Introduction

Thank you for purchasing a StarTech.com USB

to IrDA (IR) Mini Adapter. The perfect solution

for transferring data to and from portable

devices, the adapter allows you to establish a

wireless gateway for desktop or notebook com-

puters to transfer data using an infrared signal

via an available USB port. Supporting data

transfer rates of up to 115.2Kbps with an effec-

tive range of about one meter, USB2IR2 is ideal

for communicating with PDAs, Cell Phones and

more.

Features

• Compliant with IrDA specification V1.3

• USB Powered, no adapter required

• Fully compliant with USB spec. Rev. 1.1

• Maximum operating distance of 1 Metre

System Requirements

• Windows 98, 98SE, ME, 2000, XP or

Windows Vista

operating system

• An available USB port

Package Contents

• 1 x USB IR Adapter

• 1 x 2’ (0.6 metre) USB A-A M/F Extension

Cable

• 1 x Software/Driver CD

• 1 x Instruction Manual

UUSSBB ttoo IIrrDDAA ((IIRR)) MMiinnii AAddaapptteerr

UUSSBB22IIRR22

Installation

With the computer powered on, connect the USB IrDA adapter to

an available USB port. Windows should automatically detect a

new device, and prompt you for driver installation. Please select

Locate and install Driver Software.

Windows Vista

Windows will search online for driver updates for the adapter, and

notify you that it couldn’t locate suitable software. Click on

Browse my computer for Driver Software.

Windows will search online for driver updates for the adapter, and

notify you that it couldn’t locate suitable software. Click on

Browse my computer for Driver Software. Insert the Driver CD

into the CD/DVD-ROM drive. On the window that follows, click

the Browse button, then navigate to and select the \S110\IRDA\

folder on the driver CD, then click OK to designate the location.

Once the path to the correct file has been specified, click on Next

to begin installation. You will receive a warning, indicating that the

software you are attempting to install has not been verified. Click

on Install this driver software anyways, to proceed through

installation.

Once the necessary files have been installed, you will be notified

that The software for this device has been successfully

installed. Click Close.

Windows 2000 / XP

Specifications

Regulatory

Certifications

ROHS, CE

Product

Dimensions

50 x 18 x 10mm

Supported

Standards

USB v1.1 , IrDA v1.3

LED Indicator Activity

Supported Data

Transfer Rate

Up to 115.2Kbps

Support, Warranty Information, and Regulatory Compliance Statement

If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, follow-

ing the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty cov-

ers parts and labor costs only. StarTech.com does not warrant its products from

defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability: In no event shall the liability of StarTech.com Ltd. and

StarTech.com USA LLP (or their officers, directors, employees or agents) for any

damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or

related to the use of the product exceed the actual price paid for the product. Some

states do not allow the exclusion or limitation of incidental or consequential damages.

If such laws apply, the limitations or exclusions contained in this statement may not

apply to you.

FCC Compliance Statement: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interfer-

ence in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be deter-

mined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:• Reorient or relocate the

receiving antenna.

Rev: October 24, 2007

With the computer powered on, connect the USB IrDA adapter to an available USB port. Windows should

automatically detect a new device, and prompt you for driver installation:

When the Found New Hardware Wizard launches, please

select No, Not this time and click on Next.

On the screen that follows, select Install from a list or specif-

ic location, then click Next.

On the screen that follows, select Search for the best driver

in these locations, ensure the only checkmark appearing on

the page is next to Include this location in the search then

click the Browse button to navigate to and highlight the

S110\IRDA\ folder, and click OK. Click Next to proceed.

Please wait while Windows installs the necessary files. Once complete, a message will appear

indicating that The Wizard has finished installing the software.... Click Finish to conclude

installation.

Verifying Successful Installation

Right-click on My Computer (Computer in Windows Vista

), and select Manage.

In the left pane, click on Device Manager, and in the right pane, click on Infrared Devices. If

installation was successful, you will see S110 USB Infrared Controller listed:

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Ikke kategoriseret
Model:	USB2IR2
Bredde:	20 mm
Dybde:	30 mm
Højde:	10 mm
Pakkevægt:	60 g
Forbindelsesteknologi:	Trådløs
Kompatible operativsystemer:	Windows 98/98SE/2000/ME/XP/Vista
Værtsgrænseflade:	USB
Maksimal driftstilstand:	1 m
Overholdelse af branchestandarder:	FIR, IrDA: v1.3, MIR, SIR, USB: v1.1
Dataoverførselshastighed:	4 Mbit/s
Antal kasser eller hovedpapkasser:	120 stk
Sikkerhed:	FCC, CE & VCCI
Chipsæt:	Tanic S110
