Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 11, 2020

Product Diagram (MONPROTECT)

Rear View

Component Function

1Cable Management

Hole

• Route the and for the Power Video Cables

Display Transparent through this opening in the

VESA Panel

2VESA Mounting Holes

• Insert 4 of the appropriately sized through Screws

the , the , the Washers VESA Mounts Transparent

VESA Panel 5 , the appropriate size and number of

mm 20 mm Spacers Display and/or , and into the

3Transparent VESA

Panel

• Clear acrylic sheet

• Weight - 8.3 lb. (3.76 kg)

• Three mounting heights

• Minimum mounting height (from Mounting

Surface VESA Mountto the middle of the ) - 9.7 in.

(245 mm)

Requirements

For the latest requirements, please visit:

www.startech.com/MONPROTECT

• Clean, Flat, and Stable Surface for Installation

• Display with 75 x 75 mm or 100 x 100 mm Spaced VESA Mounting Holes

Transparent VESA Panel - Single Display

• Monitor Mount with a Single VESA Mounting Point

Consult the for the or contact the of the User Manual Monitor Mount Manufacturer

Monitor Mount Monitor Mount to determine if the can support the combined weight

of the and the . Transparent VESA Panel Display

• Phillips Head Screwdriver

• Two People for Installation and Adjustments

• (Optional - for cleaning) Microber Cloth

Installation

Warnings: Installing the is a two person task. Do not Transparent VESA Panel

attempt to complete the installation with one person.

The additional weight of the may overload the Transparent VESA Panel Monitor

Mount during installation and/or use. Do not exceed the weight capacity of the

Monitor Mount.

(For a Display Already Attached to a Mount) Detach the Display

• Remove the from the .Display Monitor Mount

Note: Refer to the for steps on how to Monitor Mount Manufacturer’s User Manual

remove the from the .Display VESA Mount

Attach the Transparent VESA Panel

Figure 1

Screw

Washer

VESA Mount

20 mm Spacer

5 mm Spacer

VESA Mounting Holes

Display VESA

Mounting Holes

Warning Statements

Make sure that you assemble this product according to the instructions.

Do not exceed the weight capacity of the Monitor Mount used in conjunction with this product.

This product is intended for indoor use only and should not be used outdoors.

This product does not lter UV light and it may amplify the sun’s rays. Exercise caution when using this product close to a

natural light source.

Do not use ammonia-based cleaners to clean this product.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of the Phillips Screw Company in the United States and other countries.

Warranty Information

This product is backed by a ten-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

To accommodate dierent designs, Display MONPROTECT comes with four sets of

Screws that are dierent lengths and diameters:

• M4 x 35mm Screws x 4

• M5 x 35mm Screws x 4

• M4 x 16mm Screws x 4

• M5 x 16mm Screws x 4

To select the that t the , complete the following:Screws Display

• Determine whether the are ush or inset. Inset Display’s VESA Mounting Holes

mounts will require .Spacers

• and/or located ush on the rear of the will require the Power Video Ports Display

use of the .20 mm Spacers

• Determine the appropriate length of required by adding the depth of the Screw

Mounting Holes Display Spacerson the , the length of the appropriate number of ,

and the thickness of the .Transparent VESA Panel

• Determine the appropriate diameter of required by nding the diameter of Screw

the on the . This information may be labeled on the rear Mounting Holes Display

of the . Or, it can be found in the for the .Display User Manual Display

Note: The four sets of (included) may not be compatible with every installation Screws

scenario. Additional (sold separately) may need to be sourced for unique Screws

installations.

1. Remove the from the . Blue Plastic Film Transparent VESA Panel

2. Remove the from the . If the does not VESA Mount Monitor Mount VESA Mount

detach from the , remove the from the Monitor Mount Monitor Mount Mounting

Surface.

Note: Refer to the for steps on how to Monitor Mount Manufacturer’s User Manual

remove the or .VESA Mount Monitor Mount

3. Position the , screen side down, onto a . Display Clean, Flat, and Stable Surface

Tip: The installation should take place close to the intended . This Mounting Location

reduces the distance the must travel with the Two People Transparent VESA Panel

Assembly.

4. Determine if the features or Display 75 x 75 mm 100 x 100 mm Spaced VESA

Mounting Holes.

5. (Optional) Place the necessary number of over the four Spacers Display VESA

Mounting Holes Displayon the rear of the . (Figure 1)

Note: Ensure the correct are being utilized. Display VESA Mounting Holes

6. Determine the desired mounting height of the (low, middle, Transparent VESA Panel

high) and make note of the corresponding . VESA Mounting Holes

7. Lift the over the . Ensure the top of the Transparent VESA Panel Display Transparent

VESA Panel Display is facing in the same direction as the top of the . Lower the

Transparent VESA Panel VESA Mounting Holes while ensuring the selected align

with the (optional) or on the rear of the Spacers Display VESA Mounting Holes

Display.

8. Route the and for the through the Power Video Cables Display Cable Management

Hole Displayand connect them to the .

9. Slide one onto one of the appropriately sized . Repeat for a total of Washer Screws

four .Screws

10. Insert the (with ) through the , the Screws Washers VESA Mount Transparent VESA

Panel Spacers Display VESA Mounting Holes, the (optional) , and into the .

11. Use a to tighten the .Phillips Head Screwdriver Screws

Warning! Do not over-tighten the . If resistance is encountered, stop tightening. Screws

Failure to do so could result in damage to the or the . Transparent VESA Panel Display

12. Connect the and for the to the and Power Video Cables Display Power Source

Video Source.

Mount the Transparent VESA Panel Assembly

1. Reach one hand under the to secure a grip onto Transparent VESA Panel Assembly

the . Use the other hand grip the Display Transparent VESA Panel.

Tip: This step should be completed without gloves. The Transparent VESA Panel

Assembly can easily slip out of gloved hands.

2. Lift the over to the . Transparent VESA Panel Assembly Mounting Location

3. Reattach the to the .VESA Mount Monitor Mount

4. Wipe away any on the with a Fingerprints Transparent VESA Panel Assembly

Microber Cloth.

Operation

Cleaning the Transparent VESA Panel

• Wipe clean with a .Microber Cloth

Note: Do not use to clean the .Ammonia Based Cleaners Transparent VESA Panel
