible Party : Sony Electronics Inc.
Address : 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number : 858-942-2230
This product contains a button cell or coin battery.
WARNING
• INGESTION HAZARD: This product
contains a button cell or coin battery.
• DEATH or serious injury can occur if
ingested. • A swallowed button cell or
coin battery can cause Internal Chemical
Burns in as little as 2 hours. • KEEP new
and used batteries OUT OF REACH of
CHILDREN • Seek immediate medical
attention if a battery is suspected to be
swallowed or inserted inside any part of
the body.
• Remove and immediately recycle or dispose of used batteries according to local
regulations and keep away from children. Do NOT dispose of batteries in household trash
or incinerate.
• Even used batteries may cause severe injury or death.
• Call a local poison control center for treatment information.
• Non-rechargeable batteries are not to be recharged.
• Do not force discharge, recharge, disassemble, heat above 55 °C (131 °F) or incinerate.
Doing so may result in injury due to venting, leakage or explosion resulting in chemical
burns.
This product contains a non-replaceable button/coin cell battery.
Battery type: ML621 or MS621
Nominal Voltage: 3 V
Important note on use of 5 GHz wireless LAN
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the
MAC, through the digital and analog baseband, and finally to the RF chip. Several special
packets are initiated by the MAC. These are the only ways the digital baseband portion will
turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the
transmitter will be on only while one of the aforementioned packets is being transmitted.
In other words, this device automatically discontinue transmission in case of either
absence of information to transmit or operational failure.
Frequency Tolerance: ±20 ppm
For Customers in Canada
5150-5350 MHz band is restricted to indoor operation only.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-
5350MHz and 5650-5850MHz and that these radars could cause interference and/or
damage to LE-LAN devices.
For Customers in Europe
WLAN 2 400 MHz < 60 mW e.i.r.p.
5 150 - 5 350 MHz
5 470 - 5 725 MHz
< 35 mW e.i.r.p.
5 725 - 5 850 MHz < 25 mW e.i.r.p.
Bluetooth 2 400 MHz < 10 mW e.i.r.p.
Hereby, Sony Corporation declares that this equipment is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet
address:
https://www.compliance.sony.eu
Hereby, Sony Corporation declares that this equipment is in compliance with the UK
relevant statutory requirements.
The full text of the declaration of conformity is available at the following internet address:
https://compliance.sony.co.uk
For this radio equipment the following restrictions on putting into service or of
requirements for authorization of use apply in AT/BE/BG/CY/CZ/DK/EE/FI/FR/DE/EL/HU/
IE/IT/LV/LT/LU/MT/NL/PL/PT/RO/SK/SI/ES/SE/UK/UK(NI)/HR/IS/LI/NO/CH/AL/BA/MK/
MD/RS/ME/XK/TR:
5150 - 5350MHz band is restricted to indoor operations only.
The power delivered by the charger must be between min 2.5 Watts required by the radio
equipment, and max 27 Watts in order to achieve the maximum charging speed.
USB PD fast charging
Deactivating the power management function will increase the energy consumption of
the product.
For Customers in the UK
STATEMENT OF COMPLIANCE
1. Model No.: WW697160
2. Name and address of the manufacturer’s authorised representative: Sony Europe B.V.,
The Heights, Brooklands, Weybridge, Surrey KT13 0XW, United Kingdom
3. This statement of compliance is issued under the sole responsibility of the
manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan
4. Object of the statement: Digital Camera
5. The object of the statement described above is in compliance with the applicable
security requirements in Schedule 1 of S.I. 2023 No. 1007 (Product Security)
6. Where applicable, references to the relevant standards used in relation to which
compliance is declared:
7. Defined support period for security updates: 2028-12-31
8. Additional information: Note(s):
Signed for and on behalf of:
Sony Europe B.V.
Kris De Pauw
Vice President
Weybridge, 2024-08-26
Sony Europe B.V.
Registered Office: The Heights, Brooklands, Weybridge, Surrey, KT13 0XW, United Kingdom
· Incorporated in the Netherlands No. 71682147
The support period for security updates can be found on the page linked below. The date
given in this document is as of the time of release.
https://compliance.sony.co.uk
For customers who purchased their camera from a store in
Japan that caters to tourists
Note
Some certification marks for standards supported by the camera can be confirmed on the
screen of the camera.
Select MENU
(Setup) [Setup Option] [Certification Logo].
Specifications
Camera
[System]
Camera Type: Digital Still Camera
Lens: ZEISS Sonnar T
35mm single
focus lens
[Image sensor]
Image format: 35 mm full frame, CMOS
image sensor
Number of effective pixels on camera:
Approx. 61 000 000 pixels (still
images) / approx. 50 800 000 pixels
(movies)
Total number of pixels on camera:
Approx. 62 500 000 pixels
Additional information on this product and answers to frequently asked
questions can be found at our Customer Support Website.
