Quick Start Guide

How to Install the Bundled Software

How to Use Your “WALKMAN”

1 Connect your “WALKMAN” to your computer using

the USB cable (

1), or the Micro USB cable ( ) 2

and charge cable (

3).

2 Select the following order with the computer.

Select [start] - [My Computer] or [Computer] - [WALKMAN] -

[Storage Media].

3 Double-click [Setup.exe].

The install wizard appears.



When you execute [Setup.exe], the [Setup.exe] file stored in the

[Storage Media] folder of your “WALKMAN” is copied to your

computer for backup, and WALKMAN Guide and Media Go are

installed to your computer.

4 Follow the on-screen instructions.

After executing [Setup.exe], the WALKMAN Guide shortcut appears

on the desktop of your computer.

5 Double-click (WALKMAN Guide) on the

desktop to start the WALKMAN Guide.

For details on transferring music, etc., refer to the User Guide

included in the WALKMAN Guide.

Contents

Please check the items in the package.

 “WALKMAN” (1)

 Headphones (1)

 Earbuds (Size S, L) (1)

 Attachment (1)

Use when connecting your

“WALKMAN” to the cradle (not

supplied), etc.



 Quick Start Guide (this manual)

 Software

The software is stored in the built-in

flash memory of your “WALKMAN,”

and includes the following items:

 Media Go

 WALKMAN Guide

 User Guide, etc.

For details on how to install, refer to

“How to Install the Bundled

Software (User Guide included)”.

NWZ-S763/S764/S765 only

 USB cable (1)

NWZ-S763BT/S764BT only

 Wireless Stereo Headphones (1)

 Earbuds for Wireless Stereo

Headphones (Size S, L) (1)

 Micro USB cable (1)

 Charge cable (1)



 User Guide for Wireless Stereo

Headphones (1)

About Windows Operating System

Make sure that the OS is Windows XP (Service Pack 3 or later), Windows Vista*

(Service Pack 1 or later) or Windows 7*

[Compatibility mode] for Windows XP is not supported.

How to Use your “WALKMAN”

BACK/HOME button

5-way button

OPTION/PWR OFF button

Charging the Battery

The battery of your “WALKMAN” is recharged while your “WALKMAN” is

connected to a running computer.

Charging...

About

3 hours

Charging

Fully-charged

Turning your “WALKMAN” On and Off

To turn on Press any button.

To turn off Press and hold the OPTION/PWR OFF

button.

 Hint



You can start the WALKMAN Guide and Media Go from the [start] menu (displayed by

clicking [start]).



If you delete the [Setup.exe] file in your “WALKMAN” by formatting the built-in flash

memory of your “WALKMAN,” copy [Setup.exe] file and [Install] folder from the

[Backup] folder on the computer to your “WALKMAN.” Connect your “WALKMAN”

to the computer on which to install, and follow the above procedure from step 1 to

install. After installing, delete [Setup.exe] file and [Install] folder from your

“WALKMAN.”

The backup data is preserved in the following [C] drive on your computer by the default

install setting.

C:\Program Files*

\Sony\WALKMAN Guide\NWZ-S760\Backup

[Program Files(x86)] may be displayed depending on the computer OS.

What can you do with the WALKMAN Guide ?

The WALKMAN Guide includes the following items:

 User Guide

The following contents can be viewed in your web browser.

 Details on how to use your “WALKMAN”

 How to use software to transfer content to your “WALKMAN”

 Troubleshooting

 Customer Registration Link

 Customer Support Link

 Other useful Links

Includes link information, etc., on the download site.

The bundled items differ depending on the country/region of purchase.

 Hint



After executing [Setup.exe], you can use the free space in the [Storage Media] folder

more effectively by formatting the built-in flash memory of your “WALKMAN.” To

format the built-in flash memory of your “WALKMAN,” see “To initialize (format) your

“WALKMAN”” on the backside.

Transferring Music

From CDs, etc., using Media Go

Media Go supports data transfer from iTunes 10 to your “WALKMAN.”

By drag-and-drop using Windows Explorer

Note



Media Go does not support contents that use digital rights management

technology (“WM-DRM”) for Windows Media. If your transfer “WM-DRM”

contents, use Windows Media Player. Refer to “Specifications” - “Specifications” -

“Supported file format” in the User Guide (HTML document) to check if your

“WALKMAN” support “WM-DRM” contents.

For details on transferring music, videos, photos or podcasts, refer to the User

Guide. The User Guide can be readily viewed from the WALKMAN Guide.

How to Install the Bundled Software (User Guide included)

NWZ-S763/S764/S765/S763BT/S764BT

Home menu

SensMe™ Channels

FM Radio

Photos

Settings

Voice Recording

Videos

Music

Go to song

playback screen

Podcasts

Playlists

Bluetooth

How to use the Home menu

The Home menu appears when you press and hold the BACK/HOME button. The

Home menu is the starting point to play audio, search for songs, changing settings,

etc.

From the Home menu, you can select the desired item on the screen by using the 5-

way button.

Confirm.

Return to the previous screen.

About the manuals

In addition to this Quick Start Guide, this model is accompanied by the User

Guide (HTML document) which you can view from the WALKMAN Guide.

For details, refer to “How to Install the Bundled Software (User Guide

included).”

Parts and Controls

To initialize (format) your “WALKMAN”

You can format the built-in flash memory of your “WALKMAN.” If the

memory is formatted, all files including the User Guide (HTML document)

will be erased and all setting values returned to their defaults. Be sure to verify

the files stored in memory prior to formatting, and then export any necessary

files to the hard disk of your computer or other device beforehand.

1 Press and hold the BACK/HOME button until the Home

menu appears.

2 Select [Settings] – [Common Settings] – [Reset/

Format] – [Format] – [Yes] – [Yes] in this order.

Press the / / / button to select the item, and then press the     

button to confirm.

When initialization finishes, [Memory formatted.] appears.

Note



Do not format the built-in flash memory using Windows Explorer. If you

format the built-in flash memory, format it on your “WALKMAN.”

Troubleshooting

If your “WALKMAN” does not function as expected, try the following steps to

resolve the issue.

1 Find the symptoms of the issue in “Troubleshooting” in the

User Guide (HTML document), and try any corrective

actions listed.

For details on connecting to a computer, see the tables on the right.

2 Connect your “WALKMAN” to your computer to charge the

battery.

You may be able to resolve some issues by charging the battery.

3 Press the RESET button with a

small pin, etc.

Before resetting your “WALKMAN,” check that

no song, video, etc. is being played back. You

can then reset your “WALKMAN” safely.

4 Check information on the issue in

the Help of each software.

5 Look up information on the issue on one of the customer

support Web sites.

About the customer support Web sites, see “For the latest information”.

6 If the approaches listed above fail to resolve the issue,

consult your nearest Sony dealer.

Symptom Cause/Remedy

Your “WALKMAN”

cannot charge the

battery.



The USB cable is not connected to a USB connector

on your computer properly.



Disconnect the USB cable, and then reconnect it.



Use the supplied USB cable.



The battery is charged in an ambient temperature out

of the range of 5 °C (41 °F) to 35 °C (95 °F).



You cannot charge the battery when the icon

appears. Charge the battery in an ambient

temperature of 5 °C (41 °F) to 35 °C (95 °F).



The computer is not on.



Turn on the computer.



Your computer has entered Sleep or Hibernation

status.



Release the computer from Sleep or Hibernation

status.



A USB hub is being used.



Connecting your “WALKMAN” via a USB hub may

not work. Connect your “WALKMAN” to your

computer using the USB cable (supplied).



The operating system installed on the computer is not

supported by your “WALKMAN.”



To charge your “WALKMAN,” connect your

“WALKMAN” to a computer with the operating

system that is supported by your “WALKMAN.”



You have not used your “WALKMAN” for more than

a year.



Depending on the conditions under which your

“WALKMAN” is used, the battery may have been

deteriorated. Consult your nearest Sony dealer.

[Connected USB. The

player cannot be

operated.] or [Connected

USB (MTP). The player

cannot be operated.]

does not appear when

connected to the

computer with the USB

cable (supplied) (The

computer does not

recognize your

“WALKMAN”).



The USB cable is not connected to a USB connector

on your computer properly.



Disconnect the USB cable, and then reconnect it.



Use the supplied USB cable.



A USB hub is being used.



Connecting your “WALKMAN” via a USB hub may

not work. Connect your “WALKMAN” directly to

your computer using the USB cable (supplied).



The USB connector on your computer may have a

problem.



Connect your “WALKMAN” to another USB

connector on your computer.

Symptom Cause/Remedy

[Connected USB. The

player cannot be

operated.] or [Connected

USB (MTP). The player

cannot be operated.]

does not appear when

connected to the

computer with the USB

cable (supplied) (The

computer does not

recognize your

“WALKMAN”).

(Continued)



When you use your “WALKMAN” for the first time,

or when the battery is low, it may take your

“WALKMAN” about 30 seconds to display the

message after connected to a computer. This is not a

malfunction.



The software authentication may be performed and it

may take rather a long time. Wait for a while.



The software installation has been failed.



Reinstall the software by using the installer. The

imported data will remain untouched.



The computer is running another software other than

the one used for transferring.



Disconnect the USB cable, wait a few minutes, and

reconnect it. If the problem persists, disconnect the

USB cable, restart the computer, and then

reconnect the USB cable.

Your “WALKMAN”

becomes unstable while

it is connected to the

computer.



A USB hub or USB extension cable is being used.



Connecting your “WALKMAN” via a USB hub or

extension cable may not work. Connect your

“WALKMAN” directly to your computer using the

USB cable (supplied).

When double-clicking

[Setup.exe] to install the

bundled software,

[Setup.exe] does not

execute, and the

Properties window

opens.



Install the bundled software after installing Windows

Media Player 11 or later. For details on Windows

Media Player, refer to the following web site:



http://support.microsoft.com/



BACK/HOME button



5-way button*

 (play/pause/confirm) button

 / buttons

 / buttons



Headphone jack



WM-PORT jack

Connect the USB cable (supplied), or peripheral devices (not supplied).



Display



Bluetooth indicator



VOL +*

/– button



OPTION/PWR OFF button

Press to display the option menu.

If you press and hold the OPTION/PWR OFF button, the screen turns off and your

“WALKMAN” enters standby mode.



HOLD switch



Strap hole



Microphone

Use to make voice recordings.



RESET button

Use a small pin, etc.

There are tactile dots. Use them to help with button operations.

Precautions

About the headphones



Avoid playing the unit at so loud a volume that extended play might affect your hearing.



At a high volume outside sounds may become inaudible. Avoid listening to the

unit in situations where hearing must not be impaired, for example, while

driving or cycling.

License and Trademark Notice

Refer to the User Guide (HTML document).

Excessive sound pressure from earphones and headphones can cause hearing loss.

Do not expose the batteries (battery pack or batteries installed) to excessive heat such as

sunshine, fire or the like for a long time.

WALKMAN:

Rated current consumption 500 mA

For customers who purchased the set supplied with the Wireless Stereo

Headphones

Wireless Stereo Headphones:

Rated current consumption 100 mA

When replacing the headphones/earphones, please refer to the models of the headphones/

earphones adapted to your unit that appear below.

MDR-EX083, MDR-NWBT10

At high volume, prolonged listening to the personal audio player can

damage the user’s hearing.

Owner’s Record

The model and serial numbers are located on the back of the player. Record them in the

space provided below. Refer to these numbers in the spaces whenever you call upon your

Sony dealer regarding this product.

Model No. ________________________

Serial No. ________________________

RESET button

Hereby, Sony Corp., declares that this equipment is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

For details, please access the following URL:

http://www.compliance.sony.de/

Norway

Use of this radio equipment is not allowed in the geographical area within a radius

of 20 km from the centre of Ny-Alesund, Svalbard.

For the latest information

If you have any questions or issues with this product, or would like information on

compatible items with this product, visit the following web sites.

For customers in the USA:

http://www.sony.com/walkmansupport

For customers in Canada:

http://www.sony.ca/ElectronicsSupport/

For customers in Europe:

http://support.sony-europe.com/DNA

For customers in Latin America:

http://www.sony-latin.com/index.crp

For customers in other countries/regions:

http://www.sony-asia.com/support

For customers who purchased the overseas models:

http://www.sony.co.jp/overseas/support/

Produkt Specifikationer

Mærke:	Sony
Kategori:	Mp3-afspiller
Model:	NWZ-S764
Bredde:	44.3 mm
Dybde:	8.4 mm
Højde:	97.5 mm
Vægt:	57 g
Produktfarve:	Sort
Skærm diagonal:	2 "
Skærmopløsning:	320 x 240 pixel
Berøringsskærm:	Ingen
Bluetooth:	Ja
FM radio:	Ja
Batteriteknologi:	Lithium-Ion (Li-Ion)
Equalizer:	Ja
Antal USB 2.0-porte:	1
Udgange til hovedtelefoner:	1
Slumretimer:	Ja
Automatisk slukning:	Ja
Understøttede videoformater:	H.264, MP4, MPEG4, WMV
Understøttede lydformater:	AAC, MP3, WMA
Driftstemperatur (T-T):	5 - 35 °C
Skærm:	LCD
Kabler inkluderet:	USB
Batterier inkluderet:	Ja
Bluetooth-version:	2.1+EDR
Bluetooth-profiler:	A2DP, AVRCP, OPP
Understøttede billedformater:	JPG
Frekvensområde:	20 - 20000 Hz
Forbindelsesteknologi:	Trådløs
Baggrundsfarve:	Hvid
Equalizerbånd, antal:	5
Understøttede radiobånd:	FM
Opladningstid for batteri:	3 t
Samlet lagringskapacitet:	8 GB
Indbygget mikrofon:	Ja
Kompatible operativsystemer:	Windows XP/Vista/7
Afspilningstilstande:	Normal, Repeat, Repeat one, Shuffle
Tilslutning af hovedtelefoner:	3,5 mm
Baggrundslys:	Ja
USB-drevet:	Ja
FM båndbredde:	87.5 - 108 MHz
Stemmeoptagelse:	Ja
Genopladelig:	Ja
Antal forudindstillede stationer:	30
Vedvarende afspilningstid, video:	10 t
Vedvarende afspilningstid, lyd:	50 t
Minimum plads på lagerdisk:	600 MB
Aspiller medietype:	Flash-hukommelse
Minimum processorhastighed:	1000 MHz
Minimum RAM:	1024 MB
Stemmeoptagelsestid:	9 t
