Side 1/3

3 ft Mini DisplayPort™ to DVI Active Adapter Converter Cable – mDP to DVI 2560x1600 – Black

StarTech ID: MDP2DVIMM3BS

The MDP2DVIMM3BS 3ft active Mini DisplayPort to DVI adapter cable lets you directly connect your Mini DP video

source (Laptop, Macbook®, Ultrabook™ etc.) directly to a nearby DVI monitor or projector, saving the expense of

additional adapters while eliminating the clutter of excess cable.

For guaranteed compatibility with virtually any Mini DisplayPort output the active Mini DP to DVI adapter supports

multimode (DP++) as well as single-mode DisplayPort signals. Unlike passive adapters, this ensures the

MDP2DVIMM3BS can be used with graphics cards that are not capable of outputting multimode DP++ signals,

such as ATI® Eyefinity cards.

Compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt™ I/O

port, the adapter supports resolutions up to 2560x1600.

The MDP2DVIMM3BS is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Applications

Use with single-mode Mini DisplayPort video outputs that are not capable of outputting multimode DP++

signals, such as ATI® Eyefinity video cards

Connect your DVI display device (monitor, projector) directly to a Mini DisplayPort output device

Ideal for using your DVI monitor as a secondary display

www.startech.com

1 800 265 1844

Features

Active Mini DisplayPort to DVI conversion

1x Male DisplayPort connector, 1x Male DVI connector

Compatible with Intel® Thunderbolt™ devices that are capable of outputting a DisplayPort signal

Supports resolutions up to 2560x1600 and HDTV resolutions up to 1080p

Plug-and-play Installation

Technical Specifications

Warranty 2 Years

Adapter Style Cable Adapter

Audio No

Chipset ID PS171A

Converter Type Active

Connector A 1 - Mini-DisplayPort (20 pin) Male

Connector B 1 - DVI-D (25 pin) Male

Maximum Cable Length 3 ft [0.9 m]

Maximum Digital Resolutions 2560x1600 (Dual link)

Supported Resolutions 2560x1600

1920x1200

1920x1080

Wide Screen Supported Yes

Cable Length 3 ft [0.9 m]

Color Black

Product Height 0.6 in [15 mm]

Product Length 36.2 in [920 mm]

Product Weight 3.3 oz [93.2 g]

Product Width 1.6 in [40 mm]

Humidity 40%-85%RH

Operating Temperature 0°C to 60°C (32°F to 140°F)

Storage Temperature -10°C to 70°C (14°F to 158°F)

Shipping (Package) Weight 3 oz [84 g]

Included in Package 1 - Active DisplayPort to DVI Adapter

www.startech.com

1 800 265 1844

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	MDP2DVIMM3BS
Bredde:	40 mm
Dybde:	920 mm
Højde:	15 mm
Vægt:	82 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	82.2 g
Pakkedybde:	220 mm
Pakkebredde:	200 mm
Pakkehøjde:	15 mm
Understøttede videotilstande:	1080p
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	40 - 85 %
Driftstemperatur (T-T):	0 - 60 °C
Maksimal opløsning:	1920 x 1200 pixel
Understøttede grafikopløsninger:	1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Kabellængde:	0.9 m
Harmoniseret systemkode (HS):	84733080
Bæredygtighedscertifikater:	RoHS, CE
Hovedkassen højde (udvendigt):	435 mm
Hovedkassens længde (udvendigt):	415 mm
Hovedkassens bredde (udvendigt):	420 mm
Plug and play:	Ja
Maksimal opdateringshastighed:	30 Hz
DisplayPort-version:	1.2
Produkter pr. hovedkasse (udvendigt):	180 stk
Stik 1:	Mini DisplayPort
Stik 2:	DVI-D
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stik 1 formfaktor:	Lige
Stik 2 formfaktor:	Lige
DVI dobbelt link:	Ingen
Konverter type:	Aktiv
Chipsæt:	Parade - PS171
