Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 17, 2020 4:13 PM

Product Diagram (CBMMCTTOOL)

Component Function

1 Lever

• Used to remove excess Cable from a Steel

Cable Tie, after it has been tightened.

2 Head

• Used to hold a Steel Cable Tie during the

tightening process.

3 Nose

• Used to align the Steel Cable Tie through the

Head of the Cable Tie Tool.

4 Grippers

• Used to grip a Steel Cable Tie during the

tightening process.

5 Handles

• Used to tighten a Steel Cable Tie during the

tightening process.

Requirements

For the latest requirements, please visit www.startech.com/CBMMCTTOOL

• Steel Cable Tie

• Set of Cables

• Safety Gloves

Using the Cable Tie Tool

It is recommended that you put on a pair of Safety Gloves before handling the Steel

Cable Tie.

Metal Cable Tie Tool

1. Wrap a Steel Cable Tie around a set of cables.

2. Insert the end of the Steel Cable Tie through the Self Locking Head on the Steel

Cable Tie.

3. Pull the end of the Steel Cable Tie to tighten the Steel Cable Tie around the set of

cables.

4. Insert the end of the Steel Cable Tie through the side of the Head of the Cable Tie

Tool so that the Steel Cable Tie is in-between the Nose of the Cable Tie Tool and

feeds out the back of the Head of the Cable Tie Tool in-between the Grippers.

Routing the Steel Cable Tie through the Cable Tie Tool

5. Push the Head of the Cable Tie Tool towards the Self Locking Head on the Steel

Cable Tie.

6. Squeeze the Cable Tie Tool’s Handles together, tightening the Steel Cable Tie

around the set of cables.

Note: You will have to squeeze the Cable Tie Tool’s Handles several times in order

to tighten the Steel Cable Tie around the set of cables.

7. When you have reached the maximum tension. Use the Lever to remove the excess

Steel Cable Tie.

Note: Be careful not to over-tighten the Steel Cable Tie, as you may damage the set

of cables.

Cable Tie

Notch

Cable Tie

Notch

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	CBMMCTTOOL
Bredde:	210 mm
Dybde:	155 mm
Højde:	40 mm
Vægt:	615 g
Produktfarve:	Sort
Pakkevægt:	620 g
Pakkedybde:	132 mm
Pakkebredde:	215 mm
Pakkehøjde:	46 mm
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	455 mm
Hovedkassens længde (udvendigt):	278 mm
Hovedkassens bredde (udvendigt):	250 mm
Produkter pr. hovedkasse (udvendigt):	20 stk
Velegnet til materialer:	Rustfrit stål
Skærebreddeområde:	4.6 - 7.9 mm
