Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 29, 2023

Product ID

2S232422485-PC-CARD

PS74ADF-SERIAL-CARD

Port/LED/

Connector

Function

1Bracket

• Secures the card to the Host Computer Case

• The comes pre-installed Full Prole Bracket

• The is included Low Prole Bracket

2Activity LEDs

• Data Receive LED: GreenFlash to show activity

• Data Transmit LED: YellowFlash to show activity

3DB9 Serial Ports • Connect Serial Peripheral Devices

Serial Mode

Switch

• Change the between , , DB9 Serial Ports RS-232 RS-422

or RS-485

PCIe p1-x1 RS232/422/485 Serial Card - Low-Prole Brackets Included

J1/J2/J3/J4

Jumper

• Optional: Used to change the of Voltage Output DB9

Pin 9

• RI DB9 Pin 9disables power on . This is the default

setting.

• 12V SATA Power Connector draws power from the

( 12VOutputs )

• 5V SATA Power Connector draws power from the

( 5VOutputs )

PCIe p1-x1

Connector

• Insert into a on thePCI Express Slot Host Computer

SATA Power

Connector

• Optional: Connect an available SATA Power Connector

from the to provide power over Host Power Supply

DB9 Pin 9

Package Contents

2S232422485-PC-CARD:

• Serial Card x 1

• Low-Prole Bracket x 2

• Ribbon Cable x 1

• Quick-Start Guide x 1

Requirements

For the latest requirements, please visit: www.StarTech.com/2S232422485-PC-CARD

• Computer with an available PCI Express Slot (x1, x4, x8, or x16)

Installation

DIP Switch Settings

To change the between , , and , use the DB9 Serial Ports RS-232 RS-422 RS-485

respective located on the . enables/Serial Mode Switch Serial Card Dip Switch 3

disables a , used for impedance matching between the 120 Ω Termination Resistor

Tx+/Tx- and Rx+/Rx- (RS-422/RS-485 4-wire) and D+/D- (RS-485 2-wire) lines. The

purpose is to prevent reections on the line that may cause signal errors.

RS-232

RS-485 (Half-Duplex)

RS-422/485 (Full-Duplex)

*2S232422485-PC-CARD shown above

PS74ADF-SERIAL-CARD:

• Serial Card x 1

• Low-Prole Bracket x 4

• Ribbon Cable x 3

• Quick-Start Guide x 1

Linux

1. Navigate to: www.StarTech.com/2S232422485-PC-CARD

2. Click the tab.Drivers/Downloads

3. Under , download the for the Linux .Driver(s) Driver Package Operating System

4. Follow the that was extracted.Linux Driver Installation Guide

Verify Driver Installation

Windows

1. Navigate to the .Device Manager

2. Under , right-click and Ports (COM & LPT) AX99100 PCIe to High Speed Serial Port

click .Properties

3. Conrm that the is installed and working as expected.Driver

Verify Driver Installation (Linux)

1. Run from the command line.lsmod | grep r8125

2. Verify that the is present in the command line. Driver

DB9 Pin Out

Pin RS-232 RS-422/RS-485 (4 Wire) RS-485 (2 Wire)

1DCD TXD- -(485)

2RXD TXD+ +(485)

3TXD RXD+ X

4DTR RXD- X

5GND GND GND

6DSR

7RTS

8CTS

9RI/PWR

Install the Card

Note: If the is to be installed into a or PCIe Card Small Form Factor Low-Prole

Desktop Full-Prole Bracket, it’s required to replace the pre-installed with the included

Low-Prole Brackets DB9 Serial Ports Ribbon Cables. The that use will need to be

installed on the separate .Low-Prole Brackets

1. Turn o the and disconnect the and any Computer Power Cable Peripheral

Devices that are connected (e.g. printers, external hard drives, etc.).

2. Remove the from the .Cover Computer Case

Note: Consult the documentation that came with the computer for details about how

to do this safely.

3. Locate an open and remove the corresponding from PCIe Slot Metal Cover Plate(s)

the rear of the . In most instances, the is attached Computer Case Metal Cover Plate

to the rear of the with a single . Save this Computer Case Phillips Head Screw

Phillips Head Screw for the next step.

4. Gently insert the into the open and fasten the to Serial Card PCIe Slot Bracket(s)

the rear of the , using the from .Computer Case Phillips Head Screw Step 4

5. (Optional) Connect from the to the SATA Power Computer Power Supply SATA

Power Connector Serial Card, located on the rear of the .

6. Replace the from the that was removed in . Cover Computer Step 2

7. Reconnect all of the that were disconnected in .Peripheral Devices Step 1

8. Reconnect the to the rear of the .Power Cable Computer

Install the Driver

Windows

1. Navigate to: www.StarTech.com/2S232422485-PC-CARD

2. Click the tab.Drivers/Downloads

3. Under , download the for Windows .Driver(s) Driver Package Operating System

4. Open the and locate the corresponding folder for theDriver Package Windows

Version.

5. Execute the to install the driver.Setup File
