6” Pendant Mount Speaker with Optional Ground or Wall Mount

Thank you for your choice of Speco Technologies’ combination speaker. This unit is designed and manufactured to SP6P

provide an extremely versatile solution for background music and paging. Out of the box, the SP6P is a pendant speaker. With

the optional mounting kits, the speaker can also be mounted on a wall or in the ground as a landscape speaker.

SPEAKER FEATURES:

1) Transformer Dial to determine speaker power (Only on SP6PTB and SP6PTW). Use a flat-edged screwdriver and turn until the left

end of the groove points towards the power value you desire. Options are 32W, 16W, 8W, 4W, and 8 Ohms. For all settings but 8

Ohms use a 70 or 25V amplifier (depending on what you set #3 to). For 8 Ohms, use an 8 Ohms amplifier.

2) Socket for pendant mount eye-bolt. Eye-bolt should be inserted through Speaker Top A described below.

3) Transformer selection switch (Only on SP6PTB and SP6PTW). Alternate between 70V and 25V. This switch should never be used

while speaker is live on an amplifier. Connecting the speaker to the wrong amplifier could damage your speaker or amplifier.

4) Speaker terminal (phoenix connector). Use this to connect to your amplifier and to another speaker. Please consult an expert if you

are not familiar with proper wiring practices.

5) Landscape/Wall-mount wire channel. Insert speaker wire under metal bar to fortify installation.

INSTALLATION INSTRUCTIONS:

1) All speaker adjustments must be made either before connection to amplifier or while amplifier is off to avoid potential damage to

equipment.

2) If you have the SP6PTB or SP6PTW, select first which voltage you are using via the switch described in #3 above. Then, select the

speaker wattage you want via the dial described in #1 above.

3) If you have the SP6PB or SP6PW, no adjustments are necessary.

4) There are two speaker tops that come in your package. The

difference is easily identifiable as one will have a built-in screw

(B), and one has two openings (A). (Pictured right)

5) Top A is the top you will use if you did not purchase the

optional mounting kit and wish to pendant mount the speaker.

To install with top A, you will need to run your speaker wire

through the top prior to connecting to the phoenix connector.

Connect the positive wire running from your amp or adjacent

speaker to one of the (+) terminals on the connector. Connect

the negative wire running from your amp or adjacent speaker

to one of the (-) terminals on the connector. If you are daisy-

chaining 70V/25V speakers, use the second (+) and (-) terminals

to connect to that speaker and repeat. (Pictured following

page)

6) Place the phoenix connector into the cradle on the top of the speaker. Make sure it’s firmly connected.

7) Line up top A so that the notch on the top meets the cutout on the speaker. (Pictured below)

8) The pendant mount eye-bolt will come with a nut and locking washer . Tighten the nut to the top and place the (Pictured below)

washer underneath.

9) Place the eye-bolt in the hole in the center of top A and screw all the way until you meet resistance. Tighten carefully at that point

until you can no longer tighten the bolt. Your speaker is ready to hang. Be sure the chain running to the building (Pictured below)

structure is strong enough to support the speaker and securely fastened.
