Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 20, 2021 3:03 PM

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product Diagram (SM2E1BMU31C)

Exterior - Enclosure

Component Function

1Drive-Tray Screws x 2

• Used to secure the in the Drive Tray

Enclosure.

2Power & Activity LED

• Indicates that the is receiving Enclosure

power.

• Blinks during read/write activity.

3USB-C Port

• Used to connect the to the Enclosure Host

Computer.

Interior - Drive Tray

Component Function

4Drive Connector • Used to connect the to the .Drive Enclosure

Adjustable Drive

Length Holes

• Used to accommodate dierent drive lengths.

Drive-Mount Screw/

Stando/Nut

• Used to secure the to the .Drive Enclosure

M.2 SATA/NVMe SSD Enclosure - USB 3.2 (10Gbps) w/ USB-C and USB-A Cables

Package Contents

• M.2 SSD Enclosure x 1

• USB-C to USB-C Cable x 1

• USB-A to USB-C Cable x 1

• Drive Installation Screw Kit x 1

• Micro Screwdriver x 1

• Quick-Start Guide

Product Information

For the latest requirements, please visit

www.startech.com/SM2E1BMU31C

Product Requirements

• M2 SATA/NVMe SSD x 1

• 30 mm, 42 mm, or 60 mm Drive Length

• Needle-nose Pliers x 2

Installation

Installing a Drive

Warning! Handle drives with care.

1. Remove the (x 2) from the , using a Drive Tray Screws Enclosure Phillips Head

Screwdriver Cover Plate, and remove the .

2. Carefully pull the out of the . Drive Tray Enclosure

3. Remove the , using a .Drive-Mount Screw Phillips Head Screwdriver

4. Place the next to the and align the screw holes in the with Drive Drive Tray Drive

the on the to determine the desired Adjustable Drive Length Holes Drive Tray

Adjustable Drive Length Hole setting.

Note: If the drive mounting hardware is already installed in the correct position,

proceed to step 8.

5. Remove the and , using two sets of Drive Stando Nut Needle-nose Pliers.

6. Insert the and into the (60, 42, Drive Stando Nut Adjustable Drive Length Hole

or 30) according to the length of the .Drive

7. Tighten the and , using two sets of Stando Nut Needle-nose Pliers.

Disconnecting a Drive

Warning! If you remove the drive before you receive the notication that it’s safe to

do so, you could experience lost or corrupted data.

If the OS is Windows, complete the following steps:Host Computer’s

Windows PC

1. On the tray, click the icon.Notication Safely Remove Hardware and Eject Media

2. Click the storage device that you want to remove.

3. When the message appears indicating that , it’s safe to remove the device

disconnect the drive.

If the OS is macOS, complete the following steps:Host Computer’s

macOS

1. Close any windows that list the contents of the drive.

2. On your desktop, click and drag the icon onto the icon on USB Storage Trash Can

your desktop.

3. Wait 5 seconds, then disconnect the drive.

8. Gently slide the on the at a 30-degree angle into the corresponding Connector Drive

Drive Connector Drive Tray on the .

Note: The on the is keyed so that it only ts one way.Connector Drive

9. Lightly push the down into position on the .Drive Drive Tray

10. Insert the through the screw hole in the and into the Drive-Mount Screw Drive

Drive-Mount Stando.

11. Tighten the , using a . Do not over-Drive-Mount Screw Phillips Head Screwdriver

tighten.

12. Slide the into the center grooves in the enclosure so that the Drive Tray USB-C Port

is facing outward.

13. Place the over the and circuit board. Secure the Cover Plate USB-C Port Cover Plate

in place by inserting two on either side of the on the Drive-Tray Screws USB-C Port

front of the enclosure and tighten, using a .Phillips Head Screwdriver

Connecting a Drive to a Computer

When the enclosure is connected to the the OS will automatically install the Computer

necessary software.

Note: The enclosure does not require an external power supply, as it receives enough

power through the USB port that it is connected to.

• Connect the or the to the USB-C to USB-C Cable USB-A to USB-C Cable USB-C Port

on the and to a on the .Enclosure USB Port Computer

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two

conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique

subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
