Side 1/44

OPERATION AND INSTALLATION

C SERIES 3-PHASE ELECTRONICALLY CONTROLLED INSTANTANEOUS WATER HEATERS

Conforms to ANSI/UL Std. 499

Certiﬁed to CAN/CSA Std. C22.2 No.88

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 12KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 15KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 18KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 24KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 27KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 36KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 48KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 54KW

» CF PLUS/CE PLUS/CES PLUS 60KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 72KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 81KW

» CF PLUS/CE PLUS/CES PLUS 90KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 108KW

» CF PLUS/CE PLUS/CES PLUS 120KW

» CF PLUS/CE PLUS/CES PLUS/CERO PLUS 144KW

2 | CF CE CES CERO PLUS SERIES WWW.STIEBEL-ELTRON-USA.COM

CONTENTS | OPERATION

OPERATION

1. General information

Read this entire manual. Failure to follow all the guides, instructions

and rules could cause personal injury or property damage. Improper

installation, adjustment, alteration, service and use of this unit can

result in serious injury.

This unit must be installed by a licensed electrician and plumber. The

installation must comply with all national, state and local plumb-

ing and electric codes. Proper installation is the responsibility of

the installer. Failure to comply with the installation and operating

instructions or improper use voids the warranty.

Save these instructions for future reference. The installer should

leave these instructions with the consumer.

If you have any questions regarding the installation, use or opera-

tion of this water heater, or if you need any additional installation

manuals, please call our technical service line at 800.582.8423 (USA

and Canada only). If you are calling from outside the USA or Canada,

please call USA 413.247.3380 and we will refer you to a qualiﬁed

Stiebel Eltron service representative in your area.

!This is the safety alert symbol. It is used to alert you to

potential personal injury hazard. Obey all safety mes-

sages that follow this symbol to avoid possible injury or

death.

1.1 Safety information

1.1.1 Structure of safety information

KEYWORD: Type of risk

Here, possible consequences are listed that may

result from not observing the safety information.

fSteps to prevent the risk are listed.

1.1.2 Symbols, type of risk

Symbol Type of risk

!Injury

Electrocution

Burns or scalding

OPERATION

1. General information ___________________________________________ 2

1.1 Safety information __________________________________________________ 2

1.2 Other symbols in this document _________________________________ 3

2. Safety ____________________________________________________________ 3

2.1 Intended use _________________________________________________________ 3

2.2 Safety precautions __________________________________________________ 3

2.3 Test symbols _________________________________________________________ 3

2.4 Licenses / certiﬁcates ______________________________________________ 3

3. Functional characteristics _____________________________________ 4

4. Troubleshooting ________________________________________________ 5

4.1 Fault table ____________________________________________________________ 5

4.2 Solutions based on symptoms in fault table __________________ 5

4.3 Cold element resistivity by heater type (in Ohms) ___________ 5

5. Mounting the water heater ___________________________________ 6

5.1 Mounting _____________________________________________________________ 6

6. Water connections _____________________________________________ 6

6.1 Venting the air_______________________________________________________ 6

6.2 Leakage check _______________________________________________________ 7

7. Electrical connection ___________________________________________ 7

7.1 Safety__________________________________________________________________ 7

7.2 Electric supply _______________________________________________________ 7

7.3 Terminal block torque _____________________________________________ 7

8. Commissioning _________________________________________________ 8

9. Maintenance ____________________________________________________ 8

10. Technical data __________________________________________________ 9

10.1 Technical data - CF Plus series ___________________________________ 9

10.2 Technical data - CE Plus series __________________________________10

10.3 Technical data - CES Plus series ________________________________11

10.4 Technical data - CERO Plus series ______________________________12

10.5 Dimension drawings ______________________________________________13

10.6 Wiring diagrams ___________________________________________________16

10.7 CF/CE/CES/CERO Plus temperature rise _______________________39

11. Spare parts and service advice ______________________________40

12. Warranty _______________________________________________________42
