Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 02/10/2012

For the most up-to-date information, please visit: www.startech.com

MCM110SC2 / MCM110SC2GB / MCM110SC2EU

MCM110ST2 / MCM110ST2GB / MCM110ST2EU

10/100 Ethernet to Multi Mode Fiber Media Converter SC 2km

*actual product may vary from photos

Packaging Contents

• Fiber/Ethernetmediaconverter

• PowerAdapter

• InstructionManual

System Requirements

• 10/100Base-TXcompatibleEthernetnetwork

• 100Base-FXbernetwork

• SCmulti-modebercable

• AvailableACelectricaloutlet

Installation

1. ConnecttheEthernetcabletotheFiberMediaConverter“LAN”port.

2. ConnecttheotherendoftheEthernetcabletotherouter/switch/

computerNIC.

3. Connectthebercableintotheberreceptacleonthemediaconverter.

4. Plugtheprovidedpoweradapterintothemediaconverter,and

intoanavailableACpoweroutlet.

5. Connecttheotherendofthebercableintotherouter/switch/

computerNIC/anothermediaconverter.Remembertoreverse

theTXandRXleadsbetweenthetwodevices.

DIP Switch Settings

Switch Function State Status

SW1 UTPMode

Auto AutoUTPdetection

Manual UsemanualUTPsettings

SW2* UTPSpeed

100 100Mbpslinkspeed

10 10Mbpslinkspeed

SW3* UTPDuplex

Full Fullduplex

Half Halfduplex

SW4

LinkFaultPass-

through

LFP LFPmodeo

ON LFPmodeon

*not enabled when SW1 set to ‘Auto’

LED Indicators

LED Function State Status

PWR

Power

Indicator

ON Converterhaspower

OFF

Converterhasno

power

FXLink/Act

FiberLink/

Activity

ON FiberlinkOK

OFF Nolinkdetected

Flashing Receivingdata

FEF FarEndFault

ON Farendlinkfailure

OFF Nofailuredetected

100 Mode

ON 100Mbps

OFF 10Mbps

Full DuplexMode

ON Fullduplexmode

OFF Halfduplexmode

TXLink/Act

EthernetLink/

Activity

Ethernetlink

detected

OFF Nolinkdetected

Flashing Receivingdata

*MCM110ST2 shown

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

MCM110SC2 MCM110ST2

Connectors

1xRJ45Ethernet

2xSCFiber

1xpowerconnector

1xRJ45Ethernet

2xSTFiber

1xpowerconnector

LEDs Power,FiberLink/Activity,EthernetLink/Activity,10/100,Full/HalfDuplex,FEF

Fiber Type Multi-Mode(62.5or50/125micron)

Optical Wavelength 1310nm

Maximum Distance 2km

Transmission Standards IEEE802.310BASE-T,IEEE802.3u100BASE-TX,l00BASE-FX

Duplex Modes

Full/HalfDuplex(Ethernet)

FullDuplex(Fiber)

Power Adapter 12VDC,200mA,centerpositive,typeMplug

Enclosure Material Plastic

Operating Temperature 0°C~50°C(32°F~122°F)

Storage Temperature -10°C~70°C(14°F~158°F)

Humidity 10%~90%RH

Dimensions 95.0mmx7

Weight 90.5

*MCM110SC2 shown

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	MCM110ST2EU
Bredde:	75 mm
Dybde:	95 mm
Højde:	20 mm
Vægt:	90.5 g
Pakkevægt:	300 g
Pakkedybde:	175 mm
Pakkebredde:	145 mm
Pakkehøjde:	65 mm
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 50 °C
Netværksstandarder:	IEEE 802.3, IEEE 802.3u
Udgangsstrøm:	0.2 A
Harmoniseret systemkode (HS):	85176990
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	240 V
Maksimal dataoverførselshastighed:	100 Mbit/s
SFP modtagertype:	Fiberoptisk
Fiber optisk strømstik:	ST
Maksimal overførselsafstand:	2000 m
Bølgelængde:	1310 nm
Maksimal spænding:	12 V
Kabeltype:	Fiberoptisk
Strøm (maks.):	0.2 A
Duplex system:	Full, Half
