RACKCOND17HD

RKCOND17HDGB

1U 17in 1080p Dual Rail LCD Rack Console

with Front USB Hub

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View ...................................................................................................................................................... 1

Introduction ............................................................................................2

Packaging Contents 2 .................................................................................................................................

Front Panel Controls ..............................................................................2

Installation ..............................................................................................3

Rack Installation.........................................................................................................................................3

PC / Server Connection 5 ...........................................................................................................................

Connecting to a KVM Switch 5 ................................................................................................................

Operation ................................................................................................5

Dual Rail Slide 6 .............................................................................................................................................

Fingerprint Reader 7 ....................................................................................................................................

Specications 10 ..........................................................................................

Technical Support ..................................................................................11

Warranty Information ............................................................................11

Instruction Manual

Introduction

Packaging Contents

• 1x Dual Rail Rack Console

• 1x Set, Mounting Rails

• 2x USB A to A Cables

• 1x DVI Cable

• 1x VGA PS/2 KVM Cable

• 6x 6mm Flat Screws

• 2x Keys

• 2x Blockers w/ screws

• 1x NA Power Cord

• 1x Power Adapter

• 1x Instruction Manual / Software CD

Front Panel Controls

Controls Description

Soft power on/o button. Adjacent LCD is lit when on.

Auto Auto-synchronize and scale down display to any valid

factory preset timings.

Up Press to scroll the function you want to adjust.

Down Press to scroll the function you want to adjust.

Menu To access the main menu. This button also acts as

the “Enter” button.

Power Indicator

GREEN

RED

STANDBY

SUSPEND

OFF

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	RACKCOND17HD
Bredde:	445 mm
Dybde:	465 mm
Højde:	44 mm
Vægt:	10200 g
Produktfarve:	Sort
Skærmtype:	LCD
Pakkevægt:	16900 g
Skærm diagonal:	17 "
Skærmopløsning:	1920 x 1080 pixel
Skærmens lysstyrke:	300 cd/m²
Synsvinkel, horisontal:	140 °
Synsvinkel, vertikal:	120 °
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Strømforbrug (typisk):	23.35 W
Driftstemperatur (T-T):	0 - 50 °C
Skærm:	TFT LCD
Strømforsyningstype:	DC
Indgangsspænding for vekselstrømsadapter:	100 - 240 V
Kabler inkluderet:	DVI, KVM, USB
Materiale:	Stål
Certificering:	CE, FCC
Effektkrav:	12VDC, 4.17A
Bæredygtighedscertifikater:	RoHS
Billedformat:	16:9
Grænseflade:	USB, PS/2, DVI, VGA
Vis antal farver:	16,78 millioner farver
Kontrastforhold (typisk):	650:1
Pixel pitch:	0.264 x 0.264 mm
Gennemsnitstid mellem fejl (MTBF):	50000 t
Rackkapacitet:	1U
