TV’s rear cover / Couvercle arrière du téléviseur
Wall-Mount Bracket / Support de fixation murale
Optional Camera and Microphone Unit (not supplied) Cable Management / Gestion du câble de la caméra avec microphone en option (non fourni)
The remote control shape, layout, availability
and function of remote control buttons may
vary depending on your region/country/TV
Display TV channel list or switch to
(Quick settings): Display Quick
(Input): Display and select the input
(Control menu): Display the
/ / / / : On screen menu
navigation and selection.
(Google Assistant / Microphone):
(Dashboard): Display Dashboard.
(Guide): Display the digital program
guide of TV or Cable/Satellite box*
*1 The remote control backlight will illuminate
when the light sensor detects the ambient
light is low. Automatic illumination of the
backlight can be turned off.
*2 RMF-TX910U only. To see the model name
of the remote control, open the remote
control cover and see the label on the
*3 The buzzer will emit a sound when you use
the remote control finder function. Refer to
the online Help Guide for details.
*4 For other remote control models, refer to
the online Help Guide for details.
*5 Only for limited region/country/model/
*6 Google Assistant requires an Internet
*7 Accessibility shortcut is available by
*8 [Cable/Satellite box setup] setting is
•Instructions about “Installing the TV to the
Wall” are included within this TV’s instruction
•Read the supplied safety documentation for
additional safety information.
Location of the identification label
Labels for the TV Model No. and Power Supply
rating are located on the rear of the TV. They can
be found by removing the terminal cover.
The model and serial numbers are located at
the side and/or rear of the TV. Record these
numbers in the spaces provided below. Refer
to them whenever you call upon your Sony
dealer regarding this TV.
Notice for customers in the United States of
Supplier’s Declaration of Conformity
Model: XR-85X93L XR-85X93CL / /
XR-75X93L / XR-75X93CL XR-65X93L / /
Responsible Party: Sony Electronics Inc.
Address: 16535 Via Esprillo, San Diego,
Telephone Number: 858-942-2230
Compatible Wall-Mount Bracket Information
Use the following Sony Wall-Mount Bracket with
Use with other Wall-Mount Brackets*
cause instability and could result in property
*1 Only for limited region/country/model.
*2 For instructions on using the Wall-
Mount Bracket with your TV please go to
https://www.sony.com/am/support for
your TV model and download “Wall-Mount
Sufficient expertise is required for TV
installations. Be sure to subcontract the
installation to a Sony dealer or licensed
contractor and pay adequate attention to safety
Before setting up your TV
Some TV models are packaged with a detached
Table-Top Stand so you can mount your TV to
a wall right away. See “Installing the TV to the
Wall” if you want to mount the TV to a wall. If
you are not mounting the TV to a wall, you will
need to attach the Table-Top Stand (refer to the
Be sure to consider the following while setting
•Disconnect all cables when carrying the TV.
•Before transporting the TV set, remove the
•Two or more persons (three or more persons
for 214.8 cm (85 inches) and above TV) are
needed to transport a large TV set.
•Correct hand placement while carrying the
TV is very important for safety and to avoid
XR-75X93L / 75X93CL / 65X93L / 65X93CL
taking measures to prevent
the TV from toppling over.
and result in property damage,
serious bodily injury or even
Preventing the TV from Toppling
•Secure the TV to a wall and/or Stand.
•Do not allow children to play or climb on
•Avoid placing or hanging items on the TV.
•Never install the TV on:
— slippery, unstable and/or uneven surfaces.
— furniture that can easily be used as steps,
such as a chest of drawers.
•Install the TV where it cannot be pulled,
•Install the TV so that the TV’s Table-Top Stand
does not protrude out from the Stand (not
supplied). If the Table-Top Stand protrudes out
from the Stand, it may cause TV set to topple
over, fall down, and cause personal injury or
•Route all AC power cords and connecting
cables so that they are not accessible to
Recommended Measures to Secure the TV
Consider the following measures when securing
your TV to a Stand (not supplied).
1 Secure the Stand for the TV.
Make sure the Stand can adequately support
the weight of the TV. Use two angle braces
(not supplied) to secure the Stand. For each
angle brace use the appropriate hardware to:
•Attach one side of the angle brace to the
•Attach the other side to the Stand.
2 Secure the TV to the Stand.
Use the optional hardware listed as follows
•M6 machine screws (screwed into the TV’s
•A screw or similar (attach it to the Stand).
•Rope or chain (strong enough to support
the weight of the TV). Make sure that there
is no excess slack in the rope or chain.
The length of the M6 machine screw differs
depending on the rope or chain diameter.
Please refer to below illustration.
3 Anchor the TV to the wall by using bolts, wall
anchor and chain (or rope).
M6 eye bolts (not supplied)
Please refer to below illustration for M6 eye
•Your TV is shipped with screws attached to
the rear of the TV depending on the TV model.
(They are fastened in the screw holes for wall
mounting.) Be sure to remove the upper two
screws prior to anchoring the TV to a wall.
•Securing the TV to the Stand without securing
the TV and the Stand to the wall provides
minimum protection against the TV toppling
over. For further protection, be sure to follow
the three measures recommended.
The BRAVIA® 4K TV Experience
Thank you for choosing Sony! Your new
BRAVIA® TV opens the door to the “4K TV
Experience”. This document will help you get
the most out of your TV. Please take a
moment to register your TV at:
https://productregistration.sony.com
https://www.sony.ca/registration
This TV displays all video input signals in a
resolution of 3840 dots × 2160 lines.
•For supported PC formats, refer to the online
Guidelines for IR Remote Control
•Point your remote control directly at the IR
sensor located on your TV.
•Make sure that no objects are blocking the
path between the remote control and the IR
•Fluorescent lamps can interfere with your
remote control; try turning off the fluorescent
•If you are having problems with the remote
control, reinsert or replace your batteries and
make sure that they are correctly inserted.
Installing the TV to the Wall
Using the optional Wall-Mount Bracket (SU-WL855
For product protection and safety reasons, Sony
strongly recommends that installation of your
TV be performed by Sony dealers or licensed
contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the
installation, periodic maintenance and
examination of this product.
Wall-Mount Bracket Installation
For instructions on Wall-Mount Bracket
installation, see the Installation Information
(Wall-Mount Bracket) on the Sony Customer
Support website for your TV model at the
https://www.sony.com/am/support
•Follow the instruction guide provided with the
Wall-Mount Bracket for your model. Sufficient
expertise is required in installing this TV,
especially to determine the strength of the
wall for withstanding the TV’s weight.
•Sony is not liable for any damage or
injury caused by mishandling or improper
•Be sure to store the unused screws and Table-
Top Stand in a safe place until you are ready to
attach the Table-Top Stand. Keep the screws
away from small children.
•Read the supplied safety documentation for
additional safety information.
* Only for limited region/country/model.
Using the optional Wall-Mount Bracket (Except
This TV’s instruction manual only provides the
steps to prepare the TV for Wall-Mount
installation before it is installed on the wall.
Your TV can be mounted to a wall using a
suitable Wall-Mount Bracket (not supplied). If
the Table-Top Stand is attached to the TV, the TV
may require detaching the Table-Top Stand; see
“Detaching the Table-Top Stand from the TV”.
Prepare the TV for the Wall-Mount Bracket
before making cable connections.
For product protection and safety reasons,
Sony strongly recommends that installation
of your TV on the wall be performed by
qualified professionals. Do not attempt to
•Follow the instruction guide provided with the
Wall-Mount Bracket for your model. Sufficient
expertise is required in installing this TV,
especially to determine the strength of the
wall for withstanding the TV’s weight.
•The screws for installing the Wall-Mount
Bracket to the TV are not supplied.
•Refer to the following table for wall-mount
XR-85X93L 85X93CL / 400 × 400 mm
XR-75X93L 75X93CL / 300 × 300 mm
XR-65X93L 65X93CL / 300 × 300 mm
•Be sure to store the unused screws and Table-
Top Stand in a safe place until you are ready to
attach the Table-Top Stand. Keep the screws
away from small children.
•Read the supplied safety documentation for
additional safety information.
•For more detailed information, visit Sony
Customer Support website.*
* Only for limited region/country/model.
1 Remove the terminal covers.
XR-85X93L / 85X93CL / 75X93L / 75X93CL
https://rd1.sony.net/help/tv/
Lisez ce manuel avant d’utiliser le produit
Service à la clientèle Sony
https://www.sony.ca/support
https://www.sony.com/tvsupport
Appelez le numéro de téléphone qui
apparaît sur votre carte/police de
Ne retournez pas le produit au magasin.
XR-85X93L 85X93CL 75X93L / /
XR-75X93CL 65X93L 65X93CL / /
Read this manual before using this product
https://www.sony.com/tvsupport
https://www.sony.ca/support
Call the telephone number that appears
on your warranty card/policy.
Please do not return the product to the
2 Remove the screws from the rear of the TV.
3 Attach the Wall-Mount Bracket (not
supplied) using the screws (not supplied).
•If using an electric screwdriver, set the
torque at approximately 1.5 N·m {15 kgf·cm}.
Detaching the Table-Top Stand from the TV
To detach the Table-Top Stand from the TV,
•Be careful when lifting the TV as the
Table-Top Stand is detached, the Table-Top
Stand may topple over and cause personal
•Take care when removing the Table-Top
Stand from the TV to prevent it from falling
over and damaging the surface that the TV
•Do not remove the Table-Top Stand for any
reason other than to install corresponding
•Be sure the TV is vertical before turning on.
To avoid uneven picture uniformity do not
power on the TV with the LCD panel facing
•When attaching the Table-Top Stand again,
be sure to fasten the screws (previously
removed) to the original holes on the rear
General troubleshooting for issues like: black
screen, no sound, frozen picture, TV does not
respond, or network is lost, do the following
1 Restart your TV by pressing the power
button on the remote control for about five
seconds. The TV will restart. If the TV does
not recover, try unplugging the AC power
cord then press the power button on the TV
and release it. Wait for two minutes, and
plug in the AC power cord.
Or, press the power button on the TV for
about 40 seconds until the TV turns off.
2 Refer to the Help menu shown below.
3 Connect your TV to the Internet and
perform a software update. Sony
recommends you to keep your TV software
updated. Software updates provide new
features and performance improvements.
4 Visit Sony support website (information
provided at the end of each language).
5 Perform the factory data reset.
When you plug in the TV, the TV may not
be able to turn on for a while even if you
press the power button on the remote
It takes time to initialize the system. Wait for
about one minute, then operate it again.
How to reset the TV to factory settings
WARNING: The reset will clear all of your
customized settings including the parental
•You can reset the TV to factory settings by
selecting [Factory data reset]. How to select
[Factory data reset], refer to the online Help
•To force factory data reset, unplug the AC
power cord. Press and hold
TV, then plug in the AC power cord.
•For security purposes, be sure to remove all
personal and account information before
discarding, selling or passing your TV to
someone else by: unlinking/unregistering,
signing out of and deactivating all network
services as well as factory reset the TV.
The remote control does not function.
The parental lock password has been
•Enter 4357 for the PIN and enter the new PIN.
For more information, refer
remote control and select
[Help]. If [Help] does not
exist, select [Edit] and add
NTSC: National Television System Committee
NEXTGEN TV: ATSC 3.0 compliant (Single
QAM on cable: ANSI/SCTE 07 2000 (Does not
include CableCARD functionality)
Depending on your country/area selection/TV
Analog terrestrial: 2 - 69 / Digital terrestrial:
Analog Cable: 1 - 135 / Digital Cable: 1 - 135
LCD (Liquid Crystal Display) Panel, LED
10 + 10 + 10 + 10 + 10 + 10
Protocol IEEE 802.11a/b/g/n/ac
75 ohm external terminal for RF inputs
HDMI IN 1/2/3/4 (HDCP 2.3-compatible)
2160p (24, 30 Hz), 1080p (24, 30, 60, 120 Hz),
1080i (60 Hz), 720p (24, 30, 60 Hz), 480p,
In eARC (Enhanced Audio Return Channel)
Refer to the online Help Guide for details.
5.1 channel linear PCM: 32/44.1/48/88.2/96/
176.4/192 kHz 16/20/24 bits, Dolby Audio,
eARC/ARC (Enhanced Audio Return Channel/
Audio Return Channel) (HDMI IN 3 only)*
Refer to the online Help Guide for details.
Two channel linear PCM: 48 kHz 16 bits,
Dolby Audio, Dolby Atmos, DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio, DTS)
USB port 1 supports High Speed USB
USB port 2 supports Super Speed USB
10BASE-T/100BASE-TX connector
(Depending on the operating environment
of the network, connection speed may differ.
The communication rate and quality are not
Home Network supported files and formats*
RS-232C mini jack, IR IN mini jack
These jacks are for receiving the external
110 V - 240 V AC, 50/60 Hz (U.S.A./Canada
XR-85X93L 85X93CL / : 495
XR-75X93L 75X93CL / : 412
XR-65X93L 65X93CL / : 359
Less than 0.5 W with 120 V AC and less than
Screen size (measured diagonally) (Approx.)
XR-85X93L 85X93CL / : 214.8 / 84.6 (85”class)
XR-75X93L 75X93CL / : 189.3 / 74.5 (75”class)
XR-65X93L 65X93CL / : 163.9 / 64.5 (65”class)
Display resolution (horizontal × vertical)
500 mA (for USB 1), 900 mA (for USB 2)
Wall-Mount Bracket: SU-WL855 XR-65X93L / (
Camera and Microphone Unit: CMU-BC1
0 ºC – 40 ºC / 32 ºF – 104 ºF
*1 Only for limited region/country/model.
*2 2 – 36 for NEXTGEN TV scanning range in
*3 When 4096 × 2160p is input and [Wide
mode] is set to [Normal], the resolution
is displayed as 3840 × 2160p. To display
4096 × 2160p, set [Wide mode] setting to
*4 Refer to the on screen menu to set [HDMI
*5 Refer to the online Help Guide for details.
*6 HDMI IN 3 and 4 only. Use the Ultra High
Speed HDMI Cable to connect.
*7 Connect your audio system to the HDMI IN 3
to route TV audio to your audio system.
*8 Specified standby power is reached
after the TV finishes necessary internal
*9 Standby power consumption will increase
when your TV is connected to the network.
•Optional accessories availability depends on
countries/region/TV model/stock.
•Design and specifications are subject to
•Subscriptions for services and applications
may be required and additional terms,
conditions and/or charges may apply when
•Power consumption will increase when
the built-in MIC is enabled as it is always
•Visit Sony website for more information on
•Dolby, Dolby Vision, Dolby Atmos, Dolby
Audio, and the double-D symbol are
trademarks of Dolby Laboratories Licensing
Corporation. Manufactured under license
from Dolby Laboratories. Confidential
unpublished works. Copyright © 1992-2022
Dolby Laboratories. All rights reserved.
•Gracenote, the Gracenote logo and logotype,
“Powered by Gracenote” logo are either
registered trademarks or trademarks of
Gracenote, Inc. in the United States and/or
•For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc.
DTS, Digital Surround, and the DTS logo are
registered trademarks or trademarks of DTS,
Inc. in the United States and other countries.
© 2020 DTS, Inc. ALL RIGHTS RESERVED.
•TUXERA is a registered trademark of
Tuxera Inc. in the US and other countries.
Be sure to register your TV.
La forme de la télécommande,
l’agencement, la disponibilité et la fonction
des touches de la télécommande peuvent
varier selon votre région ou pays ou le
modèle/réglages du téléviseur.*
Affiche la liste des canaux de
télévision ou commute sur l’entrée.
(Réglages rapides) : Affiche
(Entrée) : Permet d’afficher et de
sélectionner la source d’entrée, etc.
(Menu Contrôle) : Affiche le
/ / / / : Navigation et
sélection dans le menu à l’écran.
(Assistant Google / Micro) : Utilisez
(Tableau de bord) : Affichez le
(Guide) : Affiche le guide des
programmes numériques du téléviseur
ou du Syntoniseur câble/satellite*
*1 Le rétroéclairage de la télécommande
s’allume quand le capteur de lumière
détecte que la lumière ambiante est
faible. L’éclairage automatique du
rétroéclairage peut être désactivé.
*2 RMF-TX910U uniquement. Pour connaître
le nom du modèle de la télécommande,
ouvrez le couvercle de la télécommande
et consultez l’étiquette sur la
*3 L’avertisseur émet un son lorsque vous
utilisez la fonction de recherche de la
télécommande. Veuillez vous référer au
Manuel d’aide en ligne pour plus de
*4 Pour les autres modèles de
télécommande, veuillez vous référer au
Manuel d’aide en ligne pour plus de
*5 Uniquement pour certaines régions/
*6 L’Assistant Google nécessite une
*7 Le raccourci d’accessibilité est disponible
*8 Le réglage [Configuration d’un
syntoniseur câble ou satellite] est
•Des instructions pour « Fixer le téléviseur au
mur » sont incluses dans le mode d’emploi
•Lisez la documentation de sécurité fournie
pour plus de renseignements sur l’utilisation
Emplacement de l’étiquette d’identification
Les étiquettes indiquant le numéro de modèle
et les caractéristiques nominales de
l’alimentation du téléviseur se trouvent à
l’arrière du téléviseur. Vous pouvez les trouver
en retirant le couvercle des terminaux.
Les numéros de modèle et de série sont
indiqués à l’arrière et/ou sur le côté du
téléviseur. Inscrivez ces numéros dans les
espaces ci-dessous. Faites-y référence
chaque fois que vous appelez votre
détaillant Sony au sujet de ce téléviseur.
Avis pour les clients aux États-Unis d’Amérique
Déclaration de conformité du fournisseur
Appellation commerciale : SONY
Modèle : XR-85X93L XR-85X93CL / /
XR-75X93L / XR-75X93CL XR-65X93L / /
Partie responsable : Sony Electronics Inc.
Adresse : 16535 Via Esprillo, San Diego,
Numéro de téléphone : 858-942-2230
Information sur le support de fixation murale
Utilisez le support de fixation murale Sony
ci-dessous correspondant au modèle de votre
L’utilisation d’autres supports de fixation
peut provoquer l’instabilité de
l’appareil et causer des blessures ou des
*1 Uniquement pour certaines régions/pays/
*2 Pour des instructions sur l’utilisation du
support de fixation murale avec votre
téléviseur, veuillez accéder à la page du
site https://www.sony.com/am/support
correspondant au modèle de votre
téléviseur et télécharger le document
« Support de fixation murale ».
À l’attention des clients
L’installation de ce téléviseur nécessite
une certaine compétence. Veillez à confier
l’installation à un détaillant Sony ou à un
entrepreneur autorisé et portez une attention
particulière à la sécurité pendant l’installation.
Dimensions and weight (without Table-Top Stand) / Dimensions et poids (sans support de table)
Dimensions and weight (Table-Top Stand) / Dimensions et poids (support de table)
The length of the screw for Wall-Mount Bracket differs depending on the Wall-Mount Bracket thickness / La longueur des vis pour le support de
fixation murale diffère selon l’épaisseur du support de fixation murale
1 2 3 1 2 3
