Side 1/2

5-049-955- (1)11

KD-55X77L / 50X77L / 43X77L

Reference Guide

參考指南

Television

(mm/ )毫米 *

(kg/

千克)

   

KD-55X77L 1243 721 15.371

KD-50X77L 1126 12.1653 70

KD-43X77L 972 567 70 9.3

*1 (Approx. / 大約)

(mm/ )毫米 *

(kg/

千克)

   

KD-55X77L 1243 789 334 15.6

KD-50X77L 1126 718 12.3267

KD-43X77L 266972 632 9.5

*1 (Approx. / 大約)

https://rd1.sony.net/help/tv/kgar1/h_ga/

MIC









The remote control shape, layout, availability and function of remote

control buttons may vary depending on your region/country/TV model/

TV settings.*

 (Power)

TV:

Display TV channel list or switch to input.

(Quick settings): Display Quick Settings.

(Input select): Display and select the input source, etc.

(Control menu): Display the Control menu.



    / / / / : On screen menu navigation and selection.

(Back)

(Home)

(Google Assistant / Microphone): Use Google Assistant*

or voice

search*



+ / – (Volume)

(Mute)*

CH + / – (Channel)

(Dashboard): Display Dashboard.

(Guide): Display the digital programme guide.



App buttons

*1 For other remote control models, refer to the online Help Guide for details.

*2 Only for limited region/country/model/language.

*3 Google Assistant or voice search requires an Internet connection.

*4 Accessibility shortcut is available by pressing and holding

(Mute).

遙控器外形、按鈕的佈局、可用性與功能視您的國家/區域/電視機型號或設定而

可能略有不同。

（電源）

TV：顯示電視機頻道清單或切換為輸入。

（快速設定）：顯示快速設定。

（輸入選擇）：顯示並選擇輸入來源等。

（控制選單）：顯示控制選單。



   / / / / :在螢幕選單導航和選擇上。

（返回）

（主選單）

（Google助理/麥克風）：使用Google助理

*2*3

或語音搜尋

。



+/−（音量）

（靜音)

CH+/−（頻道）

（資訊主頁）：顯示資訊主頁。

（指南）：顯示數位節目指南。



應用按鈕

*1有關其他遙控器型號，請參閱線上說明指南以獲取詳情。

*2僅限用於有限區域/國家/型號/語言。

*3使用Google助理或語音搜尋需要網際網路連線。

*4按住

（靜音）可使用輔助使用快捷鍵。

About Manuals

Please retain the manuals for future reference.

Paper manual

Setup Guide (on top of the product) / Reference Guide (this manual) /

Safety and Other Information.

Help Guide (On screen Manual)

•To open it, select [Settings] [Help and feedback] [Help] or select t t

[Help] in the Home Menu, if [Help] does not exist, select [See all] t

[Help].

•You can refer to the Help Guide with your smartphone (visit website

provided on the front cover of Reference Guide).

Read and understand the contents of this manual before operating this

product.

Note

•Instructions about “Installing the TV to the Wall” are included within this TV’s

instruction manual.

•Read the supplied safety documentation for additional safety information.

•Images and illustrations used in the supplied manuals are for reference and

may differ from the actual product.

•Setting menus are subject to change without notice due to software

updates. For latest information, visit Sony support website.

IMPORTANT - Read the End User Software Licence Agreement before

using your Sony product. Using your product indicates your acceptance

of the End User Software Licence Agreement. The software licence

agreement between you and Sony is available online at Sony website

(https://www.sony.net/tv-software-licenses2/) or on your product screen.

Press

(Quick Settings) on the remote control and select [Settings] t

[System] t t t [About] [Legal information] [Notices and licences].

Location of the identification label

Labels for the TV Model No. and Power Supply rating are located on the rear of

the TV.

This television is designed for use in Hong Kong and ensured the usage in

Hong Kong only.

Installing the TV to the Wall

Using the optional Wall-Mount Bracket (SU-WL850 or SU-WL450)* (not supplied)

To Customers:

For product protection and safety reasons, Sony strongly recommends that

installation of your TV be performed by Sony dealers or licensed contractors.

Do not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation, periodic maintenance

and examination of this product.

Wall-Mount Bracket Installation Information

For instructions on Wall-Mount Bracket installation, see the Installation

Information (Wall-Mount Bracket) on the product page for your TV model.

https://www.sony-asia.com/support

•Follow the instruction guide provided with the Wall-Mount Bracket for your

model. Sufficient expertise is required in installing this TV, especially to

determine the strength of the wall for withstanding the TV’s weight.

•Sony is not liable for any damage or injury caused by mishandling or

improper installation.

•Only qualified service personnel should carry out wall-mount installations.

•For safety reasons, it is strongly recommended that you use Sony

accessories, including:

— Wall-Mount Bracket SU-WL850

— Wall-Mount Bracket SU-WL450

•Be sure to use the screws supplied with the Wall-Mount Bracket when

attaching the Wall-Mount Bracket to the TV set. The supplied screws are

designed as indicated by illustration when measured from the attaching

surface of the Wall-Mount Bracket.

The diameter and length of the screws differ depending on the Wall-Mount

Bracket model.

Use of screws other than those supplied may result in internal damage to the

TV set or cause it to fall, etc.

•Be sure to store the unused screws and Table-Top Stand in a safe place until

you are ready to attach the Table-Top Stand. Keep the screws away from

small children.

* Only for limited region/country/model.

Troubleshooting

General troubleshooting for issues like: black screen, no sound, frozen picture,

TV does not respond, or network is lost, do the following steps.

1 Restart your TV by pressing the power button on the remote control for

about five seconds. Select [Restart] and TV will restart. If the TV does not

recover, try unplugging the AC power cord (mains lead) then press the

power button on the TV and release it. Wait for two minutes, and plug in the

AC power cord (mains lead).

Or, press the power button on the TV for about 40seconds until the TV

turns off.

2 Refer to the Help menu shown below.

3 Connect your TV to the Internet and perform a software update. Sony

recommends you to keep your TV software updated. Software updates

provide new features and performance improvements.

4 Visit Sony support website (information provided at the end of the

supplied safety documentation).

When you plug in the TV, the TV may not be able to turn on for a

while even if you press the power button on the remote control or

the TV.

It takes time to initialize the system. Wait for about one minute, then operate it

again.

The remote control does not function.

•Replace the batteries.

The parental lock password has been forgotten.

•Enter 4357 for the PIN and enter the new PIN.

For more information, refer to the Help Guide.

To open it, select [Settings] [Help and feedback] [Help] t t

or select [Help] in the Home Menu, if [Help] does not exist,

select [See all] [Help].t

Specifications

System

Panel system

LCD (Liquid Crystal Display) Panel, LED Backlight

TV system

Analogue: I, D/K, B/G, M

Digital: DTMB

Colour system

PAL/SECAM/NTSC3.58/NTSC4.43

Channel coverage

Analogue: UHF/VHF/Cable

Digital: UHF

Sound output (W)

10 + 10

Wireless technology

Protocol IEEE 802.11a/b/g/n/ac

Bluetooth® Version 5.0

Input/Output jacks

Antenna (aerial)/cable

75 ohm external terminal for VHF/UHF

HDMI IN 1/2/3 (HDCP 2.3-compatible)

Video:

4096 × 2160p (50, 60 Hz)*

, 4096 × 2160p (24 Hz), 3840 × 2160p (50, 60 Hz)*

3840 × 2160p (24, 25, 30 Hz), 1080p (30, 50, 60 Hz), 1080/24p, 1080i (50,

60 Hz), 720p (30, 50, 60 Hz), 720/24p, 576p, 576i 480p, 480i, PC Formats*

Audio:

In eARC (Enhanced Audio Return Channel) mode

Refer to the online Help Guide for details.

Except eARC mode

Two channel linear PCM: 32/44.1/48 kHz 16/20/24 bits, Dolby Audio

eARC/ARC (Enhanced Audio Return Channel/Audio Return Channel)

(HDMI IN 3 only)*

In eARC mode

Refer to the online Help Guide for details.

In ARC mode

Two channel linear PCM: 48 kHz 16 bits, Dolby Audio, Dolby Atmos

DIGITAL AUDIO OUT (OPTICAL)

Digital optical jack (Two channel linear PCM: 48 kHz 16 bits, Dolby Audio)

1, 2

USB port 1 and 2 supports High Speed USB (USB 2.0)

LAN

10BASE-T/100BASE-TX connector (Depending on the operating environment

of the network, connection speed may differ. The communication rate and

quality are not guaranteed.)

10 – 12 (mm)

 Wall-Mount Attachment

/ 壁掛連接件

 Wall-Mount Bracket / 壁掛式支架

(mm) / (毫米)
