Side 1/2
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
DIMENSIONS
FEATURES
Intensifier T® Series HD-TVI 1080p 2MP Turret Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HTINT60TM – 2.8~12mm motorized zoom
motorized zoom
motorized zoom
motorized zoom motorized zoom focus
focus
focus
focus focus lens, dark gray housing
lens, dark gray housing
lens, dark gray housing
lens, dark gray housinglens, dark gray housing
HTINT601TA – 3.6mm lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/3” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-up X32)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 150mA (DC), 2W (AC)
Operating Temperature.... -4 F – 122 F ° °
Unit Dimensions.............. 4.58” (H) x 5.49” (Dia.)
Unit Weight...................... 1.54 lbs
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built-in heater and anti-fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Full OSD operation through on-board control and UTC (up the coax)
• Additional 960H analog output
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
Side View
Front View Optional Accessories
CVCJBD1
(Junction Box)
INTWM1
(Wall Mount)
Unit : inch
OSD ACCESS
PRESET MODE
•OUTDOOR •INDOOR•LOW LIGHT •LOBBY
•HALLWAY •ELEVATOR
MAIN SETUP
EXPOSURE
•B/W •EXTERN
• • •LOW MIDDLE HIGH
• • •SHARPNESS GAMMA MIRROR •FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
•BRIGHTNESS •SHUTTER
BACKLIGHT
•HLC•BLC
•WDR
•AUTO
• •AWB COLOR GAIN
• •ACE DEFOG
SYSTEM
•OUTPUT •FREQ. •IMAGE RANGE
•INTENSIFY •AGC
•COLOR
•SHADING
IRIS
MOTION
•FRAME RATE
•LANGUAGE•COLOR BAR •RESET•CAM TITLE
•D-ZOOM
•PRIVACY
2-MOTOR
•COLOR SPACE
•COM.
OSD Joystick
Video Test
INTCM1
(Pole/Corner Mount)
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without
notice and without incurring any obligation. Rev. 220210
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
OSD MENU Details
Intensifier T® Series HD-TVI 1080p 2MP Turret Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HTINT60TM – 2.8~12mm motorized
motorized
motorized
motorized motorized zoom focus l
zoom focus l
zoom focus l
zoom focus lzoom focus lens, dark gray housing
ens, dark gray housing
ens, dark gray housing
ens, dark gray housingens, dark gray housing
HTINT601TA – 3.6mm lens, dark gray housing
DAY / NIGHT : Adjust Day / Night options.
COLOR : Always Color mode, Default value for these cameras
B/W : Always B/W mode.
- ANTI-SAT. : Adjusts the Anti Saturation level (0~20)
EXT : please do not use this mode for these cameras
AUTO : Day / Night is switching automatically by AGC level.
- ANTI-SAT. : Adjusts the Anti Saturation level (0~20)
- AGC THRES : Adjusts AGC THRES (0~20)
- AGC MARGIN : Adjusts AGC margin (0~20)
- DELAY : Adjusts the changing delay time (LOW/MIDDLE/HIGH)
COLOR : Adjusts white balancing options.
AWB : it goes to optimized color level automatically.
COLOR GAIN : Sets the desired Color Gain value (0~20)
SPECO DNR : Uses to reduce the background noise in a low luminance
environment with 2D + 3D filtering system.
BACKLIGHT : Adjusts backlight options.
WDR : WDR illuminates darker areas of an image while retaining the
same light level for brighter areas to even out the overall brightness
of images with high contrast between bright and dark area
- Adjusts the WDR Weight (LOW/MIDDLE/HIGH)
* CVBS out cannot adjust this function.
BLC : Produces a clearer image of an object darkened by strong backlighting.
- H-POS : Adjusts the horizontal position(0~20)
- V-POS : Adjusts the Vertical position(0~20)
- H-SIZE : Adjusts the horizontal block size (0~20)
- V-SIZE : Adjusts the vertical block size (0~20)
HLC : Uses to contain extremely bright areas such as from car headlight,
the light can be masked out much of the on-screen details.
IMAGE : Adjusts various image options.
SHARPNESS: Adjusts sharpness level. Increasing this value, the picture
outline becomes stronger and clear. (0~10)
GAMMA : Sets the desired Gamma value. (0.45 ~ 0.75)
MIRROR : Change the video direction horizontally.
FLIP: Change the video direction perpendicularly.
ACE (D-WDR) : Uses a digital wide dynamic range to balance dark and over
saturated areas within the image.
DEFOG : Activated this mode when the video or the weather is foggy.
PRIVACY : Used to hide regions of the image.
MOTION : Adjust motion detection settings.
DET WINDOW
DET TONE
MDRECT FILL
SENSITIVITY : Sets the desired of “Motion” (0~20)
MOTION OSD
TEXT ALARM
SIGNAL OUT
SYSTEM : Adjusts various camera system options.
OUTPUT
MAIN OUTPUT ANALOG OUT0
ANALOG OUT0 TVI
Y GAIN
CB GAIN
CR GAIN
FRAME RATE: 1080P 30 / 720P 60
FREQ 60Hz
COM.
IMAGE RANGE
COLOR SPACE
COLOR BAR : Manufacturer’s option
LANGUAGE : Sets the desired OSD language
CAM TITLE
RESET: Press with long to reset all settings to factory defaults.
IRIS : ‘ALC’ for HTINT60TM, ‘ELC’ for HTINT601TA as a default value
2-MOTOR : AF Mode, Scanning, OnepushAF, Sync TDN, Initial
EXPOSURE : adjusts exposure settings.
BRIGHTNESS : Adjusts image brightness. (0~ 20)
SHUTTER : Outdoor / Indoor / Deblur
INTENSIFY : Sets the desired multiple of the digital exposure length.
AGC(Auto Gain Control): Adjusts the AGC level. (0~10)
