3-798-717- (1)31

FM/AM Radio

Operating Instructions

使用說明書 (背面)

Features

• High power radio

• Long battery life with two R20 (size D) batteries.

• Easy to carry with the supplied carrying strap.

Installing the

Batteries (see fig. A)

1 Open the lid of the battery case.

2 Insert the batteries with correct polarity.

3 Close the lid.

Battery life

Using Sony batteries R20 (size D):

FM: Approx. 200 hours

AM: Approx, 220 hours

Replacing batteries

When the sound becomes weak or distorted, replace

all the batteries with new ones.

Note

When the unit is not to be used for a long period of

time, remove the batteries to avoid damage caused by

battery leakage and corrosion.

Operating the Radio

1Set .”FM/AM/OFF to “FM” or “AM

Power is turned on.

2Tune in a station using TUNING.

3Adjust the volume using VOLUME.

To turn off the radio

Set .”FM/ /AM OFF OFF to “

To listen with an earphone

(not supplied)

When an earphone is connected to the jack, thev

sound through the speaker cannot be heard.

Improving the

Reception

FM: Extend the telescopic

antenna and adjust

the length and the

angle for the best

reception.

AM: Since the reception is

affected by the

direction of the radio,

rotate the radio

horizontally for

optimum reception.

Attaching the

Supplied Carrying

Strap

When you carry the unit, use the supplied carrying

strap.

Pass the strap under the bar on each side of the radio.

Pass the strap through the buckle.

Precautions

• Do not open the unit. Refer servicing to qualified

personnel only.

• Operate the unit only on 3 V DC with two R20 (size

D) batteries.

• Avoid exposure to temperature extremes, direct

sunlight, moisture, sand, dust, or mechanical shock.

Never leave in a car parked in the sun.

• Should any solid object or liquid fall into the unit,

remove the batteries, and have the unit checked by

qualified personnel before operating it any further.

• Since a strong magnet is used for the speaker, keep

personal credit cards using magnetic coding or

spring-wound watches away from the unit to prevent

possible damage from the magnet.

• When the casing becomes soiled, clean it with a soft

cloth dampened with mild detergent solution. Never

use abrasive cleansers or chemical solvents, as they

may mar the casing.

• In vehicles or in buildings, radio reception may be

difficult or noisy. Try listening near a window.

If you have any questions or problem concerning your

unit, please consult the nearest Sony dealer.

Specifications

Frequency range

FM: 87.5 – 108 MHz

AM: 530 – 1 605 kHz

Speaker

Approx. 9.2 cm dia.

Power output

300 mW (max.)

Output

v (earphone) jack (ø 3.5 mm mini jack)

Power requirements

3 V DC, two R20 (size D) batteries

Dimensions

Approx. 206 66 mm (w/h/d) incl.× 131 ×

projecting parts and controls

Mass

Approx. 673 g incl. batteries

Supplied accessories

Carrying strap (1)

Operating Instructions (1)

Design and specifications are subject to change

without notice.

English

Insert the side of the battery first.E

Telescopic antenna

ICF-F10
