Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 13, 2024
Product ID
4P-SATA-M2-ADAPTER
Top View
Component Function
1SATA Drive Ports 1 - 4
Supports SATA I/II/III
2LED Indicator
Solid Green: Power On
O: Power O
3M.2 Host Connector
Install the into a on M.2 Adapter M.2 Drive Slot
the Host Computer
Size of the is 2280M.2 Adapter
Compatible with PCIe-based B or M key M.2 slots
Product Information
For the latest product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/4P-SATA-M2-ADAPTER
M.2 to Quad SATA Drive Adapter
Requirements
Computer with M.2 Drive Slot x 1
SATA HDD/SSD x 4
Package Contents
M.2 to Quad SATA Drive Adapter x 1
SATA Cables x 4
Quick-Start Guide x 1
Installation
Install the M.2 to Quad SATA Drive Adapter
Warning: M.2 Adapter Cards can be damaged by static electricity. Ensure that the
Installer is properly grounded before they open the Computer Case or touch the M.2 to
Quad SATA Adapter. The Installer should wear an Anti-Static Strap when installing any
computer component. If an Anti-Static Strap is not available, discharge any built-up
static electricity by touching a large Grounded Metal Surface for several seconds. Only
handle the M.2 Adapter Card by its edges and do not touch the gold connectors.
1. Turn o the and disconnect the and any Computer Power Cable Peripheral Devices
that are connected (e.g. printers, external hard drives, etc.).
2. Remove the from the .Cover Computer Case
Note: Consult the documentation that came with the Computer for details about how
to do this safely.
3. Locate an available on the . If the M.2 Drive Slot Host Computer’s Motherboard M.2
Drive Slot Cover Heatsink Slot Cover/Heatsink has a or , remove the corresponding .
4. Gently insert the into the open . Secure it using a M.2 Adapter M.2 Drive Slot Phillips
Head Screwdriver Screw Step 3 and the that was removed in .
5. Connect a to the using one of the included SATA Drive M.2 Drive Adapter SATA
Cables.
6. Repeat for the remaining . Step 5 SATA Drives
7. Re-install the of the that was removed in . Cover Computer Case Step 2
8. Reconnect the and that were disconnected in Power Cable Peripheral Devices
Step 1.
9. Power on the .Computer
