ECESATA254

2 Port eSATA ExpressCard 54mm Card

Introduction

Thank you for purchasing a StarTech.com 2 Port eSATA ExpressCard 54mm Card.

Offering a simple connection from your notebook computer to eSATA (external

SATA) storage, ECESATA254 provides two eSATA ports and features port multi-

plier support with FIS based switching, allowing multiple eSATA hard drives to be

accessed using a single eSATA port.

Features

Compliant with ExpressCard/54mm standard•

Compatible with PCI Express 1-lane (x1)•

Compliant with Serial ATA 1.0 speciﬁcations•

Supports Native Command Queuing (NCQ) hard drives•

Works with SATA I/II devices with transfer speeds up to 3.0 Gbps•

Package Contents

1 x Driver CD•

1 x eSATA ExpressCard •

1 x User’s Manual•

System Requirements

Pentium® or equivalent notebook with an available Type II PC Card slot•

Windows® 2000 SP4/XP SP1/Server 2003/Vista™ •

Speciﬁcations

Hardware Installation

Insert the controller card into an empty ExpressCard/54mm slot. This can be 1.

performed while the computer is powered on or off.

The operating system will detect the card and request the software driver. Insert 2.

the into the CD/DVD-ROM.Drivers & Utility CD

Direct the installation wizard to 3. , (where x:/Silicon_Image/SIL3132/Windows x:

designates the location of the CD/DVD-ROM drive) and click .OK

Click 4. to continue the installation and follow the on-screen instructions until Next

driver installation has completed.

Connect the external SATA/SATA II device(s) using eSATA cable(s) to the output 5.

ports of the controller card. (Please see StarTech.com ESATA3, ESATA6)

As necessary, conﬁgure the (eSATA connected) drive(s) partitions and format 6.

accordingly.

Verifying Successful Installation

Right-click on the 1. icon and choose My Computer Properties.

In the left pane of the 2. window, select Computer Management Device Manager.

In the right pane of the 3. window, click on the “ ” sign Computer Management +

next to . SCSI and RAID controllers

Right-click on the 4. Silicon Image SiI 3132 SATALink controller listed here and

choose .Properties

Check the 5. in the Device status General window. Here, you should see a

message indicating that “This device is working properly”.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver •

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowl-

edges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective

holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-ment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may

be returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ofﬁcers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some

states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Bus Type

ExpressCard 54mm

Chipset

Silicon Image Sil3132

Maximum Data Transfer Rate

3 Gbps

OS Support

Windows® XP, Vista™

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	ECESATA254
Bredde:	59.5 mm
Dybde:	113 mm
Højde:	16 mm
Vægt:	40 g
Produktfarve:	Flerfarvet
Forbindelsesteknologi:	Trådløs
Certificering:	ROHS, CE
Mac kompabilitet:	Ingen
Kompatible operativsystemer:	Windows XP, Vista
Værtsgrænseflade:	ExpressCard
Antal udvendige papkasser:	50 stk
I/O-porte:	2x eSATA
Dataoverførselshastighed:	3000 Mbit/s
Antal eSATA-porte:	2
Chipsæt:	Silicon Image SIl3132
