Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 02/07/2012

For the most up-to-date information, please visit: www.startech.com

MCMGBSC15 / MCMGBSC15GB / MCMGBSC15EU

1000 Mbps Gigabit Single-Mode Fiber Ethernet Media Converter

*actual product may vary from photos

Packaging Contents

• 1xMCMGBSC15/GB/EUmediaconverter

• 1xPowerAdapter

• 1xInstallationGuide

System Requirements

• Gigabit(1000Mb/s)Ethernetnetwork

• Gigabit(1000Mb/s)Fibernetwork

LED Indicators

LED Status Description

PWR

ON PowerOn

OFF PowerO

FX LINK

ON FiberLinkDetected

OFF NoFiberLinkDetected

LINK

ON EthernetLinkDetected

OFF NoEthernetLinkDetected

ON UnitisreceivingdatafromEthernetport

OFF NoincomingdatafromEthernetport

RJ45Ethernetport

SCFiberport

LED

indicators

DCpowerport

Modeswitch

Front View

Rear View

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

Connectors

1xRJ45Ethernet

2xSCFiber

1xPowerconnector

LEDs

Power,FiberLink,FiberReceive,Ethernet

Link

Fiber Type SingleMode9/125micron

Maximum Distance 15km

Transmission

Standards

IEEE802.3ab,802.3z,802.3x

Duplex Mode Full/Half(Auto-Detect)

Dimensions 99.0mmx73.0mmx27.0mm

Weight 450g

Installation

1. ConnecttheEthernetcabletotheFiberMediaConverterRJ45

Ethernetport.

2. ConnecttheotherendoftheEthernetcabletotherouter/switch/

computerNIC.

3. Connectthebercableintotheberreceptacleonthemedia

converter.

4. Plugtheprovidedpoweradapterintothemediaconverter,and

intoanavailableACpoweroutlet.

5. Connecttheotherendofthebercableintotherouter/switch/

computerNIC/anothermediaconverter.Remembertoreversethe

TXandRXleadsbetweenthetwodevices.

Installation

The Mode Switch on the rear of the media converter can be

used control the duplex mode on the fiber side of the media

converter.

In most cases, set the Mode Switch to AUTO. If you are

connecting to another media converter FORCE mode may

need to be selected.

Auto Mode:

Auto mode is set by default and the media converter will try

to auto negotiate the fiber link. In some cases, when

connecting to another media converter on the fiber side, both

units set to "Auto" can cause an endless loop and prevent a

link from being established.

Force Mode:

Force is the alternative operating mode. In cases where a link

is not being established, the media converter needs to be

statically set to one mode only. Set the mode switch to FORCE

in these instances (such as when connecting the media

converter to another media converter).

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	MCMGBSC15
Bredde:	73 mm
Dybde:	99 mm
Højde:	27 mm
Vægt:	450 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	500 g
Pakkedybde:	206 mm
Pakkebredde:	165 mm
Pakkehøjde:	65 mm
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Dimensioner (BxDxH):	73 x 99 x 27 mm
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
Kabelteknologi:	1000BASE-LX/LH
Netværksstandarder:	IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3z
DC-in-stik:	Ja
LED-indikatorer:	Link, Power
Udgangsspænding:	9 V
Udgangsstrøm:	0.6 A
AC-adapter inkluderet:	Ja
Effektkrav:	9 VDC
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	100 - 240 V
Maksimal dataoverførselshastighed:	1000 Mbit/s
Indgangsstrøm:	0.3 A
Fiber optisk strømstik:	SC
Maksimal overførselsafstand:	15000 m
Bølgelængde:	1310 nm
Stik:	SC
Ekstern strømadapter:	Ja
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ingen
Strømstiktype:	Type M
Auto MDI/MDI-X:	Ja
Overholdelse af branchestandarder:	IEEE 802.3z
Auto-forhandling:	Ja
Fiberkanal porte:	1
Fibertilstandsstruktur:	Enkeltilstand
Duplex system:	Full, Half
Bølgelængde-division multipleksing (WDM):	Ingen
