Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 15, 2023 6:12 PM

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

1U Cantilever Shelf - 7 in. Depth

Warnings!

Review the Quick-Start Guide and ensure all instructions are understood prior to

installation and use.

Assemble this product according to the installation instructions.

If any package contents items are damaged and/or missing, do not attempt

installation. Contact StarTech.com Support immediately.

The weight of any/all added equipment must not exceed the weight capacity of the

product. This product is capable of supporting the following weight:

REV. 01: 33.1 lb (15 kg).

REV. 02 and up: 39.6 lb (18 kg).

Note: The Revision (REV.) Number appears as the fth and sixth digits of the LOT

code, located on the sticker axed to the product and product packaging. If the

sticker is missing, the product is REV. 01.

Failure to comply with these warnings may result in property damage, bodily injury,

and/or damage to the product and/or equipment.

Requirements

For the latest manuals, product information, technical specications, and declarations

of conformance, please visit:

www.StarTech.com/CABSHELF1U

• Phillips Head Screwdriver

• (Optional) Cage Nut Tool

Installation

1. Locate 1U of Mounting Space in a Rack.

2. Install the M6 Cage Nuts (x4) into the Cage Nut Holes (x4), located along the

Mounting Posts of a Rack, using pressure by hand or with a Cage Nut Tool.

Note: If the rack has M6 Threaded Holes, skip this step.

3. Align the Mounting Holes in the Front Mounting Brackets with the M6 Cage

Nuts/M6 Threaded Holes, located in the front of the Rack.

4. Install the M6 Screws (x4) and tighten, using a Phillips Head Screwdriver. Ensure

the M6 Screws (x4) are adequately fastened and the Shelf is secure prior to adding

any Server Rack Equipment.

Product Diagram

CABSHELF1U

Component Function

1 Front Mounting Brackets • Attach the Shelf to the Mounting Posts of a Rack

2 Shelf Surface • Store Server Rack Equipment

3 Rear Lip

• Prevent Server Rack Equipment from sliding o

the rear of the Shelf Surface

Package Contents

• 1U Rack Shelf x1

• M6 Screws x4

• M6 Square Cage Nuts x4

• M6 Plastic Washers x4

• Quick-Start Guide x1

*Product may vary from image

Regulatory Compliance

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.

Warranty Information

This product is backed by a lifetime warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss

of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the

product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the

limitations or exclusions contained in this statement may not apply to you.
