Side 1/31
Revision A: 11.17.2020
P/N 21-20006
*Includes End Panels. ^With Levelers Extended 1 1/4” From Base Frame
HIGH ENVIRONMENT MOBILE REFRIGERATED
SELF-SERVICE MERCHANDISER
> ROLL-DOWN SECURITY DOOR
> SELF-CONTAINED UNITS ARE STANDARD
> CLEAN SWEEP FOR SELF-CONTAINED
UNITS (OPTIONAL)
Operating Manuals\Oasis\HECOXXR_High Environment_Mobile_Self-Svc Unit_Oper Manual 21-20006.pub
888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
MODEL HECO37R - 36 1/4”L* x 33 1/4”D x 82 1/8”H^
MODEL HECO47R - 47 1/4”L* x 33 1/4”D x 82 1/8”H^
||||||
||||||
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
OPERATING MANUAL
M O B I L E S E R I E S
MODEL HECO57R - 59 1/4”L* x 33 1/4”D x 82 1/8”H^
MODEL HECO67R - 71 1/4”L* x 33 1/4”D x 82 1/8”H^
Model HECO57R Shown With Roll-Down
Security Door Down (Similar Design to Models
HECO37R, HECO47R and HECO67R)
Model HECO37R Shown With Roll-Down
Security Door Up (Similar Design to Models
HECO47R, HECO57R and HECO67R)
See SCC P/N 21-20628 For These
Models’ Field Service Parts List.
2
TABLE OF CONTENTS
OVERVIEW / ENVIRONMENTAL CONDITIONS / COMPLIANCE / WARNINGS / PRECAUTIONS /
WIRING .……….………………………………………………………………………………….……..
CASE REMOVAL FROM SKID (LEVELERS/CASTERS) …….……………...……………..…………….
INSTALLATION: MERCHANDISER SET-UP / ELECTRICAL SET-UP ……………………………...….
INSTALLATION, CONTINUED: SYNCHRONOUS DEFROST CONNECTION (OPTIONAL) ..……….
ROLL-DOWN SECURITY DOOR - EXTENDED ……………………………………......…………………..
ROLL-DOWN SECURITY DOOR - RETRACTED ………………………………………………………….
MAINTENANCE FUNDAMENTALS: LED LIGHT FIXTURES ……………………..…………………….
MAINTENANCE FUNDAMENTALS: FANS ………………………………………………………………...
MAINTENANCE FUNDAMENTALS, CONT’D: HONEYCOMB AIR DIFFUSERS ……………………..
MAINTENANCE FUNDAMENTALS, CONT’D: SHELF ASSEMBLY / SHELVES / LIGHTS / FAN
SWITCH ...……………………………………………………………………………………………….
MAINTENANCE FUNDAMENTALS, CONT’D: BALLAST ACCESS …………………………………….
MAINTENANCE, CONT’D - EVAPORATOR COIL / FAN / TUB / DRAIN / TROUGH / TXV, ETC…...
CONDENSER PACKAGE LAYOUT: MODELS HECO37R ONLY ……………………..………………...
CONDENSER PACKAGE LAYOUT: MODELS HECO47R ONLY ……………………..………………...
CONDENSER PACKAGE LAYOUT: MODELS HECO57R ONLY ……………………..………………...
CONDENSER PACKAGE LAYOUT: MODELS HECO67R ONLY ……………………..………………...
SERIAL LABEL & LOCATION / TECHNICAL INFORMATION / ADDITIONAL INFORMATION …....
CLEANING SCHEDULE (PERFORMED BY STORE PERSONNEL & TRAINED SERVICE
PROVIDERS) ……………………………….…………………………………….…...…….…....……
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS) ….....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ...…………………………...
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ..……..
CAREL® TEMPERATURE CONTROLLER INFORMATION ……………………………………….….....
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION .………….…….
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22-23
24
25-27
28-30
31
