Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: October 7, 2019

Product Diagram (MCM10GSFP)

Front View:

Port/LED Function

1 SFP+ Media ConverterSFP+ Slot • Connect an to the .

2LEDs

• Link

• Solid Green: Link speed of 10G

• Power

• Solid Green: is receiving power.Media Converter

3RJ45 Port

• Connect an to the Ethernet Network Device Media

Converter.

Note: The LED Indicators on the RJ45 port are inactive.

Rear View:

10GbE Fiber Media Converter | Open SFP+ Slot

Port/LED Function

45V DC Port

• Connect the to power the Universal Power Adapter

Media Converter.

Requirements

For the latest requirements, please visit .www.startech.com/MCM10GSFP

Installing the Media Converter

Connecting the Media Converter

1. Turn o the that will be connected to the Networking Equipment Media

Converter.

2. Remove the from the .Dust Cover SFP+ Slot

3. Insert an MSA-compliant 10GbE SFP+ module (sold separately) into the SFP+ Slot

on the Media Converter.

Note: The can only be used with 10GbE SFP+ Module.Media Converter

4. Remove the from the .Dust Cover SFP+ Module

5. Connect a (sold separately) to the on the Fiber-Optic Cable Fiber-Optic Ports SFP+

Module.

6. Connect the other end of the to the . Fiber-Optic Cable Fiber-Network Device

Note: For , the TX and RX connectors must be paired at Duplex Fiber Optic Cables

both ends of the connection. For example TX to RX, and RX to TX.

7. Connect a (sold separately) to the on the Cat 6/6a Cable RJ45 Port Media

Converter.

8. Connect the other end of the to the .Cat 6/6a Cable Ethernet Network Device

Powering the Media Converter

1. Connect the to the on the .Universal Power Adapter 5V DC Port Media Converter

2. Connect the other end of the to an . Universal Power Adapter AC Electrical Outlet

The (power) should light up solid green.PWR LED

3. Turn the from step #1 back on. Networking Equipment

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

4. Rotate the clockwise until you hear an audible click indicating that the Power Clip

Power Clip Power Adapter is properly attached to the .

Removing the Power Adapter Clip

• While pressing the button turn the counter-clockwise until the Release Power Clip

Power Clip is released.

Note: Check the link budget of your SFP+ modules, as well as the module’s intended

wiring distance. SFP+ modules are designed to transmit signals over large distances. If

the physical wiring distance is too short, the transmitting optical signal (laser) may be

too strong and damage the receiving SFP+ module. An in-line optical attenuator may

be required to protect it from damage.

Warning: There may be a delay (up to 10 seconds) establishing a network connection

when connecting the to a . Media Converter Network Device

Duplex Mode Support

The supports 10G and will automatically negotiate the Media Converter’s RJ45 Port

connection type. By default, it will automatically detect the link speed and the duplex

mode of your connected equipment.

The (10GBase-LR/SR) allows 10G full duplex Media Converter’s Fiber-Optic Port

auto-negotiation. Check to ensure the duplex setting of the connected ber equipment

matches the duplex setting of the .Media Converter

Distance Capabilities

The distance capabilities of the are variable and depend on the Media Converter SFP+

Module Fiber-Optic Cable and the used.

Installing the Power Adapter Clip

1. Remove the from the box.Power Adapter

2. Locate the specic to your region (e.g. U.S.).Power Clip

3. Align the on the with the on the so that the Tabs Power Clip Slots Power Adapter

Contact Prongs Power Adapter on the are vertical (one above the other).

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	MCM10GSFP
Bredde:	80 mm
Dybde:	122 mm
Højde:	30 mm
Vægt:	274 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	350 g
Pakkedybde:	207 mm
Pakkebredde:	144 mm
Pakkehøjde:	38 mm
Opbevaringstemperatur (T-T):	-40 - 120 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 70 °C
Ethernet LAN-datahastigheder:	10,100,1000,1200,2500,5000,10000 Mbit/s
Husmateriale:	Aluminium
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC, UL, PSE
Netværksstandarder:	IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an
LED-indikatorer:	Link, Power
Udgangsspænding:	5 V
Udgangsstrøm:	2 A
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85176990
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	320 mm
Hovedkassens længde (udvendigt):	550 mm
Hovedkassens bredde (udvendigt):	320 mm
Intern:	Ingen
Maksimal dataoverførselshastighed:	10000 Mbit/s
Indgangsstrøm:	250 A
Fiber optisk strømstik:	SFP+
Maksimal overførselsafstand:	- m
Bølgelængde:	- nm
Ekstern strømadapter:	Ja
Produkter pr. hovedkasse (udvendigt):	20 stk
Strøm over Ethernet (PoE):	Ingen
Ethernet-grænsefladetype:	10 Gigabit Ethernet
Strømstiktype:	Type M
Auto MDI/MDI-X:	Ja
Fiber ethernet kabelteknologi:	10GBASE-LR, 10GBASE-SR
Jumbo Frames support:	Ja
Jumbo rammer:	9000
Auto-forhandling:	Ja
Fiberkanal porte:	1
Fibertilstandsstruktur:	Multi-mode, Single-mode
