ST122HDMILE

2-Port HDMI Video Splitter with Audio

- USB Powered

Installation Guide

Manual Revision:12/02/2010

For the most up-to-date information, please visit www.startech.com

Packaging Contents

• 1 x HDMI Splitter

• 1 x 24in USB to DC Power Cable

• 1 x Installation Guide

System Requirements

• HDMI enabled display devices (i.e. monitor, projector,

HDTV, etc.)

• HDMI enabled video source (i.e. computer, Blu-Ray

player, PVR/DVR, etc.)

• Available USB port

Installation

1. Make sure all displays and the video source device are

turned off before installing.

2. Connect an HDMI cable (not included) from each of the

video display devices (e.g. monitor, HDTV, etc) to the

numbered output HDMI connectors on the video splitter.

NOTE: Port 1 (OUT1) is the primary output so EDID

information will be taken from there. The capabilities of

the display on Port 1 will be applied to all other ports so be

careful not to exceed the capabilities of the other displays.

3. Connect the integrated HDMI cable from the video splitter

to the video source device (e.g. computer, PVR/DVR, etc).

If the cable is too short, an extension cable may be used.

4. Connect the included USB to power adapter cable from

the video splitter to an available USB port on the video

source device.

5. Turn on the display devices, followed by the video source.

The video output should be displayed on all connected

display devices.

Cascade Operation

The ST122HDMILE HDMI splitter can be cascaded/daisy-

chained with almost any other additional HDMI video

splitters for expanded capabilities, such as more ports and

reaching greater distances.

1. Make sure all displays and the video source device are

turned off before installing.

2. Connect the inputs of the second level HDMI

splitters to the “OUT1” and “OUT2” connectors on the

ST122HDMILE. If only connecting a single HDMI splitter,

make sure it is connected to “OUT1”.

3. Connect each of the video display devices (e.g. monitor,

HDTV, etc) to the output HDMI connectors on each of the

video splitters.

4. Power on the HDMI Video splitters, starting with the

ST122HDMILE, and then moving down the chain.

5. Turn on the display devices, followed by the video source.

The video output should be displayed on all connected

display devices.

NOTE: The more levels of HDMI splitters that are

cascaded, the greater the chances of the signal quality

becoming degraded.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their

respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may

be returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ofﬁcers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some

states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Specications

Number of Ports

Video Signal

High Speed HDMI (1.3)

Connectors

2 x HDMI type A female (Output)

1 x HDMI type A male (Input)

1 x DC Power

LEDs

1 x Power LED

Maximum Video Resolution

1080p

Maximum Cable Distance

15 m

Audio Support

Yes

HDCP Support

Yes

DDC Support

Yes

Enclosure Material

Plastic

Power Adapter

USB powered

Operating Temperature

0°C ~ 70°C (32°F ~ 158°F)

Storage Temperature

-20°C ~ 85°C (-4°F ~ 185°F)

Humidity

0% ~ 95% RH

Dimensions

85.5mm x 52.7mm x 20.3mm

Weight

120g

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	ST122HDMILE
Vekselstrømsindgangsspænding:	5 V
Bredde:	50 mm
Dybde:	75 mm
Højde:	25 mm
Vægt:	76 g
Brugervejledning:	Ja
Produktfarve:	Grå
Pakkevægt:	219 g
Pakkedybde:	210 mm
Pakkebredde:	145 mm
Pakkehøjde:	40 mm
HD-type:	Fuld HD
Understøttede videotilstande:	480i, 480p, 720i, 720p, 1080i, 1080p
Opbevaringstemperatur (T-T):	-20 - 85 °C
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
HDCP:	Ja
Driftstemperatur (T-T):	0 - 70 °C
Maksimal opløsning:	1920 x 1080 pixel
Kabler inkluderet:	USB
Understøttede grafikopløsninger:	1600 x 1200 (UXGA)
Fjernbetjening inkluderet:	Ingen
Certificering:	CE, FCC, TAA, REACH
Kabellængde:	0.28 m
Harmoniseret systemkode (HS):	85176990
Bæredygtighedscertifikater:	RoHS
USB-drevet:	Ja
HDMI-version:	1.3
Maksimal driftstilstand:	15 m
Videoudgang:	2x HDMI
Video porttype:	HDMI
Antal videoporte:	2
