Side 1/2

Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 25, 2019 2:04 PM

Product Diagram (MONSTND)

Rear View

Part Function

1 Top Plate • Used as a platform for a Monitor or Laptop

2 Upper Leg

• Attaches to the Top Plate

• Congurable with three height-adjustment

settings

Cable-Management

Slots

• Used for organizing and routing Cables

4 Lower Leg • Attaches to the Upper Leg

Height-Adjustment

Screw

• Used to secure the Upper Legs and Lower

Legs together

• Can be removed to adjust height settings

Monitor Riser - Metal - Height Adjustable

Requirements

• Clean, Flat, and Stable Surface x 1

For the latest requirements please visit: www.startech.com/MONSTND.

Installation

Assembly

1. Place the Top Plate, top side down, onto a Clean, Flat, and Stable Surface.

2. Place the Upper Legs onto the Top Plate. Ensure the Holes in the Upper Legs are

aligned with the Holes in the Top Plate. The slanted portion of the Upper Legs

should be aligned with the slanted portion of the Top Plate.

3. Secure the Upper Legs to the Top Plate, using two M6x10 mm Screws for each

side. Fasten the M6x10 mm Screws using the 4 mm Hex Key.

4. Align the Lower Leg against the Upper Leg at the desired Monitor height setting.

5. Insert the Height-Adjustment Screw through the Upper Leg and into the Lower

Leg, then hand-tighten.

Note: Tighten the Height-Adjustment Screws by hand. Do not over-tighten.

6. Repeat steps 4 and 5 to attach the second Lower Leg.

7. Turn the Monitor Riser Assembly upright.

Operation

Height Adjustment

1. Place the assembled Monitor Riser, top side down, on a Clean, Flat, and Stable

Surface.

2. Remove the Height-Adjustment Screws.

3. Adjust the height of the Lower Legs to the desired height.

4. Insert the Height-Adjustment Screws through the Upper Legs and into the Lower

Legs, then hand-tighten.

5. Turn the Monitor Riser Assembly upright.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a ve-year warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	MONSTND
Bredde:	305 mm
Dybde:	405 mm
Højde:	125 mm
Vægt:	3200 g
Brugervejledning:	Ja
Produktfarve:	Sort, sølv
Ramme, materiale:	Aluminium, Steel
Pakkevægt:	3700 g
Pakkedybde:	460 mm
Pakkebredde:	354 mm
Pakkehøjde:	78 mm
Harmoniseret systemkode (HS):	94038900
Bæredygtighedscertifikater:	CE, RoHS
Højdejustering:	Ja
Overholdelse af bæredygtighed:	Ja
Maksimal vægtkapacitet:	10 kg
Skruer inkluderet:	Ja
Højdejusteringsområde:	125 - 175 mm
Forbedret kabelstyring:	Ja
Maksimal skærmstørrelse kompatibilitet:	32 "
Antal understøttede skærme:	1
Antal skruer:	6
Nøgletype:	Sekskantnøgle
Arbejdsoverfladeareal:	410 - 270 mm
