Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

I T: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

P T: Guia do usuário - pt.startech.com

Manual Revision: 02/05/2015

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x 2U Horizontal Cable Manager (for CMPNL2U) or 1 x 2U Combo

Cable Manager (for CMPNL2Uxx)

• 24 x Cable Clamps

• 4 x 5/8” #10-32 UNF Screws

• 4 x #10-32 UNF Cage Nuts

• 4 x 5/8” #12-24 UNC Screws

• 4 x #12-24 UNC Cage Nuts

System Requirements

• 2U of Rack Space

CMPNL2Uxx

2U Finger Duct and D-Ring Hook Rack Cable Manager

Product Diagram

CMPNL2U

CMPNL2UC

Installation

1. Determine the location on the rack where you want to install the

cable manager; an open 2U space is required.

2. Depending on the rack type, insert the four provided #10-32

or #12-24 cage nuts on opposite posts at equal height levels/

positions.

3. Align the cable manager mounting points with the cage nuts on

the rack.

4. Using the four provided #10-32 or #12-24 screws and a

screwdriver, secure the cable manager to the rack.

5. Insert the provided Cable Clamps into the front Cable Clamp

mounting points as desired.

6. Insert and organize your cables as desired.

Mounting Point

Horizontal

D-Ring Hook

Cable Clamp

Mounting Point (x24)

Mounting Point

Vertical

D-Ring Hook

Horizontal

D-Ring Hook

Cable Clamp

Mounting Point (x24)

Mounting Point

CMPNL2UCD

Mounting Point

Vertical

D-Ring Hook

Horizontal

D-Ring Hook

Cable Clamp

Mounting Point (x24)

Mounting Point

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

CMPNL2UC

U Height 2U

Color Black

Enclosure Type Steel

Dimensions (WxDxH) 20.31 x 4.01 x 3.46 in

(516 x 102 x 88 mm)

Product Weight 1540 g (54.36 oz)

Specications

CMPNL2U

U Height 2U

Color Black

Enclosure Type Steel
